Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 2100 × 900 × 880 mm | |
|---|---|---|
| Overall 3-seat sofa dimensions | 2100 x 900 x 880 mm | |
| Overall single armchair dimensions | 990 x 990 x 900 mm | |
| Central coffee table dimensions | 1200 x 600 x 450 mm | |
| Side end table dimensions | 600 x 600 x 430 mm | |
| Seat height from floor | 450 mm | |
| Seat cushion depth | 650 mm | |
| Backrest height above seat | 430 mm | |
| Armrest height above seat | 200 mm | |
| Coffee table drawer unit dimensions | 400 x 400 x 300 mm | |
| Sofa leg height | 30 mm | |
| U-shaped seating arrangement overall footprint | 3500 x 2800 mm | |
| Diagonal metal table leg height | 420 mm | |
| Seat Cushion Thickness | 180 mm | |
| Back Cushion Thickness | 160 mm | |
| Leg Height / Floor Clearance | 160 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Total set net weight | 300 kg | |
|---|---|---|
| Single seat static load capacity | 500 kg | |
| Seat foam density | 32 kg/m³ | |
| Back and armrest foam density | 20 kg/m³ | |
| Foam rebound rate | 45% | |
| Foam 75% compression set | 10% | |
| Spring system fatigue cycle rating | 50000 cycles | |
| Recommended total seating capacity | 5 persons | |
| Standard product warranty | 5 years | |
| Upholstery abrasion resistance | 50000 cycles |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Seat and back upholstery | 1.5mm thick beige faux leather (Xipi) | |
|---|---|---|
| Internal sofa frame | Kiln-dried solid hardwood with plywood reinforcement, 12% moisture content | |
| Seat support system | S-shaped serpentine springs with cross-weave elastic webbing | |
| Seat cushion filling | Dual-layer high-density polyurethane foam with 180g silk wadding top layer | |
| Back and armrest filling | High-density polyurethane foam with 3A doll cotton wrap | |
| Sofa support feet | Black matte PP plastic low-profile glide feet | |
| Coffee and side table tops | Dark brown engineered wood with matte laminate finish | |
| Coffee table drawer fronts | Light gray matte engineered wood with two horizontal drawers | |
| Table support legs | Brushed silver angled metal (steel alloy) V-shaped legs | |
| Seam stitching | 25mm stitch pitch concealed seam construction | |
| Timber Frame Section / Moisture | Primary section ≥30 × 50 mm; recommended moisture 12% | |
| Spring / Webbing Specification | Sinuous spring wire 4 mm; elastic webbing 70 mm wide |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Seating configuration | 3-seat sofa plus two single armchairs arranged in symmetric U-shape | |
|---|---|---|
| Backrest function | Fixed upright non-reclining backrests with no tilt or adjustment mechanisms | |
| Coffee table storage | Central two-drawer unit for storing small office supplies and tea sets | |
| Table surface function | Scratch-resistant laminate top for holding drinks, documents, and meeting supplies | |
| Floor protection | Integrated plastic glide feet to prevent scratching carpet and hard flooring | |
| Color option availability | Standard beige finish, with custom color options for commercial projects | |
| Cleaning functionality | Water-resistant faux leather surface for quick wipe cleaning of spills | |
| Arrangement flexibility | Modular units that can be repositioned to fit different reception room layouts | |
| Cushion Service Configuration | Recommended 2removable/replaceable cushion methods |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Total number of shipping cartons | 6 | |
|---|---|---|
| Total set gross shipping weight | 350 kg | |
| Total shipping volume | 3.5 cbm | |
| On-site assembly time | 50 minutes | |
| 20ft GP container loading quantity | 8 sets | |
| 40ft HQ container loading quantity | 18 sets | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Module Carton Dimensions | 2200× 1050× 850 mm | |
| Reference Packaging Volume | 1.8 m³/item |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Corporate office reception areas | Formal beige styling suitable for welcoming visitors and client waiting | |
|---|---|---|
| Executive office guest meeting spaces | U-shaped layout supports small face-to-face discussions and tea service | |
| Government institution waiting lounges | Durable commercial construction meets public area high-traffic requirements | |
| Conference room breakout spaces | Matching table set provides surface for documents and refreshments | |
| Hotel business center lobbies | Neutral color and formal design coordinate with professional hospitality interiors | |
| Enterprise visitor rest areas | Easy-to-clean upholstery reduces maintenance for high-usage public zones |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 1335-1:2020 | Office furniture seating strength and stability for non-adjustable guest seating | |
|---|---|---|
| EN 1021-1:2014 | Upholstered furniture ignition resistance for cigarette smolder test | |
| EN 16139:2013 | Strength, durability and safety requirements for non-domestic seating |
North America Purchasing & Inspection Reference * ANSI/BIFMA Standards
US and Canada office-furniture standards
| ANSI/BIFMA X5.4-2020 | Standard for lounge and public seating durability and strength requirements | |
|---|---|---|
| ANSI/BIFMA X7.1-2020 | Standard for formaldehyde and TVOC emissions from office furniture systems |
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to wood frame components | |
|---|---|---|
| GB 18584-2001 | Limit of harmful substances in wooden furniture, formaldehyde emission ≤0.1mg/L for wood parts | |
| GB/T 16799-2008 | Furniture use artificial leather, applicable to upholstery material performance requirements | |
| GB 20210-2006 | Fire safety requirements for upholstered furniture in public places, cigarette ignition resistance |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to wood frame components; 2. GB 18584-2001: Limit of harmful substances in wooden furniture, formaldehyde emission ≤0.1mg/L for wood parts; 3. GB/T 16799-2008: Furniture use artificial leather, applicable to upholstery material performance requirements; 4. GB 20210-2006: Fire safety requirements for upholstered furniture in public places, cigarette ignition resistance; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
