Automatic mm / inch conversion · Core engineering specifications
| overall dimensions | 2400 x 400 x 2000 mm | |
|---|---|---|
| open shelf compartment height | 350 mm | |
| open shelf compartment depth | 350 mm | |
| central solid door width | 800 mm | |
| frosted glass door section width | 400 mm | |
| shelf panel thickness | 25 mm | |
| carcass side panel thickness | 18 mm | |
| frosted glass panel thickness | 5 mm | |
| back panel thickness | 9 mm | |
| edge band thickness | 1 mm | |
| central warm brown accent strip width | 120 mm | |
| clearance under unit base | 20 mm | |
| Carcass Panel Thickness | 25 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
| maximum static load per shelf | 30 kg | |
|---|---|---|
| maximum static load for glass-enclosed shelves | 20 kg | |
| total cabinet maximum static load | 300 kg | |
| LED strip operating lifespan | 30000 hours | |
| door hinge cycle rating | 80000 open/close cycles | |
| anti-tip connector static load rating | 50 kg per connector | |
| surface abrasion resistance | 2000 cycles | |
| unit net weight | 80 kg | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| cabinet carcass panels | E1 grade engineered particle board, dark espresso woodgrain melamine finish | |
|---|---|---|
| central door panel | E1 grade MDF, dark woodgrain finish with vertical warm brown accent strip | |
| right section door | 5mm frosted tempered glass with thin dark metal frame | |
| shelf panels | 25mm thick engineered wood, matching dark woodgrain melamine finish | |
| back panels | 9mm thick engineered wood, dark matte finish backing all compartments | |
| door hinges | Cold-rolled steel soft-close concealed hinges, matte black finish | |
| integrated lighting | Warm white 3000K recessed LED strips mounted under upper shelf edges | |
| edge banding | 1mm thick matching dark PVC edging on all exposed panel edges | |
| leveling feet | Nylon adjustable leveling feet at base corners | |
| Edge Band Thickness | 2 mm | |
| Primary Connector Specification | Reference M6-M8 cam/bolt fittings with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| open shelf display storage | Four left and four right open compartments for books, awards, and decorative objects | |
|---|---|---|
| concealed solid door storage | Central full-height solid door encloses hidden storage for office supplies and files | |
| frosted glass door storage | Right full-height frosted glass door encloses semi-visible display storage to reduce dust | |
| integrated LED display lighting | Recessed warm LED strips illuminate each open shelf to highlight displayed items | |
| adjustable shelf positions | Shelves include 32mm spaced mounting holes for height adjustment to fit tall objects | |
| soft-close door operation | Concealed hinges enable slow, quiet door closing without slamming | |
| wall anti-tip anchoring | Two anti-tip metal connectors secure cabinet top to wall to prevent forward tipping | |
| leveling adjustment | Base leveling feet adjust 10mm to compensate for uneven office flooring | |
| Cable / Vent Opening Reference | If fitted, 80 mm diameter |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
| executive office backdrop | Placed behind executive desk for book, award, and decorative display in management offices | |
|---|---|---|
| open office reception area | Used as a backdrop storage unit in reception zones to display company credentials and decor | |
| private study and home office | Installed in home studies for book storage and curated decor display with ambient LED lighting | |
| conference room perimeter storage | Positioned along conference room walls to store reference materials and display corporate artifacts | |
| library display zone | Used in office library areas to feature curated collections with illuminated open shelving |
EU Market Access Requirements* EN Standards
| EN 14749:2016 | Safety requirements for domestic and kitchen storage units and worktops | |
|---|---|---|
| EN 312:2010 | Particle board specification for furniture structural use | |
| EN 62471:2008 | Photobiological safety of LED lighting products, applicable for integrated strips |
US and Canada office-furniture standards
| ANSI/BIFMA X5.9-2019 | Storage furniture performance standard for office use, applicable for shelf load testing |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for cabinet structural performance | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, applicable for E1 grade panel compliance | |
| GB/T 4897.3-2003 | Particle board specification for furniture use, applicable for carcass panel quality |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for cabinet structural performance; 2. GB 18580-2017: Formaldehyde emission limits for wood-based panels, applicable for E1 grade panel compliance; 3. GB/T 4897.3-2003: Particle board specification for furniture use, applicable for carcass panel quality; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
