Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions | 2000 x 400 x 2000 mm | |
|---|---|---|
| Tall left closed door width | 600 mm | |
| Small lower left closed door dimensions | 400 x 500 mm | |
| Total open shelf tiers | 5 tiers | |
| Shelf thickness | 25 mm | |
| Carcass panel thickness | 18 mm | |
| Back panel thickness | 9 mm | |
| Edge band thickness | 1 mm | |
| Gold trim width | 10 mm | |
| Large wide open cubby dimensions (upper right) | 1000 x 300 mm | |
| Bottom open book storage cubby height | 300 mm | |
| Clearance between fixed shelves | 320 mm | |
| Door / Drawer Front Thickness | 22 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Single open shelf static load capacity | 23 kg | |
|---|---|---|
| Door hinge open angle | 110 degrees | |
| Hinge cycle rating | 80000 cycles | |
| Unit net weight | 95 kg | |
| Anti-tip connector requirement | 2 pieces | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles | |
| Anti-tip Fixing Reference | Products above 1200 mm should use at least 2 wall fixing points | |
| Recommended Procurement Warranty | Carcass 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Carcass construction | 18mm E1 grade engineered wood with matte black laminate finish | |
|---|---|---|
| Closed door panels | Engineered wood with dark vertical wood-grain veneer finish | |
| Frame accent trim | Gold-toned plated steel alloy, 10mm width along outer perimeter | |
| Shelf panels | 25mm engineered wood with matching matte black laminate finish | |
| Door hardware | Concealed soft-close metal hinges with black finish | |
| Back panel | 9mm hardboard with black matte finish, fixed to carcass with staples |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Storage layout | Asymmetric mixed storage with two solid closed doors on left, varied open cubbies on center/right | |
|---|---|---|
| Door operation | Left-side solid doors swing open via concealed hinges to access enclosed hidden storage | |
| Shelf configuration | Fixed non-adjustable shelves form varied cubby sizes for books and display items | |
| Stability feature | Wall-mounted anti-tip anchors prevent forward tipping during loaded use |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Executive office backdrop | Placed behind an executive desk for document storage and curated display | |
|---|---|---|
| Open plan office storage | Used in collaborative work zones for shared reference material and decor display |
EU Market Access Requirements* EN Standards
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.9 |
|---|
Standards applicable to China-market projects
This product must meet the following technical requirements: 1. Technical standards and test reports must be supplied during tender or purchase confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
