Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2600 x 2600 x 760 mm | |
|---|---|---|
| Tabletop thickness | 50 mm | |
| Central turntable track diameter | 2000 mm | |
| Rotating lazy Susan serving plate diameter | 600 mm | |
| Cylindrical pedestal base diameter | 1600 mm | |
| Pedestal base height | 710 mm | |
| Per-person place setting width | 580 mm | |
| Under-table knee clearance height | 660 mm | |
| Outer walnut tabletop ring width | 300 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Seating capacity | 14 persons | |
|---|---|---|
| Static distributed tabletop load | 300 kg | |
| Turntable rotating load capacity | 80 kg | |
| Net product weight | 210 kg | |
| Finish abrasion resistance | 2000 cycles | |
| Structural warranty | 5 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
| Outer dining ring | Walnut wood veneer over E0-grade MDF substrate | |
|---|---|---|
| Inner turntable track surface | Matte black laminated wear-resistant panel | |
| Central lazy Susan disc | Solid walnut wood veneer with radial sunburst pattern | |
| Cylindrical pedestal shell | Brushed stainless steel veneer over composite structural core | |
| Table edge banding | Solid walnut wood lipping matching outer veneer | |
| Turntable bearing assembly | Heavy-duty steel ball bearing swivel mechanism | |
| Structural connection hardware | Zinc-plated steel M10 assembly bolts and brackets | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support | |
| Reference Finish / Color Count | Recommended 6top finishes and 3frame colors |
Adjustment / rotation / tilt / mobility / storage features
| Central serving turntable | 360-degree smooth manual rotation for shared dish access | |
|---|---|---|
| Single pedestal design | No obstructing table legs to interfere with guest seating around perimeter | |
| Leveling feet | Adjustable threaded feet at pedestal base for uneven floor alignment | |
| Table surface performance | Stain and heat resistant laminate and wood finish for hot serving ware | |
| Assembly structure | Knockdown construction with separate pedestal and tabletop sections | |
| Tabletop edge profile | Smooth rounded eased edge to prevent contact injury for seated guests | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| High-end private restaurant dining rooms | Formal group meal service with 14 guest capacity and shared lazy Susan | |
|---|---|---|
| Hotel banquet private function rooms | Commercial grade construction for frequent event and catering use | |
| Corporate executive dining spaces | Sophisticated two-tone finish matches premium formal interior design | |
| Large family residential dining rooms | Accommodates extended family gatherings and holiday meals | |
| Wedding and event venue dining areas | Stable pedestal design provides unobstructed seating for all guests |
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Furniture strength, durability and safety for domestic and contract dining tables | |
|---|---|---|
| EN 13722:2004 | Furniture surface resistance to cold liquids for dining table top finishes | |
| EN 15372:2016 | Furniture stability requirements for free-standing tables to prevent tipping |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to wood dining table construction | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, E1 grade minimum for indoor use | |
| GB/T 4893.8-2013 | Furniture surface wear resistance test method for finished table surfaces | |
| GB/T 10357.1-2013 | Mechanical performance test for tables, static load and stability requirements |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to wood dining table construction; 2. GB 18580-2017: Formaldehyde emission limits for wood-based panels, E1 grade minimum for indoor use; 3. GB/T 4893.8-2013: Furniture surface wear resistance test method for finished table surfaces; 4. GB/T 10357.1-2013: Mechanical performance test for tables, static load and stability requirements; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
