Automatic mm / inch conversion · Core engineering specifications
| Two-seater sofa overall dimensions | 1900 x 850 x 800 mm | |
|---|---|---|
| Single armchair overall dimensions | 900 x 850 x 800 mm | |
| Tea table overall dimensions | 1300 x 700 x 550 mm | |
| Seat height from floor | 450 mm | |
| Seat depth (usable surface) | 550 mm | |
| Backrest height above seat | 350 mm | |
| Armrest height above seat | 200 mm | |
| Table usable surface thickness | 15 mm | |
| Tea table lower storage shelf clearance | 250 mm | |
| Cantilever sofa base front projection | 120 mm | |
| Sofa base ground contact bar length | 800 mm | |
| Three-seater sofa overall dimensions | 2000 x 850 x 850 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Lower shelf static load capacity | 30 kg | |
|---|---|---|
| Two-seater sofa net weight | 55 kg | |
| Seat cushion indentation load deflection (ILD) | 45 | |
| Seat foam rebound rate | 40% | |
| Upholstery abrasion resistance (Martindale) | 50000 cycles | |
| Table drawer static load per drawer | 10 kg | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ | |
| Upholstery Thickness / Abrasion Reference | 1.4 mm / 50000 cycles | |
| Five-star Base Static Load Reference | Acceptance target ≥120 kg; chair reference load 150 kg |
Core acceptance fields · Panels / hardware / frame / upholstery
| Seat and back upholstery | 1.2mm thick black polyurethane faux leather | |
|---|---|---|
| Seat cushion core | 40mm thick high-density polyurethane foam | |
| Back cushion core | 30mm thick medium-density polyurethane foam | |
| Sofa internal frame | 20mm x 40mm rectangular steel tube frame with 1.2mm wall thickness | |
| Sofa base | Polished 304-grade stainless steel cantilever sled base, 2mm wall thickness | |
| Tea table load-bearing frame | 20mm x 40mm black powder-coated rectangular steel tube, 1.5mm wall thickness | |
| Tea table top | 15mm thick dark green sintered stone surface with polished finish | |
| Tea table drawer unit | 18mm thick medium-density fiberboard with walnut wood grain veneer, fitted with brushed chrome pull handles | |
| Tea table lower shelf | 8mm thick tempered black glass open storage shelf | |
| Upholstery stitching | Nylon bonded thread with 8 stitches per 30mm seam pitch | |
| Drawer hardware | Full extension cold-rolled steel drawer slides with 10000 open/close cycle rating | |
| Base floor glides | 10mm thick non-marking PVC floor protection pads fitted to base contact points |
Adjustment / rotation / tilt / mobility / storage features
| Cantilever base flex function | Polished stainless steel sled bases provide controlled 5 mm flex when seated to improve comfort without floor damage | |
|---|---|---|
| Tea table integrated boiling station | Recessed cutout in tabletop accommodates electric tea kettle set with concealed cable routing for reception tea service | |
| Tea table drawer storage | Two side-mounted pull-out drawers provide enclosed storage for tea utensils, cups and small office supplies, extending 350mm when fully opened | |
| Tea table open lower shelf | Full-width open lower shelf provides accessible storage for bottled water dispensers, reading materials, waste bins and guest accessories | |
| Fixed upright back support | Taut, non-reclining backrests with fixed angle of 105 degrees from seat support upright formal posture suitable for guest reception | |
| Fixed wide armrests | Padded integrated armrests fixed at standard seating height support arm weight during extended conversations, with no height or angle adjustment | |
| Modular configuration flexibility | Set can be arranged in U-shape, face-to-face or linear layouts to fit different reception room footprints, with the tea table positioned central to all seats | |
| Fully assembled delivery option (seating) | All sofa units ship fully assembled with only base glides to be fitted on site, reducing on-site installation time | |
| Fixed wide padded armrests | Padded integrated armrests fixed at 200mm above seat surface support arm weight during extended conversations, with no height or angle adjustment | |
| Fully assembled seating delivery | All sofa units ship fully assembled with only base glides to be fitted on site, reducing on-site installation time to 50 minutes per set | |
| Recline Angle / Lock Reference | 125° with 3 suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg |
Verified carton / gross weight / assembly / loading data
| Total shipping packages per full set | 4 packages | |
|---|---|---|
| Two-seater sofa carton dimensions | 1950 x 900 x 650 mm | |
| Single armchair carton dimensions | 950 x 900 x 650 mm | |
| Tea table flat pack carton dimensions | 1350 x 750 x 150 mm | |
| Total gross weight per full set | 180 kg | |
| Total shipment volume per full set | 2.4 CBM | |
| On-site assembly time for full set | 50 minutes | |
| 40ft HQ container loading capacity (full sets) | 28 sets | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set |
Recommended spaces / users / usage modes
| Corporate executive reception areas | Suitable for executive floor guest rooms and visitor waiting spaces, with formal black upholstery that matches modern professional office aesthetics | |
|---|---|---|
| Government and institutional meeting waiting spaces | Durable contract-grade construction and neutral styling suit high-traffic public sector reception and meeting antechamber use | |
| Private office visitor seating zones | Compact footprint allows placement of two single chairs or one two-seater opposite an executive desk for short meetings with guests | |
| Business lounge and club waiting areas | Medium-firm cushioning and upright support provide comfortable seating for wait times of up to 45 minutes in premium business lounges | |
| Tea service integrated meeting spaces | Included multifunction tea table with dedicated boiling station supports traditional tea service for client meetings without additional furniture | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Access Requirements* EN Standards
| EN 13759:2004 Office furniture - Seating for reception areas | Applicable standard specifying stability, strength and dimensional requirements for reception seating intended for non-task office use | |
|---|---|---|
| EN 15372:2008 Furniture - Strength, durability and safety requirements for non-domestic storage furniture | Applicable to the tea table drawer and shelf storage components for commercial office use | |
| EN 12521:2015 Furniture - Strength, durability and safety requirements for non-domestic tables | Applicable to the tea table structure specifying load capacity, stability and surface durability requirements |
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.4 Public and Lounge Seating |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 General technical requirements for wooden furniture | Applicable to the tea table wood drawer components, specifying dimensional tolerance, edge finishing and structural strength requirements for procurement acceptance | |
|---|---|---|
| GB/T 19001-2016 Quality management systems | Recommended as supplier quality system requirement for consistent production of commercial office seating and table components | |
| GB 18584-2001 Indoor decorating and refurbishing materials - Limit of harmful substances of wood based furniture | Applicable to limit formaldehyde emission from engineered wood components in the tea table for indoor air quality compliance | |
| GB/T 24821-2009 Office furniture sofas | Applicable to all upholstered sofa units, specifying structural durability, foam performance and upholstery adhesion requirements for commercial reception use | |
| GB 20286-2006 Fire retardant products and components in public places - Requirements for fire performance of furniture and subassemblies | Applicable for high-traffic public reception areas requiring flame-retardant upholstery and foam |
This product must meet the following technical requirements: 1. GB/T 3324-2017 General technical requirements for wooden furniture: Applicable to the tea table wood drawer components, specifying dimensional tolerance, edge finishing and structural strength requirements for procurement acceptance; 2. GB/T 19001-2016 Quality management systems: Recommended as supplier quality system requirement for consistent production of commercial office seating and table components; 3. GB 18584-2001 Indoor decorating and refurbishing materials - Limit of harmful substances of wood based furniture: Applicable to limit formaldehyde emission from engineered wood components in the tea table for indoor air quality compliance; 4. GB/T 24821-2009 Office furniture sofas: Applicable to all upholstered sofa units, specifying structural durability, foam performance and upholstery adhesion requirements for commercial reception use; 5. GB 20286-2006 Fire retardant products and components in public places - Requirements for fire performance of furniture and subassemblies: Applicable for high-traffic public reception areas requiring flame-retardant upholstery and foam; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
