PRODUCT MODULE 01 / 06

Physical Dimensions

Automatic mm / inch conversion · Core engineering specifications

Data source: Structured from factory data; final measured values prevail.

Overall dimensions (W × D × H)	630 × 640 × 1040 mm
Overall chair dimensions	630 x 640 x 1040 mm
Finished Seat Cushion Thickness	90 mm
Backrest Padding Thickness	70 mm
Lumbar Support Zone Height	240 mm
Clear Width Between Armrests	540 mm

PRODUCT MODULE 02 / 06

Weight, Load & Performance

Net weight / load capacity / users / durability

Data source: Product performance data; verify exact test conditions before procurement.

Recommended user weight capacity	120 kg
Net weight reference	12.5 kg
Static seat verification load	588 N downward
Backrest cyclic durability target	120,000 cycles
Seat slide-rail durability target	100,000 cycles
Caster rolling durability target	100,000 cycles
Seat foam density	45 kg/m3 molded polyurethane
Back mesh tensile acceptance target	1,200 N warp and 1,000 N weft
Suitable user height range	160 to 185 cm
Warranty target	3 years

PRODUCT MODULE 03 / 06

Materials & Structure

Core acceptance fields · Panels / hardware / frame / upholstery

Data source: Subject to the factory material list and inspection report.

Backrest support	Light gray woven polyester mesh tensioned within a molded polymer frame
Seat cushion	Gray fabric-upholstered padded seat with a 70 mm molded polyurethane foam core
Load-bearing seat shell	Molded polymer seat pan over a steel tilt mechanism plate
Arm and back frame	One-piece light gray molded polymer frame forming fixed loop arms and back side rails
Gas lift	Black 50 mm diameter steel gas-lift cylinder with polymer telescopic cover
Five-star base	Gray molded or coated five-star support base with radial legs

PRODUCT MODULE 04 / 06

Functions & Adjustment

Adjustment / rotation / tilt / mobility / storage features

Data source: Functional configuration; the supplier specification prevails.

Height adjustment	Pneumatic seat-height lift over a 100 mm stroke controlled by the under-seat lever
Recline and lock	Multi-position synchro tilt with a 15-degree back recline and tension adjustment
Mobility	Five-point caster base provides omnidirectional movement and braking-free rolling on office floors
Fixed arm support	Integrated fixed loop arms give forearm support without width, height or pivot adjustment

PRODUCT MODULE 05 / 06

Packaging & Logistics

Verified carton / gross weight / assembly / loading data

Data source: Reference for export quotations and container planning.

20-foot container loading	212 cartons
Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Carton Dimensions	850× 420× 720 mm
Reference Packaged Gross Weight	23 kg/set
Reference Carton Volume	0.26 m³/set

PRODUCT MODULE 06 / 06

Applications & Usage

Recommended spaces / users / usage modes

Data source: Recommended applications based on product form and category.

Open-plan office workstation	Suited to daily computer work at 760 mm desks because it provides swivel access, 100 mm height lift and rolling mobility
Meeting and shared desk areas	Gray fixed-arm mesh design is suitable for hot desks, meeting rooms and administrative seats used by rotating occupants

STANDARD S1

EU Market Entry Requirements * EN Standards

EU Market Access Requirements* EN Standards

Office furniture safety and strength	EN 16139:2013/AC:2013, Level 2, apply strength, durability and stability tests for non-domestic seating
Upholstered furniture flammability	EN 1021:2014 and EN 1021:2014, apply cigarette and match ignition tests to seat and back textile assemblies
Office chair caster testing	EN 12529:1999, apply caster load, rolling and swivel durability requirements for office chairs
Adjustment device safety	EN 1335:2018, apply safety, structural and gas-lift requirements for office work chairs

STANDARD S2

North America Purchasing & Inspection Reference * ANSI/BIFMA Standards

US and Canada office-furniture standards

Office chair safety and durability	ANSI/BIFMA X2017apply back, seat, base, arm, caster and stability tests for general-office use
Low-VOC furniture emissions	ANSI/BIFMA e2019Furniture Sustainability Standard, apply VOC and material-disclosure criteria where specified

STANDARD S3

Standards Applicable to China-Market Projects * GB Standards

Standards applicable to China-market projects

Office chair safety standard	GB/T 28004swivel office chair: apply to stability, strength, durability and hardware acceptance
Formaldehyde emission control	GB 18580apply to wood-based panels or composite components used in the seat assembly

Standardized tender description text

This product must meet the following technical requirements:
1. Office chair safety standard: GB/T 28004swivel office chair: apply to stability, strength, durability and hardware acceptance;
2. Formaldehyde emission control: GB 18580apply to wood-based panels or composite components used in the seat assembly;
Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.

GENERATED EXPORTS

Ready-to-use export tools

Export data is generated from the current published product record.

Technical Report PDF

Directly download an English report in metric or imperial units.

PDF · MBM-GRY-01

Complete Parameter Workbook

Download all product information and parameter modules in English.

XLSX · MBM-GRY-01

International Listing Template

English title, specifications, materials, standards and purchasing fields.

XLSX · LISTING

Customs Declaration Data

Prepare customs description, material, usage, dimensions and declaration elements.

CUSTOMS · MBM-GRY-01Open Export Tool

Quick Actions

Post an RFQ

Product Description

The Mid-Back Mesh Swivel Office Chair with Fixed Arms, model MBM-GRY-01, is a practical gray task chair designed for everyday desk use in both commercial and residential settings. Its coordinated light gray frame, mesh back, gray upholstered seat, and black gas lift create a clean, understated appearance that integrates well with neutral office interiors. The chair uses a five-star support base with radial legs and twin-wheel casters, while the one-piece molded frame forms continuous loop armrests and back side rails. The fixed arms define a structured seating area and offer stable forearm support without width, height, or pivot adjustment. Overall dimensions are 630 by 640 by 1040 millimeters, with 540 millimeters of clear width between the armrests. The mid-height back includes a 240-millimeter lumbar support zone, helping maintain a conventional task-chair profile suited to standard workstations. Construction balances comfort, support, and manageable weight. The backrest uses light gray woven polyester mesh tensioned within a molded polymer frame, allowing the back to remain visually open during seated use. The padded seat is upholstered in gray fabric and features a molded polyurethane foam core, with finished seat cushion thickness of 90 millimeters and foam density specified at 45 kilograms per cubic meter. Beneath the cushion, a molded polymer seat pan sits over a steel tilt mechanism plate. A black 50-millimeter-diameter steel gas-lift cylinder with a polymer telescopic cover connects the seat to the gray molded or coated five-star base. The product has a recommended user weight capacity of 120 kilograms and a net weight reference of 12.5 kilograms. Functionality is centered on flexible desk movement and basic ergonomic adjustment. An under-seat lever operates the pneumatic seat-height lift, which provides a 100-millimeter stroke for adapting to different desk and user requirements. The multi-position synchro tilt offers a 15-degree back recline, a lock function, and tension adjustment. Swivel access and the five-point caster layout support omnidirectional movement and braking-free rolling on office floors, making the chair easy to reposition during computer work, collaboration, or shared-desk use. This model is well suited to open-plan office workstations, particularly daily computer tasks at 760-millimeter desks. Its neutral gray fixed-arm mesh design also fits hot desks, meeting rooms, administrative areas, and shared workspaces used by rotating occupants. For home offices, study rooms, or residential work areas, it offers a commercial task-chair format without a bold visual statement. Buyers should plan for assembly and logistics: each set is supplied in two cartons, with a reference assembly time of 40 minutes, packaged gross weight of 23 kilograms, and carton volume of 0.26 cubic meter per set. A 20-foot container loading reference is 212 cartons. Procurement decisions should also account for the fixed arm design, mesh back, fabric seat, swivel base, caster mobility, and the stated tilt and height-adjustment features, ensuring the chair matches the intended desk type, flooring, user mix, and shared-workplace requirements.
