Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 2000 × 880 × 860 mm | |
|---|---|---|
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Sofa static seat load | 300 kg total, 100 kg per seat | |
|---|---|---|
| Single armchair static load | 130 kg per chair | |
| Coffee table distributed top load | 40 kg | |
| Side table distributed top load | 25 kg | |
| Glass tabletop point-load capacity | 15 kg at center over 100 x 100 mm | |
| Sofa net weight reference | 65 kg | |
| Total seating capacity | 3 seats on sofa and 1 seat per armchair | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ | |
| Upholstery Thickness / Abrasion Reference | 1.4 mm / 50000 cycles |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Seat and back upholstery | Black leather-look upholstery over padded cushions; exact hide, split leather, or PU content needs BOM confirmation | |
|---|---|---|
| Cushion structure | Block foam seat cushions with segmented stitching and a padded roll-top back cushion | |
| Side panel construction | Upholstered black side panels enclosed by rectangular wood-finished posts and arm caps | |
| Wood-finished frame parts | Reddish-brown wood veneer or laminated wood composite arm caps, rails, and legs; substrate requires BOM confirmation | |
| Tabletop panels | Clear or frosted light-glass inset set into wood perimeter rails; tempering marking is not visible | |
| Table support frame | Rectangular wood-finished legs connected by an apron with square open cut-outs and intermediate rails |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Seating configuration | Fixed one-sofa, two-armchair reception layout providing five seats with no recline or folding mechanism | |
|---|---|---|
| Table service layout | Central coffee table serves all three seating positions, while the square side table provides a secondary cup and display surface | |
| Upholstery support | Tall padded backs, thick side panels, and wide armrests provide formal upright support for waiting and meeting use | |
| Table surface protection | Glass inset panels create wipe-clean drink surfaces while wood rails contain trays and cups within the tabletop |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Executive reception area | Formal five-seat arrangement for visitor waiting, brief meetings, and executive office reception due to its high-back sofa and matching armchairs | |
|---|---|---|
| Lounge or meeting tea area | Central and side tables support cups, reading material, and decor while maintaining clear circulation around three seating units |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
North America Purchasing & Inspection Reference * ANSI/BIFMA Standards
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.4 |
|---|
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
This product must meet the following technical requirements: 1. Technical standards and test reports must be supplied during tender or purchase confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
