Automatic mm / inch conversion · Core engineering specifications
| Overall three-seat sofa dimensions | 2000 x 860 x 780 mm | |
|---|---|---|
| Overall single armchair dimensions | 950 x 860 x 780 mm | |
| Seat height from floor | 450 mm | |
| Seat depth | 580 mm | |
| Backrest height above seat | 330 mm | |
| Armrest height above floor | 620 mm | |
| Leg floor clearance | 120 mm | |
| Matching oval coffee table dimensions | 1200 x 600 x 450 mm | |
| U-shape arrangement footprint | 3200 x 2400 mm | |
| Seat cushion thickness | 120 mm | |
| Back cushion thickness | 80 mm | |
| Metal leg tube diameter | 30 mm | |
| Leg Height / Floor Clearance | 160 mm |
Net weight / load capacity / users / durability
| Total set net weight | 125 kg | |
|---|---|---|
| Three-seat sofa static load capacity | 450 kg | |
| Seat foam density | 45 kg/m³ | |
| Foam rebound rate | 60% | |
| Recommended maximum user weight per seat | 130 kg | |
| Frame static load cycle durability | 50000 cycles | |
| Warranty period | 5 years | |
| Available color options | 4 | |
| Seat Foam Density / Rebound | 40 kg/m³ / 60% | |
| Upholstery Abrasion Reference | Fabric 60000 cycles; leather-class cover 1.4 mm |
Core acceptance fields · Panels / hardware / frame / upholstery
| Upholstery outer shell | PU leather (faux leather), 1.2mm thickness | |
|---|---|---|
| Side contrast panels | Matte gray PU leather, 1.2mm thickness | |
| Seat and back fill | High-density polyurethane foam with serpentine spring support | |
| Internal support frame | Kiln-dried solid hardwood + 15mm plywood panel structure | |
| Legs | Powder-coated matte black carbon steel, 1.5mm wall thickness | |
| Armrest structure | Padded curved wrap-over design with internal wood substrate | |
| Coffee table top | 12mm sintered stone matte light gray finish | |
| Coffee table base | Brushed stainless steel tubular frame with oval ring foot | |
| Seam stitching | Reinforced polyester thread, 8 stitches per 50mm pitch | |
| Upholstery abrasion resistance | 50000 Martindale cycles | |
| Timber Frame Section / Moisture | Primary section ≥30 × 50 mm; recommended moisture 12% | |
| Spring / Webbing Specification | Sinuous spring wire 4 mm; elastic webbing 70 mm wide |
Adjustment / rotation / tilt / mobility / storage features
| Seating configuration | Fixed three-seat sofa plus two single armchairs for 5-person guest capacity | |
|---|---|---|
| Assembly requirement | Knock-down leg attachment for sofa, chairs and coffee table | |
| Surface maintenance | Stain-resistant smooth upholstery wipeable with mild detergent | |
| Stability design | Four-point leg contact per seating piece with non-marking floor glides | |
| Arrangement flexibility | Modular placement allows linear, U-shape or separate zone configuration | |
| Weight distribution | Serpentine spring seat support prevents premature cushion sag | |
| Floor protection | Non-scratch plastic glides fitted to all leg bases | |
| Cushion Service Configuration | Recommended 2removable/replaceable cushion methods |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Module Carton Dimensions | 2200× 1050× 850 mm | |
| Reference Packaging Volume | 1.8 m³/item | |
| Reference Packaged Gross Weight | 110 kg/item |
Recommended spaces / users / usage modes
| Corporate office reception lobbies | Formal two-tone design accommodates 5 waiting guests in professional arrangement | |
|---|---|---|
| Executive suite meeting waiting areas | Compact U-shape configuration fits small visitor zones outside private offices | |
| Conference room break-out spaces | Upholstered comfort supports short meeting and post-meeting conversational use | |
| Business lounge and visitor centers | Stain-resistant contract-grade upholstery suits high-traffic public office areas | |
| Medical and professional service waiting rooms | Fixed stable seating and wipeable surfaces support daily cleaning requirements | |
| Modern open office collaboration zones | Neutral gray/white finish coordinates with contemporary office interior palettes |
EU Market Access Requirements* EN Standards
| EN 13761:2002 | Office furniture – Visitor seating, strength and durability performance reference | |
|---|---|---|
| EN 1022:2018 | Domestic and contract furniture – Seating stability test method reference | |
| EN 12520:2015 | Furniture – Strength, durability and safety for domestic seating reference |
US and Canada office-furniture standards
| ANSI/BIFMA X5.1-2017 | General purpose office chairs, static load and durability reference for guest seating | |
|---|---|---|
| ANSI/BIFMA e3-2019 | Furniture sustainability standard for material and emission criteria reference |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to internal frame quality inspection | |
|---|---|---|
| GB/T 19001-2016 | Quality management system reference for manufacturer production control | |
| GB 18584-2001 | Indoor decoration material limit of harmful substances for wooden furniture, emission inspection reference | |
| GB/T 2703-2022 | Furniture test method for seat stability and static load, applicable to seating performance verification |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to internal frame quality inspection; 2. GB/T 19001-2016: Quality management system reference for manufacturer production control; 3. GB 18584-2001: Indoor decoration material limit of harmful substances for wooden furniture, emission inspection reference; 4. GB/T 2703-2022: Furniture test method for seat stability and static load, applicable to seating performance verification; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
