PRODUCT MODULE 01 / 06
Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 900 × 400 × 2000 mm | |
|---|---|---|
| overall unit dimensions | 900 x 400 x 2000 mm | |
| upper glass door section height | 1300 mm | |
| lower solid door section height | 600 mm | |
| plinth foot height | 100 mm | |
| adjustable shelf count (upper section) | 6 | |
| lower compartment internal shelf count | 1 | |
| individual glass panel size | 280 x 380 mm | |
| door panel thickness | 18 mm | |
| back panel thickness | 5 mm | |
| side panel thickness | 18 mm | |
| shelf panel thickness | 18 mm | |
| edge band thickness | 1 mm | |
| lower compartment internal clearance height | 560 mm | |
| Carcass Panel Thickness | 25 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
PRODUCT MODULE 02 / 06
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| unit net weight | 90 kg | |
|---|---|---|
| per shelf static load capacity | 25 kg | |
| tempered glass door impact resistance | 10 J | |
| hinge open/close cycle rating | 80000 cycles | |
| recommended maximum loaded unit weight | 250 kg | |
| anti-tip anchor load rating | 50 kg | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles | |
| Anti-tip Fixing Reference | Products above 1200 mm should use at least 2 wall fixing points |
PRODUCT MODULE 03 / 06
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| main carcass frame | E1 grade engineered wood with walnut wood veneer | |
|---|---|---|
| upper door frame | Solid walnut wood with rounded soft edge profile | |
| upper door panels | 5 mm thick clear tempered safety glass | |
| lower door panels | Fluted vertical-grain solid walnut wood | |
| internal shelves | 18 mm thick walnut-veneer engineered wood | |
| plinth base and feet | Solid walnut wood, short tapered profile with open toe kick | |
| back panel | 5 mm thick hardboard with walnut finish | |
| door hinges | Matte black plated steel adjustable concealed hinges | |
| surface finish | Matte scratch-resistant polyurethane clear coat | |
| edge banding | 1 mm thick solid wood edge tape matching veneer color | |
| Edge Band Thickness | 2 mm | |
| Primary Connector Specification | Reference M6-M8 cam/bolt fittings with at least 2 fixing points at major joints |
PRODUCT MODULE 04 / 06
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| upper glass door operation | Double side-hinged doors with 110° opening, adjustable hinges | |
|---|---|---|
| lower solid door operation | Double side-hinged doors with soft-close mechanism | |
| upper shelf adjustability | 6 adjustable shelves with 50 mm increment positions | |
| dust protection | Sealed door gaskets on all doors to prevent dust entry on stored items | |
| modular alignment | Pre-drilled side holes for ganging multiple matching cabinets side-by-side | |
| wall anti-tip anchoring | Included steel anti-tip bracket kit for wall mounting | |
| display visibility | Clear grid glass panels allow full visibility of books and decor without opening doors | |
| concealed storage | Lower solid doors hide stored files and items away from direct view | |
| Cable / Vent Opening Reference | If fitted, 80 mm diameter |
PRODUCT MODULE 05 / 06
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
PRODUCT MODULE 06 / 06
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| home study space | Fits as standalone book storage and display for personal study rooms | |
|---|---|---|
| executive office space | Serves as background storage cabinet for files and decor in manager offices | |
| living room display | Placed against living room walls for book and decorative object display | |
| library/reading room | Modularly ganged in rows for high-capacity book storage in public reading areas | |
| recommended matching furniture | Pair with matching executive desk and wood frame office chair for cohesive workspace look |
STANDARD S1
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 14749:2016 | Safety and performance requirements for domestic storage furniture, applicable for structural safety | |
|---|---|---|
| EN 12521:2015 | Strength and durability requirements for home storage furniture, applicable for load testing | |
| EN 12150-1:2015 | Thermally toughened soda lime silicate safety glass for door panels, applicable for glass safety |
STANDARD S2
North America Purchasing & Inspection Reference * ANSI/BIFMA Standards
US and Canada office-furniture standards
| ANSI/BIFMA X5.9-2019 | Storage furniture performance standard for office use, applicable for commercial installation |
|---|
STANDARD S3
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for structural performance verification | |
|---|---|---|
| GB/T 4893.4-2013 | Surface wear resistance test for furniture finishes, applicable for durability acceptance | |
| GB 18584-2001 | Formaldehyde emission limit for interior wooden furniture, applicable for material safety | |
| GB/T 28202-2011 | Hardware for furniture hinge performance requirements, applicable for hardware acceptance |
Standardized tender description text
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for structural performance verification; 2. GB/T 4893.4-2013: Surface wear resistance test for furniture finishes, applicable for durability acceptance; 3. GB 18584-2001: Formaldehyde emission limit for interior wooden furniture, applicable for material safety; 4. GB/T 28202-2011: Hardware for furniture hinge performance requirements, applicable for hardware acceptance; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
