Automatic mm / inch conversion · Core engineering specifications
| 3-seater sofa overall dimensions | 2200 x 880 x 780 mm | |
|---|---|---|
| Single armchair overall dimensions | 950 x 880 x 780 mm | |
| Coffee table overall dimensions | 1300 x 700 x 500 mm | |
| Seat height from floor | 450 mm | |
| Seat depth per seating position | 580 mm | |
| Armrest height from seat surface | 180 mm | |
| Backrest height from seat surface | 400 mm | |
| Coffee table lower shelf clearance | 250 mm | |
| Sofa leg height | 150 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Per-seat static load capacity | 160 kg | |
|---|---|---|
| 3-seater sofa net weight | 75 kg | |
| Recommended maximum occupancy | 5 persons | |
| Upholstery abrasion resistance reference | 50000 double rubs | |
| Seat cushion compression set reference | 15% | |
| Upholstery abrasion resistance | 50000 double rubs | |
| Seat cushion compression set | 15% | |
| Chrome trim scratch resistance | 4H pencil hardness | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ |
Core acceptance fields · Panels / hardware / frame / upholstery
| Seat and back upholstery | Dark grey polyurethane faux leather, 1.2mm thickness, matte finish | |
|---|---|---|
| Seat cushion core | High-density polyurethane foam, 45kg/m³ density, 120mm thickness | |
| Backrest cushion core | Medium-density polyurethane foam, 35kg/m³ density, 80mm thickness | |
| Decorative and structural trim | Polished chrome-plated steel, 20mm width strip along all arm and base edges | |
| Sofa support legs | Polished chrome-plated square steel tube, 30mm cross-section, 150mm height, with adjustable foot glides | |
| Sofa internal frame | Kiln-dried solid hardwood and 15mm thick multilayer plywood frame | |
| Coffee table top | 8mm thick black tempered glass top with embedded tea tray recess | |
| Coffee table frame and lower shelf | 20x20mm square black powder-coated steel tube frame, 5mm thick black matte tempered glass lower shelf | |
| Seam construction | Nylon bonded thread stitching, 8 stitches per 50mm seam pitch along all panel edges | |
| Edge trim | Polished chrome-plated cold-rolled steel, 20mm width, 0.8mm thickness strip along all arm and base edges | |
| Coffee table frame | 20x20mm square black powder-coated steel tube, 1.2mm wall thickness, welded corner joints with matte black finish | |
| Coffee table shelves | 8mm thick black tempered glass top with recessed tea service area, 5mm thick black matte tempered glass lower shelf, polished smooth edges |
Adjustment / rotation / tilt / mobility / storage features
| Fixed seat and back configuration | Non-reclining, fixed cushion position design for formal upright reception seating, no tilt or recline mechanism | |
|---|---|---|
| Chrome trim protection | Continuous steel trim along arm and base edges resists scuffing and impact damage from bags or footwear during daily use | |
| Adjustable floor glides | Each sofa leg is fitted with a height-adjustable plastic glide to compensate for uneven floor surfaces and protect floor finishes | |
| Integrated coffee table storage | Two-tier coffee table design provides a recessed top surface for tea service and an open lower shelf for storage of supplies or waste bins | |
| Modular arrangement flexibility | Individual seating units can be positioned in multiple layouts including L-shape, opposing, or straight row configurations to fit different reception room sizes | |
| Easy clean upholstery | Smooth non-porous faux leather surface allows wiping and disinfection with standard commercial cleaning products without staining or water damage | |
| Fixed reception seating configuration | Non-reclining, fixed cushion position design for formal upright reception seating, no tilt or recline mechanism, fixed 100-degree backrest angle for professional posture | |
| Edge impact protection | Continuous 20mm steel trim along arm and base edges resists scuffing and impact damage from bags, luggage or footwear during daily high-traffic use | |
| Floor leveling adjustment | Each sofa leg is fitted with a 15mm travel height-adjustable nylon glide to compensate for uneven floor surfaces and prevent scratches to hard floor finishes | |
| Two-tier coffee table storage | Double-shelf coffee table design provides a recessed top surface for tea service and beverage placement, open lower shelf with 250mm clearance for document storage, waste bins or tissue boxes | |
| Modular layout flexibility | All individual seating units are freestanding with no permanent connecting hardware, can be arranged in L-shape, opposing face-to-face, or straight row configurations to fit reception rooms from 12sqm to 30sqm | |
| Disinfectable surface performance | Smooth non-porous faux leather surface allows wiping and disinfection with 75% alcohol or quaternary ammonium commercial cleaning products without staining or surface degradation |
Verified carton / gross weight / assembly / loading data
| Total shipping carton count | 5 cartons | |
|---|---|---|
| Largest carton dimensions (3-seater sofa) | 2250 x 900 x 650 mm | |
| Total shipment gross weight | 170 kg | |
| Total shipment volume | 2.9 CBM | |
| On-site assembly time | 60 minutes | |
| 20ft GP container loading quantity | 18 sets | |
| 40ft HQ container loading quantity | 45 sets | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm |
Recommended spaces / users / usage modes
| Corporate office reception areas | Suitable for waiting areas outside executive offices or main reception lobbies, formal appearance aligns with professional business environments | |
|---|---|---|
| Small conference and meeting spaces | Can be used for informal small group discussions or visitor meetings, seating 5 people comfortably around the central coffee table | |
| Public service waiting zones | Suitable for government service halls, bank branch waiting areas, or healthcare clinic waiting rooms, durable upholstery withstands high daily foot traffic | |
| Executive lounge areas | Appropriate for VIP lounges in office buildings, airports or hotels, polished chrome trim creates a premium modern appearance | |
| Recommended complementary furniture | Pair with matching side tables, floor lamps, and low-pile commercial carpet as shown in the render for a coordinated installation | |
| Corporate office main reception areas | Suitable for waiting areas outside executive suites or company main lobbies, formal dark grey finish and chrome trim align with professional business brand environments, 5-person capacity supports standard visitor wait volumes | |
| Internal departmental meeting spaces | Can be used for informal small group discussions or short visitor meetings, seating 5 people comfortably around the central coffee table for face-to-face conversation without formal conference table setup | |
| Executive VIP lounge areas | Appropriate for VIP lounges in office buildings, business hotels or airport business centers, polished chrome trim creates a refined modern appearance without excessive ornamentation for premium guest experience |
EU Market Access Requirements* EN Standards
| Seating durability recommendation | EN 12520:2015 Furniture - Strength, durability and safety - Requirements for domestic seating, applicable as baseline reference for light commercial reception seating performance | |
|---|---|---|
| Surface flammability recommendation | EN 1021:2014 Upholstered furniture - Ignitability - Part 1: Ignition source smouldering cigarette, applicable for fire safety verification of upholstery materials | |
| Seating durability requirement | EN 12520:2015 Furniture - Strength, durability and safety - Requirements for non-domestic seating, applicable as baseline reference for light commercial reception seating performance | |
| Upholstery flammability requirement | EN 1021:2014 Upholstered furniture - Ignitability - Part 1: Ignition source smouldering cigarette, applicable for fire safety verification of upholstery materials for public space use | |
| Surface scratch resistance requirement | EN 15187:2006 Furniture - Assessment of surface resistance to scuffing, applicable for verifying chrome trim and faux leather surface scratch durability |
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.4 Public and Lounge Seating |
|---|
Standards applicable to China-market projects
| Formaldehyde emission recommendation | GB 18584Indoor decorating and refurbishing materials - Limit of harmful substances of wood based furniture, applicable for testing VOC and formaldehyde emission from internal frame materials | |
|---|---|---|
| Glass safety recommendation | GB 15763.2Safety glazing materials in building - Part 2: Tempered glass, applicable for verifying tempered glass safety rating on coffee table surfaces | |
| Formaldehyde emission requirement | GB 18584Indoor decorating and refurbishing materials - Limit of harmful substances of wood based furniture, applicable for testing VOC and formaldehyde emission from internal plywood and hardwood frame materials | |
| Glass safety requirement | GB 15763.2Safety glazing materials in building - Part 2: Tempered glass, applicable for verifying tempered glass safety rating, impact resistance and breakage characteristics on coffee table surfaces | |
| Upholstery harmful substance requirement | GB 20400Leather and fur - Limit of harmful matter, applicable for testing heavy metal and phthalate content in polyurethane faux leather upholstery | |
| Furniture mechanical stability requirement | GB/T 10357.2Test of mechanical properties of furniture - Stability of seating, applicable for verifying sofa anti-tip stability during normal use |
This product must meet the following technical requirements: 1. Formaldehyde emission recommendation: GB 18584Indoor decorating and refurbishing materials - Limit of harmful substances of wood based furniture, applicable for testing VOC and formaldehyde emission from internal frame materials; 2. Glass safety recommendation: GB 15763.2Safety glazing materials in building - Part 2: Tempered glass, applicable for verifying tempered glass safety rating on coffee table surfaces; 3. Formaldehyde emission requirement: GB 18584Indoor decorating and refurbishing materials - Limit of harmful substances of wood based furniture, applicable for testing VOC and formaldehyde emission from internal plywood and hardwood frame materials; 4. Glass safety requirement: GB 15763.2Safety glazing materials in building - Part 2: Tempered glass, applicable for verifying tempered glass safety rating, impact resistance and breakage characteristics on coffee table surfaces; 5. Upholstery harmful substance requirement: GB 20400Leather and fur - Limit of harmful matter, applicable for testing heavy metal and phthalate content in polyurethane faux leather upholstery; 6. Furniture mechanical stability requirement: GB/T 10357.2Test of mechanical properties of furniture - Stability of seating, applicable for verifying sofa anti-tip stability during normal use; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
