Modern Two-Tone Matte Grey Handleless Sideboard Cabinet with LED-Lit Central Open Shelf (model SB-GR-WA-LED-1800) is listed under Panel-type Filing Cabinet, with overall dimensions of 1800 × 410 × 750 mm and main material of Particle‑board (PB). Load capacity: 68 kg. Certifications: contemporary,styling,handleless,push-to-open,doors,LED,display,niche,freestanding,elevated,base. This page consolidates 6 groups of specifications and GB / EN / ANSI/BIFMA standard references, with metric and imperial units. 1 supplier(s) are listed and you can request a quote online.
| Time | Field | Original Value | Corrected Value | Note / Status |
|---|---|---|---|---|
No correction records yet. Found an error? Click the flag at the end of a row to report it. | ||||
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| overall dimensions | 1800 x 410 x 750 mm | |
|---|---|---|
| central open niche width | 800 mm | |
| central open niche height | 440 mm | |
| central open niche depth | 380 mm | |
| upper open shelf usable height | 220 mm | |
| lower open shelf usable height | 220 mm | |
| outer door width | 450 mm | |
| central lower door width | 400 mm | |
| door panel thickness | 18 mm | |
| top/bottom edge trim thickness | 20 mm | |
| support foot height | 30 mm | |
| internal cabinet shelf depth | 370 mm | |
| open niche shelf thickness | 18 mm | |
| corner radius of vertical edges | 50 mm | |
| Carcass Panel Thickness | 25 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| top surface static load capacity | 68 kg | |
|---|---|---|
| door hinge open angle | 110 degrees | |
| hinge cycle durability | 80000 cycles | |
| push latch cycle durability | 50000 cycles | |
| net product weight | 85 kg | |
| LED strip service life | 30000 hours | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles | |
| Anti-tip Fixing Reference | Products above 1200 mm should use at least 2 wall fixing points |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| main carcass and doors | 18mm matte grey lacquered MDF | |
|---|---|---|
| trim and open niche back panel | Walnut-toned wood veneer | |
| edge banding | 1mm PVC edge band on all internal cut edges | |
| support feet | Reinforced black nylon block feet with non-slip pads | |
| door hardware | Soft-close concealed hinges with push-to-open touch latches | |
| display lighting | Warm white 3000K recessed LED strip lights |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| door operation | Push-to-open handleless mechanism for all four doors | |
|---|---|---|
| door closing action | Soft-close hydraulic dampers prevent slamming on all doors | |
| internal storage | Adjustable shelf in each closed door compartment | |
| display lighting | Integrated warm white LED strips illuminate each open shelf tier |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| living room storage | Placed against a wall for media accessories, book and decorative item display | |
|---|---|---|
| office lounge / breakout area | Used for storage of servingware, documents and display items in common areas |
EU Market Access Requirements* EN Standards
| EN 14749:2016 | Safety and performance requirements for domestic storage furniture and kitchen worktops | |
|---|---|---|
| EN 12521:2015 | Strength, durability and safety requirements for domestic seating and storage furniture |
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.9 Storage Units |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for panel constructionAcceptance | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limit for engineered wood panels, E1 grade required for indoor use |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for panel constructionAcceptance; 2. GB 18580-2017: Formaldehyde emission limit for engineered wood panels, E1 grade required for indoor use; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
