Automatic mm / inch conversion · Core engineering specifications
| overall dimensions | 3980 x 430 x 2200 mm | |
|---|---|---|
| left sliding door section width | 1200 mm | |
| right open display section width | 2780 mm | |
| open shelf tier count | 5 tiers | |
| open shelf per-tier column count | 3 columns | |
| single open compartment inner dimensions | 890 x 380 x 350 mm | |
| middle closed cabinet row count | 2 rows | |
| middle closed small cabinet door count | 8 doors | |
| sliding door panel thickness | 18 mm | |
| shelf panel thickness | 25 mm | |
| back panel thickness | 9 mm | |
| base plinth height | 60 mm | |
| edge banding thickness | 2 mm | |
| Carcass Panel Thickness | 25 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
| unit net weight | 260 kg | |
|---|---|---|
| single open shelf static load capacity | 40 kg | |
| sliding door hardware cycle rating | 50000 open/close cycles | |
| LED strip service life | 50000 hours | |
| recommended maximum loaded total weight | 650 kg | |
| standard product warranty | 5 years | |
| available color option count | 3 | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| main carcass panels | 18mm melamine-faced MDF, light wood grain finish | |
|---|---|---|
| sliding door panels | 18mm MDF with matte light grey lacquer finish | |
| middle closed cabinet doors | 18mm MDF with matching matte light grey finish | |
| shelf surfaces | 25mm melamine-faced particleboard, scratch-resistant surface | |
| edge banding | 2mm PVC edge banding on all exposed panel edges | |
| back panel | 9mm melamine hardboard, fixed to carcass with staples | |
| sliding door track | Powder-coated aluminum alloy track with nylon glides | |
| integrated lighting | Recessed 24V warm white LED strips, frosted polycarbonate diffuser | |
| door hinges for middle cabinets | Soft-close cold-rolled steel hinges | |
| base plinth | 18mm matching light wood grain melamine panel | |
| anti-tip hardware | 2mm thick steel wall anchor brackets, included with installation | |
| Edge Band Thickness | 2 mm |
Adjustment / rotation / tilt / mobility / storage features
| left section access | Two-panel horizontal sliding door system, track-mounted for full compartment access | |
|---|---|---|
| sliding door operation | Smooth gliding nylon rollers on aluminum track, no protruding handles | |
| middle cabinet door operation | Push-to-open soft-close mechanism, 110-degree door opening angle | |
| open shelf illumination | Recessed warm white LED strips under each shelf front, low-voltage 24V power supply | |
| LED light control | Touch-sensitive dimmer switch mounted on inner cabinet side, 3 brightness levels | |
| shelf configuration | Fixed shelf positions for aligned grid layout, no adjustable shelf holes visible | |
| storage compartment layout | 15 open display compartments plus 8 enclosed closed cabinets plus full sliding door storage section | |
| cable management | Concealed rear cable channel for LED power wiring, exit point at unit base | |
| anti-tip safety | Two steel wall anchors secure unit to wall structure, preventing forward tipping | |
| Cable / Vent Opening Reference | If fitted, 80 mm diameter |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
| executive office background | Installed behind executive desk for document storage and award display | |
|---|---|---|
| open office filing zone | Used as centralized document and supply storage in shared work areas | |
| reception area display | Placed in reception lobbies to display company credentials, brochures and decor | |
| conference room storage | Installed along conference room walls for meeting materials and equipment storage | |
| target user profile | Corporate offices, co-working spaces, professional service firms requiring commercial-grade storage | |
| recommended clearance | Maintain 1000mm clear walkway in front of unit for unobstructed door and shelf access |
EU Market Access Requirements* EN Standards
| EN 14749:2016 | Safety and strength requirements for domestic and office storage furniture | |
|---|---|---|
| EN 12521:2015 | Strength, durability and stability requirements for commercial office furniture |
US and Canada office-furniture standards
| ANSI/BIFMA X5.9-2019 | Storage furniture performance standard for office use, covering load and stability | |
|---|---|---|
| ANSI/BIFMA e3-2019 | Furniture sustainability standard for material emissions and recycled content |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for panel construction and finish quality | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, required E1/ENF grade for indoor office use | |
| GB/T 4897.3-2015 | Particleboard specifications for furniture use, applicable for shelf and carcass panels | |
| GB 7000.204-2008 | Safety requirements for built-in LED lighting fixtures used in furniture |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for panel construction and finish quality; 2. GB 18580-2017: Formaldehyde emission limits for wood-based panels, required E1/ENF grade for indoor office use; 3. GB/T 4897.3-2015: Particleboard specifications for furniture use, applicable for shelf and carcass panels; 4. GB 7000.204-2008: Safety requirements for built-in LED lighting fixtures used in furniture; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
