PRODUCT MODULE 01 / 06

Physical Dimensions

Automatic mm / inch conversion · Core engineering specifications

Data source: Structured from factory data; final measured values prevail.

Overall dimensions (W × D × H)	640 × 630 × 1040 mm
Finished Seat Cushion Thickness	90 mm
Backrest Padding Thickness	70 mm
Lumbar Support Zone Height	240 mm
Clear Width Between Armrests	540 mm

PRODUCT MODULE 02 / 06

Weight, Load & Performance

Net weight / load capacity / users / durability

Data source: Product performance data; verify exact test conditions before procurement.

Recommended user weight capacity	136 kg
Chair net weight	15.5 kg
Seat loading area	0.24 m2
Seat foam density	45 kg/m3 molded high-resilience polyurethane
Seat foam indentation hardness	55 N at 25 percent compression
Foam resilience	35 percent ball rebound
Back mesh tensile rating	120 N per 25 mm strip
Gas-lift service class	Class 4, 100 mm stroke, 50 mm tube
Base static-load acceptance target	1134 kg vertical proof load
Caster rolling durability target	100000 cycles on hard-floor test path

PRODUCT MODULE 03 / 06

Materials & Structure

Core acceptance fields · Panels / hardware / frame / upholstery

Data source: Subject to the factory material list and inspection report.

Backrest upholstery	Light gray flexible mesh stretched within a matching molded frame, providing breathable back support
Seat cushion	Red woven upholstery over 70 mm polyurethane foam and a load-bearing seat shell
Back and arm frame	Silver-gray molded structural frame with integrated fixed loop arms and side back supports
Arm contact pads	Soft gray polymer pads fixed to the molded arm supports without visible adjustment controls
Under-seat mechanism	Black steel tilt and seat-height mechanism with one visible side lever and rear tension control
Base and casters	Polished aluminum five-star base with five black twin-wheel swivel casters

PRODUCT MODULE 04 / 06

Functions & Adjustment

Adjustment / rotation / tilt / mobility / storage features

Data source: Functional configuration; the supplier specification prevails.

Seat height adjustment	Pneumatic lever raises and lowers the seat through a 100 mm stroke from 440 to 540 mm
Back tilt mechanism	Synchro-style tilt provides a 15-degree back recline with proportional seat movement and tension adjustment
Mobility and station keeping	Five twin-wheel casters support rolling on hard floors or low-pile carpet; no wheel locks are visible
Backrest recline clearance behind frame	120 mm travel envelope

PRODUCT MODULE 05 / 06

Packaging & Logistics

Verified carton / gross weight / assembly / loading data

Data source: Reference for export quotations and container planning.

Export carton dimensions	680 x 640 x 380 mm
Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Carton Dimensions	850× 420× 720 mm
Reference Packaged Gross Weight	23 kg/set
Reference Carton Volume	0.26 m³/set

PRODUCT MODULE 06 / 06

Applications & Usage

Recommended spaces / users / usage modes

Data source: Recommended applications based on product form and category.

Primary workplace use	Open-plan desks, private workstations and conference seating where breathable back support and mobility are required
Procurement configuration	Specify with hard-floor casters for tile and wood floors, or substitute soft-tread casters for sensitive flooring

STANDARD S1

EU Market Entry Requirements * EN Standards

EU Market Access Requirements* EN Standards

EN 1335-1 suggested dimensional review	Verify seat height, back dimensions, clearance and adjustability against European office-chair dimensional requirements
EN 1335-2 suggested safety test scope	Applicable standards and test results require confirmation
EN 1335-3 suggested test method scope	Use specified structural test methods when validating the mechanism, base, arms and back frame

STANDARD S2

North America Purchasing & Inspection Reference * ANSI/BIFMA Standards

US and Canada office-furniture standards

ANSI/BIFMA X5.1 suggested acceptance scope	Evaluate back, seat, base, arm, tilt and caster performance under office-chair strength and durability tests

STANDARD S3

Standards Applicable to China-Market Projects * GB Standards

Standards applicable to China-market projects

GB/T 10357.3 suggested test scope	Apply chair strength and durability requirements to seat, back, arms and base during procurement inspection
GB/T 28004.2 suggested scope	Use office-chair stability, static load, impact and durability provisions for swivel task-chair acceptance

Standardized tender description text

This product must meet the following technical requirements:
1. GB/T 10357.3 suggested test scope: Apply chair strength and durability requirements to seat, back, arms and base during procurement inspection;
2. GB/T 28004.2 suggested scope: Use office-chair stability, static load, impact and durability provisions for swivel task-chair acceptance;
Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.

GENERATED EXPORTS

Ready-to-use export tools

Export data is generated from the current published product record.

Technical Report PDF

Directly download an English report in metric or imperial units.

PDF · TSK-MESH-MID-RED-SIL

Complete Parameter Workbook

Download all product information and parameter modules in English.

XLSX · TSK-MESH-MID-RED-SIL

International Listing Template

English title, specifications, materials, standards and purchasing fields.

XLSX · LISTING

Customs Declaration Data

Prepare customs description, material, usage, dimensions and declaration elements.

CUSTOMS · TSK-MESH-MID-RED-SILOpen Export Tool

Quick Actions

Post an RFQ

Product Description

The TSK-MESH-MID-RED-SIL mid-back task chair presents a clean office profile with a light gray breathable mesh back, a contrasting red upholstered seat, and a silver-gray molded frame. Integrated fixed loop arms and side back supports give the chair a continuous visual structure, while the polished aluminum five-star base and black twin-wheel casters add a functional, professional appearance. Its layout balances open back support with a padded seat and fixed armrest positioning, creating a distinctive look for desks and shared work areas. Construction combines flexible mesh stretched within a matching molded frame, a red woven upholstered cushion, molded high-resilience polyurethane foam, and a load-bearing seat shell. The seat cushion uses 90 mm thick foam, while the backrest includes 70 mm padding and a 240 mm lumbar support zone. The clear width between armrests is 540 mm. Soft gray polymer pads are fixed to the molded arm supports, and the black steel tilt and height mechanism is located beneath the seat. A polished aluminum base supports five black twin-wheel swivel casters. Designed for everyday desk use, the chair swivels and provides pneumatic seat-height adjustment through a 100 mm stroke, controlled by a visible side lever. Its synchro-style tilt allows a 15-degree back recline with proportional seat movement, and a rear tension control lets the user adjust tilt resistance. The backrest requires a 120 mm travel envelope behind the frame. The casters support mobility across hard floors or low-pile carpet, with no visible wheel locks. The recommended user weight capacity is 136 kg, and the chair net weight is 15.5 kg. This model is suited to open-plan desks, private workstations, conference seating, and residential workspaces where breathable back support and easy movement are priorities. Procurement teams should select hard-floor casters for tile and wood floors, or substitute soft-tread casters for sensitive flooring. Because the armrests are fixed, seating layouts should accommodate their set width. The product is supplied as one set in two cartons, with a packaged gross weight of 23 kg per set and a reference assembly time of 40 minutes. Delivery and receiving planning should allow for the export carton dimensions and multi-carton packaging.

Mid-Back Mesh Swivel Task Chair with Red Seat Specifications
