Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions | 800 x 350 x 2000 mm | |
|---|---|---|
| Closed cabinet section width | 530 mm | |
| Open shelf section width | 270 mm | |
| Plinth base height | 80 mm | |
| Open shelf tier count | 4 tiers | |
| Individual open shelf internal height | 440 mm | |
| Open shelf internal depth | 320 mm | |
| Closed door height | 1900 mm | |
| Door thickness | 18 mm | |
| Main carcass panel thickness | 18 mm | |
| Back panel thickness | 5 mm | |
| Edge band thickness | 1 mm | |
| Carcass Panel Thickness | 25 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Individual shelf static load capacity | 37 kg | |
|---|---|---|
| Total product net weight | 83 kg | |
| Hinge cycle rating | 80000 open/close cycles | |
| Drawer slide load rating (if fitted) | 25 kg | |
| Anti-tip hardware load rating | 100 kg pull force | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles | |
| Anti-tip Fixing Reference | Products above 1200 mm should use at least 2 wall fixing points | |
| Recommended Procurement Warranty | Carcass 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Carcass panels | 18mm particleboard core with light oak melamine finish | |
|---|---|---|
| Closed cabinet door | 18mm MDF core with vertical textured oak veneer | |
| Back panel | 5mm hardboard with matching light finish | |
| Shelf surfaces | 18mm engineered wood with scratch-resistant melamine coating | |
| Hardware components | Zinc-plated steel hinges, wall anchors and mounting screws | |
| Lighting system | Low-voltage LED strip lights mounted under each open shelf |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Door operation | Full-height solid door opens 110 degrees via concealed soft-close hinges | |
|---|---|---|
| LED lighting function | Integrated LED strips provide warm white accent lighting for open display shelves | |
| Anti-tip safety | Wall anchor hardware secures unit to wall studs to prevent forward tip-over | |
| Storage configuration | Left section provides concealed closed storage, right section provides open display storage |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Residential living room use | Ideal for book storage and curated decor display alongside media consoles or seating | |
|---|---|---|
| Home office use | Suitable for document storage, reference book organization and display of workspace accessories |
EU Market Access Requirements* EN Standards
| EN 312:2010 | Particleboard performance requirements for furniture structural applications | |
|---|---|---|
| EN 14749:2016 | Safety and strength requirements for domestic storage furniture and kitchen units | |
| EN 62471:2008 | Photobiological safety for integrated LED lighting components | |
| EN 15187:2006 | Surface finish resistance to cold liquid spills for furniture maintenance |
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.9 Storage Units |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to structural safety and finish quality | |
|---|---|---|
| GB/T 4897.3-2003 | Particleboard for furniture use, applicable to core panel structural performance | |
| GB 7000.204-2008 | Safety requirements for built-in LED lighting fixtures in household furniture | |
| GB/T 10357.5-2011 | Furniture mechanical test for storage unit shelf and cabinet strength |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to structural safety and finish quality; 2. GB/T 4897.3-2003: Particleboard for furniture use, applicable to core panel structural performance; 3. GB 7000.204-2008: Safety requirements for built-in LED lighting fixtures in household furniture; 4. GB/T 10357.5-2011: Furniture mechanical test for storage unit shelf and cabinet strength; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
