Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 1840 × 990 × 890 mm | |
|---|---|---|
| Seat height from floor | 450 mm | |
| Seat cushion depth | 580 mm | |
| Backrest height above seat | 400 mm | |
| Padded armrest height above seat | 180 mm | |
| Coffee table leg height | 438 mm | |
| Sofa leg height from floor | 150 mm | |
| Seat cushion thickness | 120 mm | |
| Backrest cushion thickness | 100 mm | |
| Coffee table top thickness | 12 mm | |
| Back Cushion Thickness | 160 mm | |
| Leg Height / Floor Clearance | 160 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Single seating unit static load capacity | 200 kg | |
|---|---|---|
| Set net weight (total) | 145 kg | |
| Seat foam density | 45 kg/m³ | |
| Foam rebound rate | 45% | |
| Upholstery abrasion resistance | 50000 cycles | |
| Recommended maximum user weight per seat | 150 kg | |
| Frame warranty period | 5 years | |
| Powder coat thickness on metal parts | 80 μm | |
| Seat Foam Density / Rebound | 40 kg/m³ / 60% | |
| Upholstery Abrasion Reference | Fabric 60000 cycles; leather-class cover 1.4 mm |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Seating upholstery | Dark brown leather-look microfiber/PU covering | |
|---|---|---|
| Seat cushion core | Dual-layer high-resilience polyurethane foam | |
| Back cushion core | High-resilience foam with soft polyester fiber wrap | |
| Inner seating frame | Kiln-dried solid hardwood with reinforced corner blocks | |
| Seat suspension system | Zigzag S-springs with cross-laced elastic webbing | |
| Sofa legs | 1.2mm thick powder-coated cold-rolled steel angled legs | |
| Coffee table top | 12mm thick sintered stone effect panel | |
| Coffee table frame | 1.5mm thick black powder-coated steel open frame | |
| Stitching details | Matching dark polyester thread with 8 stitches per inch | |
| Foot pads | Non-slip nylon floor protection glides | |
| Timber Frame Section / Moisture | Primary section ≥30 × 50 mm; recommended moisture 12% | |
| Spring / Webbing Specification | Sinuous spring wire 4 mm; elastic webbing 70 mm wide |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Seating configuration | Fixed stationary U-shaped layout with 2 single armchairs, 1 2-seat loveseat | |
|---|---|---|
| Assembly requirement | Knocked-down shipping, legs attach to seating with included bolts | |
| Coffee table placement | Central open clearance under table for foot and leg room | |
| Surface durability | Stain and scratch resistant stone-effect table top | |
| Maintenance access | Removable cushion pads for regular cleaning and upholstery care | |
| Floor protection | Non-marking glides on all legs to prevent hard floor damage | |
| Color option availability | Custom upholstery color options including black, gray, tan | |
| Configuration flexibility | Individual seating pieces can be repositioned to suit room layout | |
| Cushion Service Configuration | Recommended 2removable/replaceable cushion methods |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Module Carton Dimensions | 2200× 1050× 850 mm | |
| Reference Packaging Volume | 1.8 m³/item | |
| Reference Packaged Gross Weight | 110 kg/item |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Executive office reception lounge | Formal U-shaped layout for 4-guest meetings and visitor waiting | |
|---|---|---|
| Corporate lobby waiting area | Durable commercial-grade upholstery suits high-traffic public office spaces | |
| High-rise office meeting breakout space | Low lounge height supports informal collaborative discussions | |
| Hotel business center reception | Professional dark brown finish matches formal hospitality interior design | |
| Executive boardroom ancillary seating | Pairs with formal conference furniture for pre-meeting guest accommodation |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 13759:2001 | Domestic and contract seating strength and durability test methods | |
|---|---|---|
| EN 1022:2018 | Seating stability test requirements for commercial lounge seating | |
| EN 12520:2015 | Furniture strength, durability and safety requirements for seating |
North America Purchasing & Inspection Reference * ANSI/BIFMA Standards
US and Canada office-furniture standards
| ANSI/BIFMA X5.4-2021 | Lounge and public seating durability and safety standard, 113kg load test reference |
|---|
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to hardwood sofa frame quality | |
|---|---|---|
| GB/T 16799-2008 | Furniture leather specification, applicable for genuine leather upholstery grading | |
| GB 18584-2001 | Formaldehyde emission limit for interior furniture, ≤0.124mg/m³ required for indoor use | |
| GB/T 19001-2016 | Quality management system reference for commercial furniture production |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to hardwood sofa frame quality; 2. GB/T 16799-2008: Furniture leather specification, applicable for genuine leather upholstery grading; 3. GB 18584-2001: Formaldehyde emission limit for interior furniture, ≤0.124mg/m³ required for indoor use; 4. GB/T 19001-2016: Quality management system reference for commercial furniture production; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
