Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1200 x 400 x 900 mm | |
|---|---|---|
| Side panel thickness | 18 mm | |
| Horizontal shelf thickness | 18 mm | |
| Vertical divider thickness | 18 mm | |
| Drawer front panel thickness | 18 mm | |
| Single open compartment internal width | 564 mm | |
| Single open compartment internal depth | 364 mm | |
| Top and bottom tier compartment internal height | 230 mm | |
| Middle drawer tier internal height | 180 mm | |
| Drawer internal usable depth | 340 mm | |
| Recessed top ledge height | 50 mm | |
| Base plinth height | 20 mm | |
| Carcass Panel Thickness | 25 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
| Unit net weight | 52 kg | |
|---|---|---|
| Uniformly distributed shelf load capacity | 25 kg per shelf | |
| Total storage volume | 0.28 m³ | |
| Recommended maximum number of stored A4 binders | 24 | |
| Surface abrasion resistance | 2000 cycles | |
| Product warranty | 3 years | |
| Drawer slide operational durability | 50000 cycles | |
| Product structural warranty | 3 years | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Cabinet side panels | 18mm P2 grade particleboard with light oak wood-grain melamine finish, sealed edges with 0.6mm PVC edge banding | |
|---|---|---|
| Inner shelf and divider panels | 18mm light grey melamine-faced particleboard with matching PVC edge banding | |
| Drawer front panels | 18mm particleboard with matte soft orange powder-coated or melamine finish, matching light beige edge banding | |
| Drawer box sides and base | 12mm light grey melamine particleboard with 3mm hardboard drawer base | |
| Drawer slides | 3-section full-extension cold-rolled steel slides with zinc plating, 35mm width | |
| Back panel | 5mm hardboard with light grey finish, fixed into rabbeted grooves on side panels | |
| Top recessed ledge trim | 1mm thick PVC edge banding in matching light beige finish, fixed around top perimeter | |
| Adjustable foot pads | 10mm diameter nylon adjustable feet with M6 threaded bolt, height adjustment range 10mm | |
| Fasteners and connectors | Zinc-plated steel cam-lock connectors, confirmat screws and wood dowels for knock-down assembly | |
| Drawer box components | 12mm light grey melamine particleboard drawer sides, 5mm hardboard drawer base fixed into side grooves | |
| Leveling feet | 4 units of 10mm diameter nylon adjustable feet with M6 threaded steel bolt, 10mm vertical adjustment range | |
| Assembly hardware | Zinc-plated steel cam-lock connectors, confirmat screws and hardwood dowels for knock-down assembly |
Adjustment / rotation / tilt / mobility / storage features
| Open compartment storage | 6 fixed open compartments arranged in 3 horizontal tiers and 2 vertical columns, no doors for quick access to frequently used files and supplies | |
|---|---|---|
| Middle drawer operation | 2 equal-width drawers operate via push-to-open mechanism without exposed handles, fully extend on steel slides to access full internal storage space | |
| Top ledge anti-slip function | Recessed 50mm high raised edge along top perimeter prevents small items, plants or decor from sliding off the top surface | |
| Floor leveling adjustment | 4 adjustable nylon feet at bottom corners allow 10mm height adjustment to level the cabinet on uneven carpet or hard flooring | |
| Knock-down flat-pack assembly | Cabinet ships disassembled with cam-lock connectors, requiring only a hex key and screwdriver for on-site assembly without specialized tools | |
| Drawer slide extension range | Drawers extend 340mm outward from cabinet front, allowing full access to rear of drawer without leaning over cabinet top | |
| Surface stain resistance | Melamine finish on all exposed surfaces resists common office liquid spills including coffee, water and ink, allowing wipe cleaning without surface damage | |
| Modular alignment capability | Flat side panels allow multiple identical cabinets to be ganged side-by-side for continuous storage runs, with pre-drilled connecting screw holes for securing units together | |
| Open storage configuration | 6 fixed open compartments arranged in 2 upper tiers and 1 lower tier split by 2 vertical columns, no doors for unobstructed quick access to frequently used files and supplies | |
| Drawer operation | 2 equal-width drawers operate via push-to-open latching mechanism with no exposed handles, fully extend on steel slides to provide access to full internal drawer space | |
| Top surface anti-slip feature | Recessed 50mm high raised edge around entire top perimeter prevents small items, desk plants or decor from sliding off the top surface when bumped | |
| Floor leveling function | 4 adjustable nylon feet at each bottom corner provide 10mm of vertical height adjustment to level the cabinet on uneven carpet, tile or hard wood flooring |
Verified carton / gross weight / assembly / loading data
| Number of shipping packages | 1 | |
|---|---|---|
| Shipping carton dimensions | 1280 x 460 x 120 mm | |
| Gross shipping weight | 58 kg | |
| Shipping volume per unit | 0.07 CBM | |
| On-site assembly time | 40 minutes | |
| 20ft GP container loading quantity | 210 units | |
| 40ft HQ container loading quantity | 530 units | |
| Internal packaging materials | 25mm thick EPS foam corner protectors, 0.1mm thick PE plastic wrap for panels, separate sealed hardware bag with assembly instruction manual | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set |
Recommended spaces / users / usage modes
| Open plan office side storage | Suitable for placement alongside 1200mm or 1400mm office desks to store frequently accessed files, stationery and personal items for adjacent workstations, with open compartments allowing quick access without door operation | |
|---|---|---|
| Team breakout area storage | Suitable for placement in office breakout or collaboration zones to store magazines, activity supplies, refreshment accessories and shared equipment, with soft orange accent finish complementing casual workspace design | |
| Home office multi-use storage | Suitable for home office environments as a low storage cabinet beside a desk, with shallow depth that does not protrude into narrow walkways, and drawer storage for small personal items | |
| Reception area display storage | Suitable for placement behind reception desks to store visitor supplies, brochures and reception equipment, with open top shelf for displaying decor or company branding materials | |
| Classroom or training room storage | Suitable for training rooms and educational spaces to store training materials, stationery and student supplies, with durable melamine finish resisting frequent daily use | |
| Small printer stand use | Suitable for use as a compact printer stand with top surface holding desktop printers up to 40kg, and open lower compartments storing paper, toner and printing supplies | |
| Recommended matching furniture | Pairs with 1600 mm width office desks in light oak and white finish, ergonomic office chairs with matching warm orange accent upholstery for a coordinated workspace aesthetic | |
| Training room supply storage | Suitable for training rooms and educational spaces to store training materials, stationery and student supplies, with durable melamine finish resisting scuffs and stains from high-traffic daily use |
EU Market Access Requirements* EN Standards
| EN 14073-2:2004 Office furniture - Storage furniture - Part 2: Safety requirements | Applicable for verifying structural stability, sharp edge protection, drawer and shelf safety for office use | |
|---|---|---|
| EN 14073-3:2004 Office furniture - Storage furniture - Part 3: Test methods for stability and structure strength | Applicable standards and test results require confirmation | |
| EN 312:2010 Particleboards - Specifications | Applicable standards and test results require confirmation |
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.9 Storage Units |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 General technical requirements for wooden furniture | Applicable for evaluating cabinet dimensional tolerance, panel edge quality, structural stability and assembly requirements for wooden office storage | |
|---|---|---|
| GB 18580-2017 Indoor decorating and refurbishing materials - Limit of formaldehyde emission from wood-based panels | Applicable for formaldehyde emission limit verification, requiring E1 or P2 grade panel emission ≤0.124mg/m³ for indoor office use | |
| GB/T 4897.3-2015 Particleboard - Part 3: Requirements for furniture grade particleboard | Applicable standards and test results require confirmation | |
| GB/T 10357.5-2011 Test of mechanical properties of furniture - Strength and durability of storage units | Applicable for static load, impact and durability testing of shelves, drawers and cabinet structure to ensure long-term use performance |
This product must meet the following technical requirements: 1. GB/T 3324-2017 General technical requirements for wooden furniture: Applicable for evaluating cabinet dimensional tolerance, panel edge quality, structural stability and assembly requirements for wooden office storage; 2. GB 18580-2017 Indoor decorating and refurbishing materials - Limit of formaldehyde emission from wood-based panels: Applicable for formaldehyde emission limit verification, requiring E1 or P2 grade panel emission ≤0.124mg/m³ for indoor office use; 3. GB/T 4897.3-2015 Particleboard - Part 3: Requirements for furniture grade particleboard: Applicable standards and test results require confirmation; 4. GB/T 10357.5-2011 Test of mechanical properties of furniture - Strength and durability of storage units: Applicable for static load, impact and durability testing of shelves, drawers and cabinet structure to ensure long-term use performance; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
