Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 2600 × 2600 × 760 mm | |
|---|---|---|
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Seating capacity | 12 persons | |
|---|---|---|
| Static tabletop load capacity | 300 kg | |
| Table set net weight | 650 kg | |
| Place setting centerline spacing | 680 mm | |
| Recommended tabletop service load per diner | 20 kg | |
| Pedestal floor contact load | 4.2 kg per square meter dead load | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ | |
| Upholstery Thickness / Abrasion Reference | 1.4 mm / 50000 cycles | |
| Five-star Base Static Load Reference | Acceptance target ≥120 kg; chair reference load 150 kg |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Outer tabletop | White engineered stone or sintered stone slab with polished surface | |
|---|---|---|
| Rotating serving disc | Blue marble-pattern stone or stone-composite panel with polished finish | |
| Center lazy susan panel | Light oak-tone wood veneer or wood-grain laminate circular insert | |
| Pedestal base | Cream lacquered wood-composite enclosure with vertical grain and dark recessed plinth | |
| Rotation hardware | Concealed metal thrust bearing under the 1600 mm disc | |
| Chair upholstery | Cream leather or leather-look polyurethane fabric over padded seat and back |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Lazy susan rotation | 1600 mm central disc rotates 360 degrees on a concealed thrust bearing for shared dish service | |
|---|---|---|
| Place setting layout | 12 settings are arranged radially with 680 mm arc spacing and individual place mats | |
| Seating access | Open pedestal design provides 680 mm knee height and permits chair approach from all sides | |
| Chair support | Four hardwood legs and continuous arm-to-back frame provide rigid armchair support without folding or recline |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Total packaging volume | 13.6 CBM | |
|---|---|---|
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Private dining room | Suitable for hotel private dining, club restaurants, and executive banquet rooms requiring 12-person shared service | |
|---|---|---|
| VIP hospitality lounge | Recommended for corporate reception or government guest dining where a quiet rotating center and coordinated armchairs support formal service |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
This product must meet the following technical requirements: 1. Technical standards and test reports must be supplied during tender or purchase confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
