Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2700 x 450 x 2400 mm | |
|---|---|---|
| Lower closed storage section height | 900 mm | |
| Central feature display niche dimensions | 1200 x 350 x 800 mm | |
| Central gold-trimmed dark glass door dimensions | 400 x 350 x 1500 mm | |
| Individual open shelf compartment dimensions | 350 x 320 x 300 mm | |
| Left solid vertical panel width | 350 mm | |
| Lower door panel thickness | 18 mm | |
| Open shelf panel thickness | 25 mm | |
| Base plinth height | 80 mm | |
| Edge banding thickness | 2 mm | |
| Carcass Panel Thickness | 25 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
| Total unit net weight | 300 kg | |
|---|---|---|
| Per open shelf static load capacity | 27 kg | |
| Hinge and soft-close mechanism cycle rating | 100000 cycles | |
| Surface stain and scratch resistance rating | Grade 2 for residential use | |
| Integrated LED strip operational lifespan | 50000 hours | |
| Anti-tip wall anchor static load rating | 100 kg | |
| Recommended maximum displayed decor weight per niche | 45 kg | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Outer frame and shelf dividers | 18mm E0-grade engineered wood with light grey matte melamine finish | |
|---|---|---|
| Lower closed door panels | 18mm textured brown wood-grain laminate engineered wood | |
| Central feature niche back panel | 12mm marble-look sintered stone with polished finish | |
| Central accent door frame | 0.8mm thick brushed gold stainless steel trim | |
| Central accent door infill | 5mm dark tinted tempered glass | |
| Open shelf integrated lighting | 12V recessed warm white LED strip lights | |
| Door opening hardware | Push-to-open touch latches with soft-close buffer hinges | |
| Back panel (non-accent sections) | 9mm thick MDF backing board with textured light grey finish | |
| Edge sealing | 2mm thick PUR seamless edge banding | |
| Edge Band Thickness | 2 mm | |
| Primary Connector Specification | Reference M6-M8 cam/bolt fittings with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Lower door operation | Handleless push-to-open activation with soft-close buffering, 110-degree hinge opening | |
|---|---|---|
| Open shelf lighting | Recessed undershelf LED strips with warm 3000K color temperature, integrated on/off control | |
| Shelf adjustability | Open upper shelves support 50mm height adjustment via pre-drilled holes | |
| Anti-tip safety | 2 heavy-duty wall anchor brackets secure top rear frame to structural wall | |
| Closed storage configuration | Lower compartments include 1 adjustable shelf per door section | |
| Central glass door access | Hinged dark glass door opens to reveal concealed narrow display or storage bay | |
| Surface maintenance | Stain-resistant matte finish wipes clean with damp cloth, no special cleaning agents required | |
| Cable management | Rear panel includes pre-cut 50mm cable ports for LED power and small electronics | |
| Cable / Vent Opening Reference | If fitted, 80 mm diameter |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
| Luxury residential living room | Full-wall display for books, art and collectibles, integrated lighting highlights decor | |
|---|---|---|
| High-end executive office | Behind-desk storage for documents and decorative objects, premium aesthetic matches executive interiors | |
| Upscale private study | Mixed open book storage and closed concealed storage for office supplies and personal items | |
| Luxury hotel lobby lounge | Displays curated art and reading materials, complements premium marble interior finishes | |
| High-end residential entryway | Full-wall statement storage for decorative items and concealed entry essentials | |
| Contemporary penthouse dining area | Displays tableware and art objects, matches high-end stone and metal interior palettes |
EU Market Access Requirements* EN Standards
| EN 14749:2016 | Safety and performance requirements for domestic and kitchen storage furniture, anti-tip compliance required | |
|---|---|---|
| EN 16122:2012 | Test methods for strength and durability of storage furniture, 100000 cycle hardware testing referenced | |
| EN 13986:2004+A1:2015 | Wood-based panels for construction, formaldehyde Class E1 emission compliance required |
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.9 Storage Units |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to cabinet dimensional and structural stability checks | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, E0 grade emission ≤0.05mg/m3 required for acceptance | |
| GB/T 4893.8-2013 | Surface abrasion resistance test for furniture finishes, minimum 1000 abrasion cycles required | |
| GB/T 10357.5-2017 | Furniture mechanical performance test for storage units, shelf load and stability validation required |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to cabinet dimensional and structural stability checks; 2. GB 18580-2017: Formaldehyde emission limits for wood-based panels, E0 grade emission ≤0.05mg/m3 required for acceptance; 3. GB/T 4893.8-2013: Surface abrasion resistance test for furniture finishes, minimum 1000 abrasion cycles required; 4. GB/T 10357.5-2017: Furniture mechanical performance test for storage units, shelf load and stability validation required; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
