Product supplierLockable Two-Section Office Display Storage Cabinet, 1.0mm thick cold-rolled steel, silver powder-coated finish
Contact the supplier for production scheduling and quotation.
PRODUCT MODULE 01 / 06
Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 900 × 400 × 2000 mm | |
|---|---|---|
| upper display section height | 1340 mm | |
| lower concealed storage section height | 660 mm | |
| upper glass door height | 1280 mm | |
| lower solid door height | 600 mm | |
| internal upper shelf spacing | 320 mm | |
| internal upper shelf depth | 370 mm | |
| lower compartment internal height | 580 mm | |
| door pull handle length | 120 mm | |
| top trim thickness | 20 mm | |
| base plinth height | 60 mm | |
| door frame profile width | 40 mm | |
| Carcass Panel Thickness | 25 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
PRODUCT MODULE 02 / 06
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| total static load capacity | 225 kg | |
|---|---|---|
| glass door impact resistance grade | Tempered safety glass, 5x stronger than annealed glass | |
| metal frame corrosion resistance | 500 hours salt spray resistance | |
| shelf adjustability positions | 5 positions per shelf | |
| product net weight | 55 kg | |
| anti-tip securement rating | Supports 200kg tip resistance per fitting | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles | |
| Anti-tip Fixing Reference | Products above 1200 mm should use at least 2 wall fixing points |
PRODUCT MODULE 03 / 06
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| main structural frame | 1.0mm thick cold-rolled steel, silver powder-coated finish | |
|---|---|---|
| upper door panels | 5mm thick clear tempered safety glass | |
| lower door panels | 18mm thick E1 grade particleboard, walnut wood-grain melamine finish | |
| internal horizontal shelves | 18mm thick E1 grade particleboard, melamine surface, metal shelf supports | |
| cabinet back panel | 3mm thick hardboard, matte grey finish | |
| door hardware pulls | Zinc alloy, matte black vertical bar pulls, polished end caps | |
| lower compartment lock | Zinc alloy cam lock with 2 included keys | |
| door hinges | Cold-rolled steel concealed hinges, nickel-plated finish | |
| top trim cap | 20mm thick dark brown engineered wood, matching edge banding | |
| base plinth | 0.8mm thick light grey powder-coated steel, raised levelling feet | |
| edge banding | 1.0mm thick PVC edge banding, matched to door and top finishes | |
| surface coating on metal parts | Epoxy polyester powder coat, scratch-resistant, anti-rust |
PRODUCT MODULE 04 / 06
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| upper glass door access | Double hinged doors swing open 110 degrees to reveal display storage | |
|---|---|---|
| lower door locking | Central cam lock secures both lower doors with keyed access | |
| upper shelf adjustment | Shelf supports clip into pre-punched frame holes to reposition shelves | |
| display visibility | Clear glass doors allow unobstructed viewing of stored items without opening doors | |
| lower concealed storage | Solid wood-grain doors hide stored documents and supplies from view | |
| hinge cycle durability | Hinges tested to 80000 open/close cycles without failure | |
| levelling adjustment | Base feet adjust 10mm to compensate for uneven floor surfaces | |
| wall anti-tip attachment | Included anti-tip bracket secures cabinet to wall to prevent forward tipping | |
| Cable / Vent Opening Reference | If fitted, 80 mm diameter |
PRODUCT MODULE 05 / 06
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
PRODUCT MODULE 06 / 06
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| private office workspace | Provides display and locked filing storage adjacent to executive desks | |
|---|---|---|
| open office filing zones | Organizes public reference materials on upper shelves and secured files below | |
| reception and waiting areas | Displays corporate materials and brochures behind glass with locked supply storage | |
| school and library admin areas | Stores reference books, documents and secured administrative supplies | |
| hospitality back-of-house areas | Holds office supplies and documents in hotel or retail back offices | |
| recommended placement | Positioned flat against load-bearing walls with anti-tip bracket installed | |
| finish compatibility | Walnut wood grain and silver frame coordinates with dark wood office desk collections |
STANDARD S1
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 14073-2:2004 | Office storage furniture, safety requirements for tall storage units | |
|---|---|---|
| EN 14074:2004 | Office furniture, test methods for storage units strength and durability | |
| EN 12150-1:2015 | Thermally toughened soda lime silicate safety glass for door panels |
STANDARD S2
North America Purchasing & Inspection Reference * ANSI/BIFMA Standards
US and Canada office-furniture standards
| ANSI/BIFMA X5.9-2019 | Storage furniture performance standard for commercial office use |
|---|
STANDARD S3
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to engineered wood components | |
|---|---|---|
| GB/T 13668-2015 | Steel filing cabinets for office use, applicable to steel frame and structural parts | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, applicable to board components | |
| GB/T 4897.3-2003 | Particleboard for furniture use, applicable to shelves and door panels |
Standardized tender description text
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to engineered wood components; 2. GB/T 13668-2015: Steel filing cabinets for office use, applicable to steel frame and structural parts; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels, applicable to board components; 4. GB/T 4897.3-2003: Particleboard for furniture use, applicable to shelves and door panels; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
