Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| overall dimensions | 900 x 450 x 2050 mm | |
|---|---|---|
| upper glass section height | 1370 mm | |
| lower solid door section height | 680 mm | |
| individual door width | 450 mm | |
| upper glass panel size | 380 x 1120 mm | |
| adjustable shelf spacing (upper section) | 320 mm | |
| lower storage compartment internal height | 620 mm | |
| plinth base height | 60 mm | |
| middle division trim thickness | 20 mm | |
| door frame thickness | 35 mm | |
| carcass panel thickness | 18 mm | |
| back panel thickness | 5 mm | |
| internal shelf thickness | 18 mm | |
| edge banding thickness | 2 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| unit net weight | 70 kg | |
|---|---|---|
| single shelf static load capacity | 30 kg | |
| hinge open/close cycle rating | 10000 cycles | |
| lock mechanism key differs | 200 unique combinations | |
| structural warranty | 10 years | |
| finish abrasion resistance | 2000 cycles | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles | |
| Anti-tip Fixing Reference | Products above 1200 mm should use at least 2 wall fixing points |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| cabinet carcass | 18mm prelaminated particle board with dark wood-grain laminate | |
|---|---|---|
| upper door panels | 5mm clear tempered glass set in matching wood-grain frames | |
| lower door panels | 18mm engineered wood with matching dark wood-grain laminate finish | |
| hardware components | Powder-coated black metal hinges, lock cylinder, and handles | |
| trim and plinth | Black PVC laminated engineered wood for middle division and base | |
| back panel | 5mm hardboard with dark matching finish |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| upper door operation | Dual hinged glass doors swing open 110 degrees for display access | |
|---|---|---|
| lower door operation | Dual hinged solid doors lock via central key cylinder for secure storage | |
| shelf adjustability | 3 upper shelves adjust on 32mm pin holes for flexible storage heights | |
| anti-tip safety | 2 wall anchor straps included to secure unit to wall surfaces |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| executive office application | Suitable for executive offices to store reference books and confidential files | |
|---|---|---|
| open office storage application | Ideal for open office shared zones to organize documents and office supplies |
EU Market Access Requirements* EN Standards
| EN 14073-2:2004 | Office storage furniture safety requirements for commercial use | |
|---|---|---|
| EN 14073-3:2004 | Office storage furniture stability and structural strength requirements | |
| EN 312:2010 | Particle board specifications for furniture and general use |
US and Canada office-furniture standards
| ANSI/BIFMA X5.9-2019 | Storage furniture performance and durability standard for office environments | |
|---|---|---|
| ANSI/BIFMA X5.1-2017 | General office furniture safety and structural performance requirements |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for structural safety | |
|---|---|---|
| GB/T 4897.3-2003 | Particle board for furniture use, applicable for carcass material quality | |
| GB 18584-2001 | Indoor decoration material limit of harmful substances for wooden furniture |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for structural safety; 2. GB/T 4897.3-2003: Particle board for furniture use, applicable for carcass material quality; 3. GB 18584-2001: Indoor decoration material limit of harmful substances for wooden furniture; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
