Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1800 x 350 x 1600 mm | |
|---|---|---|
| Sliding door section width | 600 mm | |
| Open storage section width | 1200 mm | |
| Top tier open cubby internal dimensions | 400 x 320 x 280 mm | |
| Second tier drawer panel dimensions | 600 x 320 x 250 mm | |
| Middle tier internal dividers | 20 mm thick | |
| Fourth tier drawer panel dimensions | 600 x 320 x 250 mm | |
| Bottom tier open cubby internal dimensions | 400 x 320 x 320 mm | |
| Board panel thickness | 18 mm | |
| Edge banding thickness | 1 mm | |
| Adjustable shelf clearance range | 32 mm | |
| Carcass Panel Thickness | 25 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
| Unit net weight range | 85 kg | |
|---|---|---|
| Shelf uniform static load capacity | 30 kg per shelf tier | |
| Total unit storage capacity | 240 L | |
| Recommended maximum total load | 180 kg | |
| Edge wear resistance cycles | 2000 rubs | |
| Recommended service life | 8 years | |
| Recommended maximum total distributed load | 180 kg | |
| Drawer slide operational cycle rating | 50000 cycles | |
| Sliding door track operational cycle rating | 40000 cycles | |
| Wall anti-tip anchorage load rating | 50 kg per anchor |
Core acceptance fields · Panels / hardware / frame / upholstery
| Carcass panels | 18mm E1 grade melamine-faced particleboard, white matte finish | |
|---|---|---|
| Sliding door panel | 18mm MDF with vertical ribbed light beige finish, terracotta colored edge trim | |
| Fixed drawer fronts | 18mm melamine-faced particleboard, light beige matte finish | |
| Internal divider panels | 18mm melamine-faced particleboard, terracotta matte finish | |
| Fixed shelves | 18mm melamine-faced particleboard, white matte finish | |
| Sliding door track | 1.2mm thick powder-coated aluminum, silver matte finish | |
| Drawer slides | 3-section full extension cold rolled steel slides, zinc plated | |
| Back panel | 5mm thick hardboard with white melamine finish, fixed to carcass rear rabbet | |
| Adjustable foot pads | Nylon base with M8 steel threaded stem, 10mm adjustment height | |
| Anti-tip hardware kit | 2 steel wall anchors with zinc-plated steel connecting straps, 200mm strap length | |
| Door edge trim | 1mm thick PVC edge band in terracotta finish, hot-melt glued to sliding door vertical edge | |
| Cabinet base frame | 18mm melamine-faced particleboard, white matte finish, reinforced with 30mm x 30mm solid wood corner blocks at joint locations |
Adjustment / rotation / tilt / mobility / storage features
| Left section sliding door access | Single ribbed panel sliding door travels along horizontal track to reveal full-height enclosed storage, with 100% opening access when door is slid to rearmost track position | |
|---|---|---|
| Concealed drawer storage | Two fixed-front pull-out drawers located on second and fourth tiers, each spanning two standard cubby widths, extending 300mm on full-extension slides to provide enclosed storage for private documents and small items | |
| Modular open cubby storage | 13 separate open compartments of varying widths across 5 horizontal tiers, configured for sorted storage of binders, books, display items and office supplies without door access | |
| Sectional shelf organization | Two terracotta vertical dividers on the middle tier create varied compartment widths to accommodate oversized documents, decorative objects and irregularly sized items alongside standard file storage | |
| Floor leveling adjustment | Four threaded nylon foot pads at cabinet base corners allow 10mm vertical adjustment to stabilize the unit on uneven office flooring without rocking | |
| Wall anchoring compatibility | Pre-drilled holes on rear top rail for anti-tip wall anchor installation, required for units over 1200mm height to prevent tipping during use | |
| Mixed storage zoning | Layout separates enclosed private storage, concealed drawer storage and open display storage across a single wall-mounted footprint to reduce need for separate storage units in compact office spaces | |
| Wall anchoring security | 2 pre-drilled holes on rear top rail for anti-tip wall anchor installation, with included steel straps securing cabinet to wall studs, required for units over 1200mm height to prevent tipping when drawers or doors are fully extended | |
| Fixed shelf configuration | All horizontal shelves are permanently fixed to carcass side panels and dividers with mechanical cam-lock fasteners, providing higher structural rigidity than adjustable shelves with no sagging at rated shelf load | |
| Cable / Vent Opening Reference | If fitted, 80 mm diameter |
Verified carton / gross weight / assembly / loading data
| Number of shipping packages | 2 | |
|---|---|---|
| Shipping carton dimensions | 1850 x 400 x 180 mm (main panel carton), 650 x 400 x 120 mm (hardware and small parts carton) | |
| Total shipping gross weight | 95 kg | |
| Total shipping volume (CBM) | 0.165 CBM | |
| Assembly time (two person crew) | 60 minutes | |
| 20ft GP container loading quantity | 162 units | |
| 40ft HQ container loading quantity | 396 units | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split |
Recommended spaces / users / usage modes
| Open plan office partition storage | Positioned against office partition walls or break area walls to provide shared document storage, team supply organization and display space for team awards and reference materials | |
|---|---|---|
| Private executive office side storage | Placed alongside executive desks to store working documents, personal items and reference books, with closed sliding door section concealing private materials and open sections displaying decorative items | |
| Small meeting room document storage | Installed along meeting room walls to store meeting materials, presentation supplies and archived documents, with divided open cubbies allowing quick access to frequently used materials | |
| Library and co-working space resource storage | Used in co-working areas or small office libraries to sort shared books, office supplies and equipment for easy user access, with varied compartment sizes accommodating different item dimensions | |
| Home office multi-function storage | Deployed in home workspaces to store office documents, books, decor items and personal effects, with neutral two-tone color scheme matching modern residential interiors | |
| Reception area display storage | Placed behind office reception desks to store visitor registration materials, company brochures and display decorative corporate items, with open cubbies providing visible display space and closed sections concealing administrative supplies |
EU Market Access Requirements* EN Standards
| EN 14073-2:2004 Office furniture - Storage furniture - Part 2: Safety requirements | European standard for safety requirements including stability, strength and component safety for office storage units, applicable for export market compliance verification | |
|---|---|---|
| EN 312:2010 Particleboards - Specifications | Applicable material standard for particleboard panel performance including density, internal bond and moisture resistance for cabinet carcass components | |
| EN 12720:2009 Furniture - Assessment of surface resistance to cold liquids | Applicable surface performance standard for melamine finish resistance to common office liquid spills including coffee, water and cleaning agents | |
| EN 15372:2008 Furniture - Strength, durability and safety - Requirements for non-domestic storage furniture | Applicable durability and safety standard for commercial office storage units used in high-frequency public and workplace environments |
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.9 Storage Units |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 General technical requirements for wooden furniture | Applicable standard for dimensional tolerance, panel edge treatment and structural stability of wooden office storage cabinets, recommended as acceptance baseline for delivered units | |
|---|---|---|
| GB 18580-2017 Indoor decorating and refurbishing materials - Limit of formaldehyde emission from wood-based panels | Mandatory Chinese standard for formaldehyde emission from wood panels, require E1 grade (≤0.124mg/m³) emission compliance for all carcass and panel components | |
| GB/T 10357.5-2011 Test of mechanical properties of furniture - Strength and durability of storage units | Applicable standard for shelf load, drawer operation and structural stability testing for office storage cabinets | |
| GB/T 4893.8-2013 Test of surface coatings of furniture - Part 8: Determination of abrasion resistance | Applicable standard for verifying melamine surface wear resistance performance for high-traffic office use |
This product must meet the following technical requirements: 1. GB/T 3324-2017 General technical requirements for wooden furniture: Applicable standard for dimensional tolerance, panel edge treatment and structural stability of wooden office storage cabinets, recommended as acceptance baseline for delivered units; 2. GB 18580-2017 Indoor decorating and refurbishing materials - Limit of formaldehyde emission from wood-based panels: Mandatory Chinese standard for formaldehyde emission from wood panels, require E1 grade (≤0.124mg/m³) emission compliance for all carcass and panel components; 3. GB/T 10357.5-2011 Test of mechanical properties of furniture - Strength and durability of storage units: Applicable standard for shelf load, drawer operation and structural stability testing for office storage cabinets; 4. GB/T 4893.8-2013 Test of surface coatings of furniture - Part 8: Determination of abrasion resistance: Applicable standard for verifying melamine surface wear resistance performance for high-traffic office use; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
