Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions | 3200 x 400 x 2200 mm | |
|---|---|---|
| Left closed door bay width | 600 mm | |
| Central open display section width | 1800 mm | |
| Right mixed open/closed bay width | 800 mm | |
| Closed lower storage door height | 650 mm | |
| Upper open shelf section height | 1400 mm | |
| Base plinth height | 80 mm | |
| Top trim thickness | 20 mm | |
| Open shelf depth | 350 mm | |
| Closed cabinet internal depth | 370 mm | |
| Adjustable shelf height increments | 32 mm | |
| Vertical gold trim width | 10 mm | |
| Door panel thickness | 18 mm | |
| Back panel thickness | 9 mm | |
| Carcass Panel Thickness | 25 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Single open shelf static load capacity | 25 kg | |
|---|---|---|
| Closed cabinet interior shelf static load | 30 kg | |
| Hinge open/close cycle rating | 50000 cycles | |
| Unit net weight | 210 kg | |
| Surface abrasion resistance | 2000 cycles | |
| Recommended maximum wall-mount anti-tip load | 150 kg | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles | |
| Anti-tip Fixing Reference | Products above 1200 mm should use at least 2 wall fixing points |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Main carcass panels | 18mm E0-grade particleboard with dark embossed wood-grain melamine finish | |
|---|---|---|
| Interior open shelf surfaces | 18mm particleboard with matte black melamine coating | |
| Decorative trim | 10mm wide brushed gold-finish aluminum alloy trim along frame and dividers | |
| Door panels | 18mm dark wood-grain particleboard with 2mm PVC edge banding | |
| Back panel | 9mm hardboard with matte black finish, secured to carcass with staples | |
| Door hardware | Cold-rolled steel soft-close hinges with matte black finish |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Storage configuration | Mixed asymmetrical open display shelves and closed solid-door storage bays | |
|---|---|---|
| Shelf adjustability | 3 horizontal shelves in open sections with 32mm height adjustment increments | |
| Door operation | Concealed soft-close hinges for solid doors, 110-degree opening angle | |
| Anti-tip safety | 2 steel anti-tip wall anchors included for securing unit to finished wall |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Primary application space | Executive/CEO office backdrop wall, placed behind executive desk for book and trophy display | |
|---|---|---|
| Secondary application space | Boardroom perimeter storage for reference materials and decorative displays |
EU Market Access Requirements* EN Standards
| EN 312:2010 | Particleboard performance requirements for load-bearing furniture applications | |
|---|---|---|
| EN 14749:2016 | Safety and strength requirements for domestic and office storage furniture |
US and Canada office-furniture standards
| ANSI/BIFMA X5.9-2019 | Storage furniture performance standard for office use, covering stability and load testing |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to dimensional and structural acceptance | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limit for wood-based panels, E1 level as minimum acceptance threshold | |
| GB/T 4893.8-2013 | Surface abrasion resistance test method for furniture finishes |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to dimensional and structural acceptance; 2. GB 18580-2017: Formaldehyde emission limit for wood-based panels, E1 level as minimum acceptance threshold; 3. GB/T 4893.8-2013: Surface abrasion resistance test method for furniture finishes; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
