Automatic mm / inch conversion · Core engineering specifications
| Seat Cushion Thickness | 180 mm | |
|---|---|---|
| Back Cushion Thickness | 160 mm | |
| Leg Height / Floor Clearance | 160 mm |
Net weight / load capacity / users / durability
| Total set combined weight (sofas + table) | 185 kg | |
|---|---|---|
| 3-seater sofa total static load capacity | 450 kg | |
| Recommended maximum seating capacity | 5 persons | |
| Seat cushion foam density | 40 kg/m³ | |
| Back cushion foam density | 28 kg/m³ | |
| Foam rebound rate | 45% | |
| Upholstery seam tensile strength | 120 N | |
| Frame static load bearing factor | 2.0 x rated seat load | |
| Floor glide scratch resistance | 2000 abrasion cycles on polished tile | |
| Seat Foam Density / Rebound | 40 kg/m³ / 60% |
Core acceptance fields · Panels / hardware / frame / upholstery
| Seat and back outer upholstery | Dark grey matte PU faux leather, 1.2mm thickness, 50000 cycles Martindale abrasion resistance | |
|---|---|---|
| Outer side panel upholstery | Tan brown matte PU faux leather, 1.2mm thickness, matching grey leather abrasion rating | |
| Seat internal support board | 15mm thick multi-layer plywood frame | |
| Seat cushion filling | High-resilience polyurethane foam, wrapped with 20mm soft polyester batting | |
| Back cushion filling | Medium-density polyurethane foam with integrated lumbar support pad | |
| Sofa support frame and legs | 20x40mm rectangular black powder-coated carbon steel tube, 1.5mm wall thickness | |
| Coffee table top | 12mm thick black tempered glass with polished edges | |
| Coffee table frame and lower shelf | 25x25mm black powder-coated steel frame, 8mm thick black tempered glass lower shelf | |
| Upholstery stitching | Matching dark grey bonded polyester thread, 8 stitches per 30mm seam pitch | |
| Frame surface finish | Matte black electrostatic powder coating, 60um thickness, scratch-resistant | |
| Seat support webbing | 50mm wide elastic webbing, 80mm spacing under seat foam | |
| Floor contact glides | 50mm diameter injection-molded PP plastic glides, fitted to base of all legs |
Adjustment / rotation / tilt / mobility / storage features
| Seating configuration | Fixed 3-seater sofa + 2 single armchairs layout, pre-configured for reception area arrangement | |
|---|---|---|
| Frame stability design | Angled outward-splayed sled legs with integrated cross-bracing on each seating unit, no separate loose legs, no rocking function | |
| Coffee table storage | Two-tier design with top serving surface and lower open shelf for magazines, documents or decorative items | |
| Cushion design | Fixed non-removable seat and back cushions, stitched to frame to prevent shifting in high-traffic use | |
| Lumbar support | Integrated matching grey lumbar pillow on each seating position, positioned to support lower back during upright seated conversation | |
| Armrest design | Padded wide flat armrests upholstered in grey faux leather, suitable for resting arms or placing small items during use | |
| Surface protection | Plastic floor glides fitted to bottom of all metal legs, prevent scratching hard floor surfaces | |
| Assembly requirement | Knock-down delivery, legs and table frame require simple bolted assembly with included hardware | |
| Anti-tip design | Outward leg splay provides 100mm overhang beyond seat frame per side, preventing tipping when users lean on armrests | |
| Cushion Service Configuration | Recommended 2 removable/replaceable cushion methods |
Verified carton / gross weight / assembly / loading data
| Total number of shipping cartons | 7 cartons | |
|---|---|---|
| Largest carton dimensions (3-seater sofa frame) | 1950 x 720 x 480 mm | |
| Total combined shipping gross weight | 210 kg | |
| Total shipping volume (CBM) | 1.8 CBM | |
| On-site assembly time (2 persons) | 60 minutes | |
| 20ft GP container loading quantity (full sets) | 18 sets | |
| 40ft HQ container loading quantity (full sets) | 45 sets | |
| Packaging protection | 5-layer corrugated carton, 20mm EPE foam wrapping, corner protectors on glass and frame components | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set |
Recommended spaces / users / usage modes
| Corporate office reception areas | Suitable for executive reception lobbies, visitor waiting areas, providing formal, professional seating for guests during meetings and check-in | |
|---|---|---|
| Executive private office lounge zones | Suitable for placement in manager or director offices, providing casual seating for 1:1 meetings and visitor discussions | |
| Commercial lounge and waiting spaces | Suitable for high-traffic areas including bank branch lobbies, hotel business centers, and service center waiting areas, with durable faux leather upholstery resistant to frequent use | |
| Small meeting breakout spaces | Suitable for informal meeting breakout zones in open plan offices, paired with the matching coffee table for refreshments and document placement during quick discussions | |
| Color matching recommendation | Pairs well with light grey, white or marble-finish office flooring and wall surfaces, contrasts with warm wood or dark metal accent furniture | |
| Color matching configuration | Pairs well with light grey, white or marble-finish office flooring and wall surfaces, contrasts with warm wood or dark metal accent furniture and side tables | |
| Property public waiting areas | Suitable for apartment building lobbies, property management service centers, and sales office waiting zones, with rigid metal frame resistant to heavy daily use |
EU Market Access Requirements* EN Standards
| Office furniture structural strength recommendation | EN 16139:2013 Furniture - Strength, durability and safety - Requirements for non-domestic seating, applicable to all sofa seating units | |
|---|---|---|
| Furniture surface emission recommendation | EN 16516:2017 Construction products - Assessment of release of dangerous substances - Determination of emissions into indoor air, applicable to all upholstery and panel components | |
| Tempered glass safety recommendation | EN 12150:2015 Glass in building - Thermally toughened soda lime silicate safety glass, applicable to coffee table glass components | |
| Upholstery abrasion recommendation | EN 14465:2006 Textiles - Upholstery fabrics - Specification and test methods, applicable to PU faux leather upholstery |
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.4 Public and Lounge Seating |
|---|
Standards applicable to China-market projects
| Upholstered furniture safety recommendation | GB/T 3324 General technical requirements for wooden furniture, applicable to internal plywood frame structural safety | |
|---|---|---|
| Formaldehyde emission recommendation | GB 18580 Indoor decorating and refurbishing materials - Limit of formaldehyde emission from wood-based panels, applicable to plywood internal components | |
| Upholstered furniture flame retardancy recommendation | GB 20286 Flame retardant products and components in public places, applicable to PU leather and foam components for high-traffic office reception areas | |
| Tempered glass safety recommendation | GB 15763.2 Safety glazing materials in building - Part 2: Tempered glass, applicable to coffee table glass components |
This product must meet the following technical requirements: 1. Upholstered furniture safety recommendation: GB/T 3324 General technical requirements for wooden furniture, applicable to internal plywood frame structural safety; 2. Formaldehyde emission recommendation: GB 18580 Indoor decorating and refurbishing materials - Limit of formaldehyde emission from wood-based panels, applicable to plywood internal components; 3. Upholstered furniture flame retardancy recommendation: GB 20286 Flame retardant products and components in public places, applicable to PU leather and foam components for high-traffic office reception areas; 4. Tempered glass safety recommendation: GB 15763.2 Safety glazing materials in building - Part 2: Tempered glass, applicable to coffee table glass components; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
