Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1850 x 900 x 400 mm | |
|---|---|---|
| Upper glass door section height | 1050 mm | |
| Lower solid door section height | 800 mm | |
| Glass door width (per double unit) | 300 mm | |
| Upper solid single door width | 300 mm | |
| Lower solid double door width | 600 mm | |
| Lower right solid door width | 300 mm | |
| Internal shelf depth (glass section) | 370 mm | |
| Door handle length | 120 mm | |
| Adjustable shelf spacing | 320 mm | |
| Base plinth height | 50 mm | |
| Carcass Panel Thickness | 25 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
| Per-shelf static load capacity | 25 kg | |
|---|---|---|
| Door hinge open angle | 110 degrees | |
| Hinge cycle durability | 80000 cycles | |
| Door lock (if fitted) cycle durability | 20000 cycles | |
| Surface scratch resistance | 2000 cycles | |
| Product net weight | 62 kg | |
| Warranty period | 5 years | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Cabinet carcass panels | 15mm E1-grade particleboard with walnut melamine veneer | |
|---|---|---|
| Back panel | 5mm hardboard with matching wood-grain finish | |
| Upper door frames | 1.0mm brushed silver aluminum alloy | |
| Upper door panels | 5mm clear tempered safety glass | |
| Lower/solid upper door panels | 15mm melamine-faced particleboard matching carcass finish | |
| Edge banding | 1mm PVC edge banding matching walnut finish | |
| Door handles | Black powder-coated zinc alloy pull handles | |
| Hinges | Cold-rolled steel concealed self-closing hinges | |
| Internal shelves | 15mm melamine-faced particleboard, adjustable on metal support pins | |
| Leveler feet | Nylon base feet with adjustable height | |
| Edge Band Thickness | 2 mm | |
| Primary Connector Specification | Reference M6-M8 cam/bolt fittings with at least 2 fixing points at major joints |
Adjustment / rotation / tilt / mobility / storage features
| Upper glass-door storage | Three-tier adjustable shelf storage for visible document/supply access | |
|---|---|---|
| Upper solid-door storage | Concealed two-tier storage for less frequently accessed items | |
| Lower double-door storage | Two-tier large concealed compartment for bulk office supplies | |
| Lower right single-door storage | Single-tier narrow concealed compartment for small item sorting | |
| Shelf adjustability | Shelves repositionable at 32mm increments via metal support pins | |
| Door opening | All doors open outward via concealed hinges, no sliding mechanisms | |
| Wall anti-tip | Includes two wall anchor straps to prevent forward tipping | |
| Lock readiness | Pre-drilled for optional keyed cylinder locks on all doors | |
| Cable / Vent Opening Reference | If fitted, 80 mm diameter |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
| Open-plan office zones | Placed against partition walls for shared document and supply storage | |
|---|---|---|
| Private executive offices | Positioned behind desks for mixed display of reference materials and concealed storage | |
| Conference room perimeters | Used to store meeting supplies, presentation materials and archived documents | |
| Administrative work areas | Supplies high-capacity sorted storage for office forms, stationery and records | |
| Reception back-of-house areas | Stores visitor materials, office consumables and spare equipment | |
| Education staff rooms | Provides secure organized storage for teaching materials and administrative documents |
EU Market Access Requirements* EN Standards
| EN 14073-2:2004 | Applicable standard for office storage furniture safety requirements | |
|---|---|---|
| EN 14074:2004 | Applicable standard for office furniture storage unit test methods | |
| EN 12521:2015 | Applicable standard for furniture strength, durability and safety |
US and Canada office-furniture standards
| ANSI/BIFMA X5.9-2019 | Applicable standard for office storage units |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | Applicable standard for general technical requirements of wooden furniture | |
|---|---|---|
| GB 18580-2017 | Applicable standard for formaldehyde emission limits for wood-based panels | |
| GB/T 4897.3-2003 | Applicable standard for particleboard used in furniture construction |
This product must meet the following technical requirements: 1. GB/T 3324-2017: Applicable standard for general technical requirements of wooden furniture; 2. GB 18580-2017: Applicable standard for formaldehyde emission limits for wood-based panels; 3. GB/T 4897.3-2003: Applicable standard for particleboard used in furniture construction; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
