PRODUCT MODULE 01 / 06

Physical Dimensions

Automatic mm / inch conversion · Core engineering specifications

Data source: Structured from factory data; final measured values prevail.

Overall dimensions (W × D × H)	630 × 620 × 1030 mm
Finished Seat Cushion Thickness	90 mm
Backrest Padding Thickness	70 mm
Lumbar Support Zone Height	240 mm
Clear Width Between Armrests	540 mm

PRODUCT MODULE 02 / 06

Weight, Load & Performance

Net weight / load capacity / users / durability

Data source: Product performance data; verify exact test conditions before procurement.

Recommended user weight capacity	120 kg
Net weight	13.5 kg
Seat foam density	38 kg/m3
Back mesh abrasion rating	30,000 cycles
Seat fabric abrasion rating	50,000 Martindale cycles
Caster rolling durability	100,000 cycles
Gas lift cycle life	100,000 height-adjustment cycles
Seat impact durability	100,000 cycles
Base static load	1,136 kg vertically for 1 hour
Warranty	3 years

PRODUCT MODULE 03 / 06

Materials & Structure

Core acceptance fields · Panels / hardware / frame / upholstery

Data source: Subject to the factory material list and inspection report.

Backrest support	Black flexible mesh set in a rigid polymer outer frame
Seat upholstery	Black woven fabric over a contoured foam cushion
Seat cushion	Molded polyurethane foam, 70 mm thick, 38 kg/m3 density target
Lumbar zone	Black padded lumbar contour integrated behind the mesh lower back area
Armrests	Injection-molded polymer T-shaped supports with flat polymer arm caps
Center support	Chrome-finish steel gas lift with black polymer telescopic sleeve and 50 mm outer tube

PRODUCT MODULE 04 / 06

Functions & Adjustment

Adjustment / rotation / tilt / mobility / storage features

Data source: Functional configuration; the supplier specification prevails.

Height adjustment	Pneumatic seat-height lift through a 100 mm stroke, operated by the visible under-seat lever
Backrest recline	Synchro-style tilt with 19-degree recline travel and visible tension-adjustment knob
Tilt lock	Multi-position lock control through the under-seat paddle, with upright-task and reclined working positions
Swivel movement	360-degree seat and back rotation around the central gas-lift swivel bearing

PRODUCT MODULE 05 / 06

Packaging & Logistics

Verified carton / gross weight / assembly / loading data

Data source: Reference for export quotations and container planning.

Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Carton Dimensions	850× 420× 720 mm
Reference Packaged Gross Weight	23 kg/set
Reference Carton Volume	0.26 m³/set
Indicative 20GP Loading	135 sets at 85% space utilization

PRODUCT MODULE 06 / 06

Applications & Usage

Recommended spaces / users / usage modes

Data source: Recommended applications based on product form and category.

Open-plan workstations	Suits daily individual desk work where a compact 630 mm-wide chair fits standard 1,200 mm workstations
Meeting and study areas	Appropriate for conference rooms, home offices and temporary task seating requiring basic tilt and height adjustment

STANDARD S1

EU Market Entry Requirements * EN Standards

EU Market Access Requirements* EN Standards

No standards data is available for this market.

STANDARD S2

North America Purchasing & Inspection Reference * ANSI/BIFMA Standards

US and Canada office-furniture standards

North America procurement and testing reference	Recommended references: ANSI/BIFMA X5.1

STANDARD S3

Standards Applicable to China-Market Projects * GB Standards

Standards applicable to China-market projects

No standards data is available for this market.

Standardized tender description text

This product must meet the following technical requirements:
1. Technical standards and test reports must be supplied during tender or purchase confirmation;
Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.

GENERATED EXPORTS

Ready-to-use export tools

Export data is generated from the current published product record.

Technical Report PDF

Directly download an English report in metric or imperial units.

PDF · OFC-MESH-FA-BLK-01

Complete Parameter Workbook

Download all product information and parameter modules in English.

XLSX · OFC-MESH-FA-BLK-01

International Listing Template

English title, specifications, materials, standards and purchasing fields.

XLSX · LISTING

Customs Declaration Data

Prepare customs description, material, usage, dimensions and declaration elements.

CUSTOMS · OFC-MESH-FA-BLK-01Open Export Tool

Quick Actions

Post an RFQ

Product Description

The Black Mesh Swivel Task Chair with Fixed Armrests is an unbranded office chair designed for practical daily desk use. Its clean black appearance combines a flexible mesh back, a contoured fabric seat, fixed polymer armrests, and a five-star caster base, giving it a familiar task-chair profile suited to neutral commercial interiors and home workspaces. Overall dimensions are 630 by 620 by 1030 mm, with a clear width of 540 mm between the armrests. The backrest uses black flexible mesh held in a rigid polymer outer frame. A padded lumbar contour is integrated behind the lower-back mesh area, and the lumbar support zone is 240 mm high. The backrest padding thickness is listed as 70 mm. The seat is upholstered in black woven fabric over molded polyurethane foam, with a finished cushion thickness of 90 mm and a foam density target of 38 kg per cubic meter. Fixed T-shaped armrests are made from injection-molded polymer with flat arm caps, providing a consistent support layout without adjustable arms. A chrome-finish steel gas lift forms the center support, finished with a black polymer telescopic sleeve and a 50 mm outer tube. The chair rests on a nylon five-star base fitted with twin-wheel casters, while the seat and back rotate 360 degrees around the central swivel bearing. Pneumatic height adjustment is controlled by an under-seat lever through a 100 mm stroke. A synchro-style tilt mechanism provides 19 degrees of backrest recline, a visible tension-adjustment knob allows the tilt feel to be modified, and a multi-position tilt lock is operated by the under-seat paddle for upright or reclined working positions. Rated for a recommended user weight capacity of 120 kg, the chair has a net weight of 13.5 kg. Material and component ratings include a back mesh abrasion rating of 30,000 cycles, seat fabric abrasion rating of 50,000 Martindale cycles, caster rolling durability of 100,000 cycles, and gas lift cycle life of 100,000 height-adjustment cycles. This model is appropriate for open-plan individual workstations, including standard 1,200 mm workstation layouts where a 630 mm-wide task chair is required. It also suits conference rooms, study areas, home offices, and temporary task seating that needs basic swivel, height, and recline functions. For procurement planning, each set is supplied in two cartons, with packaged gross weight of 23 kg and carton volume of 0.26 cubic meter per set. The reference assembly time is 40 minutes per set, and the indicative 20GP loading figure is 135 sets at 85 percent space utilization. Buyers should also account for floor surface compatibility, fixed armrest dimensions, assembly resources, and the chair’s black-only finish when coordinating with existing desks, meeting tables, or residential furniture.

Black Mesh Swivel Task Chair with Fixed Armrests Specifications
