Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall assembled dimensions | 900 x 470 x 2140 mm | |
|---|---|---|
| Upper glass door section height | 1140 mm | |
| Lower solid door section height | 900 mm | |
| Plinth base height | 100 mm | |
| Single glass door width | 260 mm | |
| Glass door frame width | 20 mm | |
| Upper section internal shelf count | 3 | |
| Adjustable shelf pitch range | 320 mm | |
| Lower door single panel width | 440 mm | |
| Carcass panel thickness | 18 mm | |
| Top panel thickness | 25 mm | |
| Door opening angle | 110 degrees | |
| Back panel thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Assembled product weight | 100 kg | |
|---|---|---|
| Per-shelf static load capacity | 23 kg | |
| Lower cabinet total static load | 120 kg | |
| Hinge cycle durability | 80000 open/close cycles | |
| Lock service life | 20000 lock/unlock cycles | |
| Supported user weight on top surface | 50 kg | |
| Warranty period | 10 years | |
| Internal shelf load bearing width | 860 mm | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Carcass panels | 18mm prelaminated particle board with dark wood grain veneer | |
|---|---|---|
| Upper door panels | 5mm tempered smoked glass with light silver metal framing | |
| Lower door panels | 18mm wood-grain engineered wood with matching dark finish | |
| Hardware | Zinc alloy lock, silver metal handles, Euro-style concealed hinges | |
| Internal shelves | 18mm matching wood-grain engineered board, adjustable on metal pins | |
| Edge banding | 2mm PVC matching wood grain edge trim on all exposed panels |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Lockable lower storage | Keyed cam lock centered on lower doors, supplied with 2 keys | |
|---|---|---|
| Adjustable shelving | Upper shelves repositionable on 32mm system holes for flexible storage | |
| Door operation | Dual hinged doors for upper and lower sections, 110-degree swing for full access | |
| Anti-tip protection | Wall anchor bracket included to secure cabinet to wall studs |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Office private workspace | Positioned behind executive desks for file storage and decor display | |
|---|---|---|
| Open office breakout areas | Used to store reference materials and display curated office items |
EU Market Access Requirements* EN Standards
| EN 14749:2016 | Safety and strength requirements for domestic and office storage furniture | |
|---|---|---|
| EN 14073-2:2004 | Office storage furniture, safety requirements for storage units | |
| EN 12150-1:2015 | Thermally toughened soda lime silicate safety glass for door panels |
US and Canada office-furniture standards
| ANSI/BIFMA X5.9-2019 | Storage furniture performance and durability standard for office use | |
|---|---|---|
| ANSI/BIFMA e3-2019 | Furniture sustainability standard for material emissions and social responsibility |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for panel and structural quality | |
|---|---|---|
| GB/T 4897.3-2003 | Particle board for furniture use, applicable for core panel performance | |
| GB 28007-2011 | Safety requirements for children's and adult furniture, anti-tip provisions applicable |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for panel and structural quality; 2. GB/T 4897.3-2003: Particle board for furniture use, applicable for core panel performance; 3. GB 28007-2011: Safety requirements for children's and adult furniture, anti-tip provisions applicable; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
