PRODUCT MODULE 01 / 06

Physical Dimensions

Automatic mm / inch conversion · Core engineering specifications

Data source: Structured from factory data; final measured values prevail.

Overall dimensions (W × D × H)	700 × 650 × 1360 mm
Finished Seat Cushion Thickness	90 mm
Backrest Padding Thickness	70 mm
Lumbar Support Zone Height	240 mm
Clear Width Between Armrests	540 mm

PRODUCT MODULE 02 / 06

Weight, Load & Performance

Net weight / load capacity / users / durability

Data source: Product performance data; verify exact test conditions before procurement.

Recommended user weight capacity	150 kg
Chair net weight	19 kg
Seat foam density	45 kg/m3
Back mesh tensile rating reference	350 N/50 mm
Fabric abrasion resistance target	50000 Martindale cycles
Gas-lift dynamic rating	Class 4, 150 kg
Caster rolling durability target	100000 cycles
Base static-load reference	1136 kg
Recommended daily usage	10 hours
Seat Foam Density / Rebound Reference	45 kg/m³ / 65%

PRODUCT MODULE 03 / 06

Materials & Structure

Core acceptance fields · Panels / hardware / frame / upholstery

Data source: Subject to the factory material list and inspection report.

Backrest support surface	Black flexible woven mesh tensioned in a polymer outer frame
Seat upholstery	Black woven fabric over molded foam on a load-bearing seat shell
Back frame and arm supports	Black molded polymer or glass-fiber-reinforced nylon frame with fixed upright arm supports
Five-star base	Polished die-cast aluminum five-star base with five outward legs
Casters	Black twin-wheel swivel casters with hard tread and metal mounting stems
Gas lift and center column	Chrome-plated steel gas cylinder with black upper collar

PRODUCT MODULE 04 / 06

Functions & Adjustment

Adjustment / rotation / tilt / mobility / storage features

Data source: Functional configuration; the supplier specification prevails.

Seat-height adjustment	Pneumatic lever adjusts seat height from 440 mm to 500 mm with a 60 mm stroke
Recline mechanism	Synchronized tilt mechanism with a 15-degree rear recline and tension control for users up to 150 kg
Lumbar and head support	Rigid rear lumbar support and padded curved headrest provide separate lower-back and neck contact
Recline Angle / Lock Reference	125° with 3suggested lock positions

PRODUCT MODULE 05 / 06

Packaging & Logistics

Verified carton / gross weight / assembly / loading data

Data source: Reference for export quotations and container planning.

Carton dimensions	850 x 660 x 360 mm
Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Carton Dimensions	850× 420× 720 mm
Reference Packaged Gross Weight	23 kg/set
Reference Carton Volume	0.26 m³/set

PRODUCT MODULE 06 / 06

Applications & Usage

Recommended spaces / users / usage modes

Data source: Recommended applications based on product form and category.

Recommended Matching Desk Size	2.4 m executive desk
Reference Daily Use Duration	8 hours/day; confirm by ergonomic testing

STANDARD S1

EU Market Entry Requirements * EN Standards

EU Market Access Requirements* EN Standards

No standards data is available for this market.

STANDARD S2

North America Purchasing & Inspection Reference * ANSI/BIFMA Standards

US and Canada office-furniture standards

North America procurement and testing reference	Recommended references: ANSI/BIFMA X5.1

STANDARD S3

Standards Applicable to China-Market Projects * GB Standards

Standards applicable to China-market projects

No standards data is available for this market.

Standardized tender description text

This product must meet the following technical requirements:
1. Technical standards and test reports must be supplied during tender or purchase confirmation;
Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.

GENERATED EXPORTS

Ready-to-use export tools

Export data is generated from the current published product record.

Technical Report PDF

Directly download an English report in metric or imperial units.

PDF · EM-HB-MESH-01

Complete Parameter Workbook

Download all product information and parameter modules in English.

XLSX · EM-HB-MESH-01

International Listing Template

English title, specifications, materials, standards and purchasing fields.

XLSX · LISTING

Customs Declaration Data

Prepare customs description, material, usage, dimensions and declaration elements.

CUSTOMS · EM-HB-MESH-01Open Export Tool

Quick Actions

Post an RFQ

Product Description

The High-Back Mesh Ergonomic Office Chair with Headrest and Lumbar Support presents a professional, streamlined seating solution in a coordinated black finish with a polished aluminum base. Its high-back form combines a flexible woven mesh backrest tensioned within a black polymer outer frame, an upholstered foam seat, fixed upright armrests, and a padded curved headrest. The five-star base and twin-wheel casters give the chair a familiar executive silhouette while supporting a smooth, mobile office layout. The clear width between armrests is 540 mm, with a 90 mm finished seat cushion and 70 mm backrest padding. The defined lumbar support zone is 240 mm high, reinforcing the chair’s focus on structured lower-back contact. Construction balances breathable support with durable components. The back uses black flexible woven mesh, while the seat is finished in black woven fabric over molded foam set on a load-bearing shell; the seat foam density is 45 kg/m3. The frame and arm supports are made from black molded polymer or glass-fiber-reinforced nylon. The polished die-cast aluminum five-star base uses five outward legs, paired with black twin-wheel swivel casters featuring hard treads and metal mounting stems. A chrome-plated steel gas cylinder with a black upper collar connects the seat to the base. The chair has a net weight of 19 kg and a recommended user weight capacity of 150 kg, matched by a Class 4 gas-lift dynamic rating of 150 kg. Material reference values include a back mesh tensile rating of 350 N/50 mm, a fabric abrasion resistance target of 50,000 Martindale cycles, and a caster rolling durability target of 100,000 cycles. Functional features suit extended desk-based work. A pneumatic lever provides seat-height adjustment from 440 mm to 500 mm through a 60 mm stroke. The synchronized tilt mechanism offers a 15-degree rear recline with tension control, while the recline angle reference is 125 degrees with three suggested lock positions. The rigid rear lumbar support and padded curved headrest separately address lower-back and neck contact, and the swivel base enables easy movement within a workstation. The reference daily use duration is 8 hours per day, subject to confirmation by ergonomic testing. This unbranded model, EM-HB-MESH-01, is appropriate for private offices, open workstations, meeting spaces, home studies, and executive seating paired with a 2.4 m desk. Procurement teams should plan for two cartons per set, a packaged gross weight of 23 kg, 0.26 cubic meters of package volume, and a reference assembly time of 40 minutes per chair.

High-Back Mesh Ergonomic Office Chair with Headrest and Lumbar Support Specifications
