Automatic mm / inch conversion · Core engineering specifications
| 3-seat sofa overall dimensions | 1800 x 800 x 780 mm | |
|---|---|---|
| Single armchair overall dimensions | 800 x 780 x 780 mm | |
| Coffee table overall dimensions | 1200 x 650 x 450 mm | |
| Seat height from floor for sofa and chairs | 420 mm | |
| Seat depth for all seating units | 580 mm | |
| Armrest height from floor for all seating units | 620 mm | |
| Backrest height from seat surface | 400 mm | |
| Armrest width for all seating units | 120 mm | |
| Coffee table lower shelf clearance from floor | 150 mm | |
| Seat cushion thickness | 120 mm | |
| Back cushion thickness | 100 mm | |
| Metal leg height for sofas and chairs | 150 mm | |
| Per-seat width on 3-seat sofa | 580 mm | |
| Leg Height / Floor Clearance | 160 mm |
Net weight / load capacity / users / durability
| 3-seat sofa net weight | 75 kg | |
|---|---|---|
| Single seating position static load capacity | 150 kg | |
| Seat foam density | 45 kg/m³ | |
| Back cushion foam density | 35 kg/m³ | |
| Seam stitch pitch | 8 stitches per 30mm | |
| Upholstery abrasion resistance | 50000 Martindale cycles | |
| Seat Foam Density / Rebound | 40 kg/m³ / 60% | |
| Upholstery Abrasion Reference | Fabric 60000 cycles; leather-class cover 1.4 mm | |
| Per-seat Load Reference | 130 kg/seat | |
| Upholstery Seam Pitch | 4 mm |
Core acceptance fields · Panels / hardware / frame / upholstery
| Seating outer frame upholstery | Cognac brown 1.0mm thick PU leather | |
|---|---|---|
| Seating inner cushion upholstery | Light grey 1.0mm thick PU leather | |
| Seat cushion core | High-density polyurethane foam wrapped in 20g non-woven fabric | |
| Back cushion core | Medium-density polyurethane foam with polyester fiber wrap | |
| Seating internal frame | 30x30mm hardwood and 1.2mm thick steel reinforced frame | |
| Seating support legs | 20x20mm black powder-coated square steel tube legs | |
| Coffee table top surface | 10mm thick tempered black safety glass with polished edges | |
| Coffee table vertical supports | 50x50mm transparent polished acrylic square legs | |
| Coffee table lower shelf | 8mm thick tempered black safety glass | |
| Table frame hardware | Polished chrome-plated steel corner connectors and leg mounts | |
| Seating support system | 40mm wide elastic webbing spaced 80mm apart under seat cushions | |
| Seat base dust cover | Black 30g non-woven fabric dust cover fitted to the underside of all seating units |
Adjustment / rotation / tilt / mobility / storage features
| Seating position count | 5 total seats (2 single chairs, 1 three-seat sofa) | |
|---|---|---|
| Leg design function | Elevated open metal legs provide 150mm floor clearance for easy under-seat cleaning | |
| Integrated armrest function | Continuous upholstered armrests connect front and back of each unit to eliminate sharp edges and define seating boundaries | |
| Cushion configuration | Fixed non-removable seat and back cushions tailored to the frame to prevent shifting during use | |
| Coffee table dual-surface design | Two-tier glass construction provides upper surface for refreshments and decor, lower open shelf for book or accessory storage | |
| Acrylic leg table function | Transparent acrylic support legs create a lightweight visual profile that does not block sightlines across the reception area | |
| Color blocking design function | Two-tone cognac and light grey upholstery provides a modern formal aesthetic that coordinates with both warm and neutral office interior palettes | |
| Floor protection function | Plastic glides on all seating and table legs prevent scratching of polished tile and hardwood commercial flooring during repositioning | |
| Cushion Service Configuration | Recommended 2 removable/replaceable cushion methods |
Verified carton / gross weight / assembly / loading data
| Total shipping packages | 6 packages | |
|---|---|---|
| 3-seat sofa package dimensions | 1820 x 820 x 480 mm | |
| Single armchair package dimensions | 820 x 800 x 420 mm | |
| Coffee table package dimensions | 1250 x 700 x 200 mm | |
| Total set shipping gross weight | 230 kg | |
| Total set shipping volume | 1.8 CBM | |
| On-site assembly time | 50 minutes | |
| 40HQ container load quantity | 42 sets | |
| Coffee table glass package dimensions | 1250 x 700 x 120 mm | |
| Hardware and leg package dimensions | 550 x 350 x 200 mm |
Recommended spaces / users / usage modes
| Corporate executive reception areas | Suitable for small executive waiting zones, with 5-seat capacity and formal two-tone aesthetic matching professional office interiors | |
|---|---|---|
| Small office meeting lounge spaces | Suitable for informal internal team discussion areas, with upright supportive seating and central coffee table for document and beverage placement | |
| Hotel lobby guest waiting zones | Suitable for mid-scale hotel public waiting areas, with durable PU upholstery resistant to frequent use and easy cleaning | |
| Studio customer consultation rooms | Suitable for design studio or consulting firm client meeting spaces, with compact footprint that fits small room layouts without crowding | |
| Recommended complementary decor | Pairs with low-pile commercial area rugs and simple framed wall art, without blocking floor outlets or walkways | |
| Shared office tenant lounge areas | Suitable for co-working space common lounge zones, with stain-resistant PU surfaces that withstand daily use by multiple tenants and guests | |
| Recommended complementary configuration | Pairs with 2400x1600mm low-pile commercial area rugs and simple framed wall art, without blocking floor outlets or emergency walkways |
EU Market Access Requirements* EN Standards
| Office furniture seating strength | EN 16139:2013 | |
|---|---|---|
| Furniture glass safety | EN 12150:2015 | |
| Upholstered furniture fire resistance | EN 1021:2014 | |
| Furniture surface durability | EN 14434:2018 |
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.4 Public and Lounge Seating |
|---|
Standards applicable to China-market projects
| Formaldehyde emission limit | GB 18584 | |
|---|---|---|
| Upholstered furniture safety | GB 20400 | |
| Tempered glass safety | GB 15763.2 | |
| Steel furniture coating durability | GB/T 3324 | |
| Upholstered furniture harmful substance limit | GB 18401 |
This product must meet the following technical requirements: 1. Formaldehyde emission limit: GB 18584; 2. Upholstered furniture safety: GB 20400; 3. Tempered glass safety: GB 15763.2; 4. Steel furniture coating durability: GB/T 3324; 5. Upholstered furniture harmful substance limit: GB 18401; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
