Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 2200 × 860 × 900 mm | |
|---|---|---|
| Seat height above floor | 450 mm | |
| Seat depth from front edge to backrest | 550 mm | |
| Armrest height above seat | 180 mm | |
| Backrest total height above seat | 450 mm | |
| Metal support leg height | 100 mm | |
| Coffee table pedestal base dimensions | 1000 x 500 x 350 mm | |
| Backrest vertical channel tufting width | 40 mm per channel | |
| Wood trim panel thickness (arm/side panels) | 18 mm | |
| Clearance between sofa/armchair and coffee table | 400 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Three-seat sofa total static load capacity | 500 kg | |
|---|---|---|
| Set total net weight | 180 kg | |
| Seat cushion foam density | 45 kg/m³ | |
| Seat foam rebound rate | 60% | |
| Seat foam compression set | 5% | |
| Backrest foam density | 35 kg/m³ | |
| Upholstery abrasion resistance | 100000 rub cycles | |
| Frame warranty period | 5 years | |
| Upholstery warranty period | 3 years | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Internal seating frame | Kiln-dried solid hardwood + multi-layer engineered wood, 12% moisture content | |
|---|---|---|
| Seat cushion padding | High-resilience polyurethane foam, 120 mm thickness | |
| Backrest padding | Medium-density polyurethane foam, 80 mm thickness | |
| Armrest padding | High-density polyurethane foam, 60 mm thickness | |
| Upholstery covering | 0.8 mm thick light beige PU microfiber leather, breathable matte finish | |
| Outer side/arm trim panels | Light oak wood veneer over 18 mm MDF with vertical fluted texture | |
| Support legs | 1.2 mm thick tapered gold-finish carbon steel, non-marking foot pads | |
| Coffee table top | 25 mm thick light oak veneer engineered wood, rounded polished edges | |
| Coffee table pedestal support | 2 mm thick powder-coated light grey steel column, wood veneer base plate | |
| Seam stitching | High-strength bonded polyester thread, 30 mm seam pitch | |
| Support connection hardware | Zinc-plated steel screws, mortise-and-tenon reinforced joints | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Seating structure | Fixed stationary non-reclining design, no tilt/swivel/recline mechanisms for stable guest seating | |
|---|---|---|
| Armrest design | Fully enclosed padded armrests with wood trim outer panel, integrated arm support for users | |
| Backrest support | Vertical channel-tufted center backrest, structured lumbar support without adjustable mechanisms | |
| Assembly requirement | Knock-down construction, leg attachment and table base assembly required for on-site installation | |
| Floor protection | Non-marking plastic foot pads on all legs to prevent hard floor scratching | |
| Coffee table function | Low-profile pedestal coffee table, open knee clearance under table for guest use during meetings | |
| Seating layout | Symmetric U-shaped arrangement, 5 total seating positions for reception meetings | |
| Customization | Upholstery color, wood trim finish and size adjustable for bulk procurement orders | |
| Cleaning performance | Stain-resistant faux leather upholstery, wipe-clean surface suitable for high-traffic public areas | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Largest carton dimensions (three-seat sofa) | 2250 x 890 x 620 mm | |
|---|---|---|
| Armchair carton dimensions (per unit) | 1230 x 890 x 600 mm | |
| Coffee table carton dimensions | 1250 x 750 x 220 mm | |
| Total packaged gross weight | 210 kg | |
| Total packaged volume | 1.4 CBM | |
| On-site assembly time | 50 minutes | |
| 20ft container loading quantity | 18 sets | |
| 40HQ container loading quantity | 46 sets | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Office reception lobbies | Formal symmetric layout provides structured guest waiting and greeting space for corporate offices | |
|---|---|---|
| Executive meeting rooms | Small-scale discussion and visitor meeting seating for manager or director office areas | |
| Waiting areas in public service facilities | Durable easy-clean upholstery suitable for high-traffic customer waiting zones | |
| Business lounge spaces | Modern minimalist aesthetic matches contemporary commercial lounge and co-working spaces | |
| Recommended matching configuration | Paired with the included pedestal coffee table for holding drinks, reading materials during visits | |
| User group suitability | Suitable for 5 adult users at full capacity, meeting standard business reception needs | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 13759:2009 | Applicable European standard for seating furniture stability and strength requirements for public use | |
|---|---|---|
| EN 1022:2018 | Applicable standard for domestic and contract seating stability testing requirements |
North America Purchasing & Inspection Reference * ANSI/BIFMA Standards
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.4 |
|---|
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3324-2024 | Applicable general technical requirement standard for wooden furniture frame and panel components | |
|---|---|---|
| GB 18584-2001 | Applicable indoor decoration material standard for formaldehyde emission limits on wooden components | |
| GB/T 16799-2008 | Applicable standard for polyurethane leather upholstery material performance requirements |
This product must meet the following technical requirements: 1. GB/T 3324-2024: Applicable general technical requirement standard for wooden furniture frame and panel components; 2. GB 18584-2001: Applicable indoor decoration material standard for formaldehyde emission limits on wooden components; 3. GB/T 16799-2008: Applicable standard for polyurethane leather upholstery material performance requirements; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
