Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions | 3200 x 400 x 2000 mm | |
|---|---|---|
| Carcass Panel Thickness | 25 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Single open shelf static load capacity | 30 kg | |
|---|---|---|
| Product net weight | 185 kg | |
| LED strip operational lifespan | 30000 hours | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles | |
| Anti-tip Fixing Reference | Products above 1200 mm should use at least 2 wall fixing points | |
| Recommended Procurement Warranty | Carcass 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Frame and open shelf panels | E1 grade particleboard with matte dark gray thermofoil finish | |
|---|---|---|
| Closed door panels | MDF core with light vertical wood-grain melamine finish | |
| Structural backing panels | 8mm thick hardboard with dark matte finish | |
| Integrated accent lighting | 24V LED strip lights recessed under upper shelf fronts | |
| Door hardware | Soft-close concealed hinges with 110 degree opening angle | |
| Base plinth | 25mm thick particleboard with matching dark gray finish |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Storage layout | Mixed open display shelves and 5 closed storage compartments | |
|---|---|---|
| Accent lighting | Recessed LED strips illuminate each open display shelf | |
| Door operation | Hinged doors open outward to access enclosed storage space | |
| Floor installation | Freestanding floor-standing design with optional anti-tip wall anchor |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Executive office back wall | Provides display and document storage behind executive workstations | |
|---|---|---|
| Corporate reception area | Displays decorative items and company materials in public-facing zones |
EU Market Access Requirements* EN Standards
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.9 Storage Units |
|---|
Standards applicable to China-market projects
This product must meet the following technical requirements: 1. Technical standards and test reports must be supplied during tender or purchase confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
