| Time | Field | Original Value | Corrected Value | Note / Status |
|---|---|---|---|---|
No correction records yet. Found an error? Click the flag at the end of a row to report it. | ||||
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions | 800 x 400 x 2000 mm | |
|---|---|---|
| Carcass Panel Thickness | 25 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Per-shelf static load capacity | 30 kg | |
|---|---|---|
| Net product weight | 62 kg | |
| Door open angle | 110 degrees | |
| Storage volume | 0.56 m³ | |
| Anti-tip anchor load rating | 50 kg | |
| Recommended shelf load even distribution | 70% | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles | |
| Anti-tip Fixing Reference | Products above 1200 mm should use at least 2 wall fixing points |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Cabinet carcase and panels | 18mm E1 grade melamine-faced particleboard, light oak woodgrain finish | |
|---|---|---|
| Upper door panels | 5mm clear tempered safety glass, framed in matching melamine board | |
| Lower door panels | 18mm matching melamine-faced particleboard, solid woodgrain finish | |
| Edge trim and plinth | 2mm thick PVC edge banding, matte white finish | |
| Door hinges | 110 degree cold-rolled steel concealed hinges, zinc-plated finish | |
| Locking mechanism | Zinc alloy cam lock with 2 keys, keyed alike for lower doors |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Dual-zone storage | Upper transparent display zone for decorative/visible items, lower locked enclosed zone for private storage | |
|---|---|---|
| Adjustable shelving | Upper shelves adjust in 32mm increments to accommodate varying item heights | |
| Central locking | Single key lock secures both lower doors for controlled access to stored documents and supplies | |
| Wall-mounted anti-tip | Included anchor bracket secures cabinet to wall to prevent forward tipping when doors are open |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Office document display | Suitable for manager offices and reception areas to display awards, reference materials and decorative items | |
|---|---|---|
| General office storage | Used in open offices and administrative areas to store files, supplies and personal items with locked lower access |
EU Market Access Requirements* EN Standards
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.9 Storage Units |
|---|
Standards applicable to China-market projects
This product must meet the following technical requirements: 1. Technical standards and test reports must be supplied during tender or purchase confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
