Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1600 x 900 x 460 mm | |
|---|---|---|
| Tabletop thickness | 40 mm | |
| Angled side support leg cross-section | 50 x 80 mm | |
| Central base column dimensions | 450 x 350 x 420 mm | |
| Floor clearance under side supports | 120 mm | |
| Tabletop overhang past side supports | 80 mm | |
| Support leg wall thickness | 2 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Distributed static tabletop load capacity | 136 kg | |
|---|---|---|
| Overall product net weight | 40 kg | |
| Maximum point load on central support area | 68 kg | |
| Floor protection static load per foot | 10 kg | |
| Recommended surface impact resistance | 1.5 J | |
| Surface wear resistance rating | Class 2 | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop substrate | High-density engineered wood panel | |
|---|---|---|
| Tabletop veneer | Dark walnut tone wood veneer | |
| Support frame finish | Matte dark powder-coated steel | |
| Central base column finish | Satin light gray lacquer | |
| Floor glides | Non-marking nylon foot pads | |
| Connector hardware | Zinc-plated steel bolt fittings | |
| Tabletop edge treatment | Pencil-round polished edge | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support | |
| Reference Finish / Color Count | Recommended 6top finishes and 3frame colors |
Adjustment / rotation / tilt / mobility / storage features
| Central base unit | Closed fixed storage compartment with two horizontal drawer fronts | |
|---|---|---|
| Leveling adjustment | Rotating nylon foot glides for uneven floor alignment | |
| Surface function | Fixed flat top designed for beverage service and decorative display | |
| Floor protection | Non-abrasive glides prevent scratching on hard stone or wood flooring | |
| Cleaning compatibility | Smooth sealed surfaces suitable for damp cloth wiping | |
| Stability design | Wide angled support geometry eliminates wobble on level surfaces | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Commercial reception lounge | Positioned centrally between grouped sofas for guest beverage and display use | |
|---|---|---|
| High-end residential living room | Serves as low center table for casual seating areas in luxury homes | |
| Executive office waiting area | Provides stable surface for reading materials and refreshments for waiting guests | |
| Hotel lobby lounge | Suitable for high-traffic public seating zones with durable easy-clean surfaces | |
| VIP meeting breakout space | Supports informal discussion areas with low-profile unobstructed design |
EU Market Access Requirements* EN Standards
| EN 15372:2008 | Furniture – Strength, durability and safety for non-domestic tables, applicable to commercial use load testing | |
|---|---|---|
| EN 12521:2015 | Furniture – Strength, durability and safety for domestic tables, applicable to residential lounge use |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Office Furnishings – Desk Products, applicable for commercial reception area performance testing |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to tabletop structural testing | |
|---|---|---|
| GB/T 4893.8-2013 | Surface wear resistance test method for furniture finishes, applicable to top coating validation | |
| GB 18584-2001 | Indoor decorating and refurbishing materials limit of harmful substances, applicable to wood panel emission testing |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to tabletop structural testing; 2. GB/T 4893.8-2013: Surface wear resistance test method for furniture finishes, applicable to top coating validation; 3. GB 18584-2001: Indoor decorating and refurbishing materials limit of harmful substances, applicable to wood panel emission testing; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
