Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 1200 × 600 × 450 mm | |
|---|---|---|
| Overall assembled dimensions | 1200 x 600 x 450 mm | |
| Tabletop thickness | 36 mm | |
| Frame tube section | 30 x 30 mm | |
| Frame wall thickness | 1.2 mm | |
| Under-table ground clearance | 120 mm | |
| Tabletop corner radius | 80 mm | |
| Lower cross stretcher height | 80 mm | |
| Leg footprint width per side | 580 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Net product weight | 25 kg | |
|---|---|---|
| Distributed static top load capacity | 150 kg | |
| Surface heat resistance threshold | 120 °C | |
| Surface abrasion resistance | 4000 cycles | |
| Adjustable foot pad leveling range | 10 mm | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years; finish 2 years |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Tabletop panel | White marble-pattern engineered sintered stone | |
|---|---|---|
| Frame and legs | Matte black powder-coated carbon steel tube | |
| Lower cross stretcher | Matching matte black steel tube | |
| Tabletop underside support | Powder-coated steel support rails | |
| Foot pads | Non-marking nylon adjustable glides | |
| Assembly hardware | Zinc-plated steel bolts and Allen key | |
| Surface finish coating | Lead-free matte polyester powder coat | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support | |
| Reference Finish / Color Count | Recommended 6top finishes and 3frame colors |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Leveling adjustment | Rotating nylon foot pads adjust up to 10 mm | |
|---|---|---|
| Open under-frame storage | 120 mm clearance below cross support | |
| Knock-down assembly | Frame bolts to top support rails with included hardware | |
| Surface use compatibility | Heat and scratch resistant polished top | |
| Structural bracing | Lower horizontal cross stretcher connects all four legs | |
| Non-marring contact | Soft nylon glides on all leg bases | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Office reception lounge | Positioned between seating groups for guest beverage and decor placement | |
|---|---|---|
| Residential living room | Centered in front of sofa and armchairs for everyday coffee and display use | |
| Executive break-out space | Low-profile design complements upholstered lounge seating without blocking sight lines | |
| Hotel lobby seating area | Durable scratch-resistant surface withstands high-traffic public use | |
| Showroom display setting | Sleek metal and stone finish highlights contemporary furniture collections |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 15372:2008 | Furniture strength, durability and safety for non-domestic tables | |
|---|---|---|
| EN 12521:2015 | Furniture mechanical safety requirements for tables |
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture | |
|---|---|---|
| GB/T 4893.9-2013 | Surface furniture heat resistance test method | |
| GB/T 4893.8-2013 | Surface furniture abrasion resistance test method |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture; 2. GB/T 4893.9-2013: Surface furniture heat resistance test method; 3. GB/T 4893.8-2013: Surface furniture abrasion resistance test method; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
