Automatic mm / inch conversion · Core engineering specifications
| overall assembled dimensions | 2400 x 470 x 2200 mm | |
|---|---|---|
| left sliding door section width | 600 mm | |
| right main section width | 1800 mm | |
| lower cabinet door height | 800 mm | |
| upper open shelf section height | 1300 mm | |
| individual lower door width | 600 mm | |
| open shelf compartment depth | 420 mm | |
| top open shelf vertical clearance | 380 mm | |
| middle open shelf vertical clearance | 420 mm | |
| lower open shelf vertical clearance | 500 mm | |
| sliding door panel thickness | 18 mm | |
| base plinth height | 100 mm | |
| back panel thickness | 16 mm | |
| Carcass Panel Thickness | 25 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
| unit net weight | 180 kg | |
|---|---|---|
| adjustable shelf static load rating | 30 kg | |
| lower cabinet interior total storage volume | 0.81 cbm | |
| open shelf total display/storage volume | 0.98 cbm | |
| hardware open/close cycle rating | 100000 cycles | |
| recommended maximum uniform load per cabinet | 300 kg | |
| surface stain resistance rating | Grade 4 | |
| applicable user count | 20 employees | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| cabinet carcass panels | 18mm E0-grade melamine-faced chipboard (MFC) | |
|---|---|---|
| inner shelf and frame surfaces | Matte white melamine laminate | |
| door panels | Light oak wood grain melamine veneer | |
| accent strip | Matte sage green laminate panel | |
| back panel | 16mm thick melamine-coated fiberboard | |
| edge banding | 1mm PUR seamless PVC edge sealing | |
| lower door hardware | Push-to-open rebound soft-close hinges | |
| sliding door hardware | Powder-coated aluminum top/bottom track system | |
| shelf support hardware | Zinc-plated steel adjustable shelf pins | |
| base plinth | Powder-coated steel leveler feet | |
| wall anchoring hardware | 2 anti-tip steel wall brackets | |
| Edge Band Thickness | 2 mm |
Adjustment / rotation / tilt / mobility / storage features
| lower cabinet access | Push-to-open handleless doors with 110-degree hinge opening, soft-close damping | |
|---|---|---|
| left section access | Full-height horizontal sliding door conceals tall enclosed storage compartment | |
| open shelf adjustment | 5-position pin-adjustable shelves, 32mm spacing increments for variable item heights | |
| lower cabinet storage | Dual fixed internal shelves per lower door compartment for archival file storage | |
| surface maintenance | Matte stain-resistant finish allows wipe cleaning with damp cloth and mild detergent | |
| level adjustment | Individual adjustable feet at base compensate for ±15mm uneven floor height | |
| anti-tip safety | Wall-mounted anchor brackets prevent forward tipping during loaded access | |
| optional lighting upgrade | Recessed 12V low-voltage LED strip mount points pre-routed under open shelves | |
| Cable / Vent Opening Reference | If fitted, 80 mm diameter |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
| corporate open office zones | Provides shared document and display storage along perimeter walls for team work areas | |
|---|---|---|
| executive private offices | Matches modern light wood office aesthetics for behind-desk storage and display | |
| small business reception areas | Stores office supplies while displaying branded decor in public-facing spaces | |
| co-working facility common areas | Offers mixed open and locked storage for shared member document organization | |
| education administration offices | Holds student files, administrative documents and office supplies in school settings |
EU Market Access Requirements* EN Standards
| EN 14073-2:2004 | Office storage furniture safety requirements, applicable for structural stability and anti-tip verification | |
|---|---|---|
| EN 312:2010 | Particleboard specifications, applicable for wood-based panel performance confirmation | |
| EN 12727:2000 | Office storage furniture strength and durability test methods, applicable for load cycle validation |
US and Canada office-furniture standards
| ANSI/BIFMA X5.9-2019 | Storage cabinets safety and performance standard, applicable for commercial office load testing |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for structural and dimensional tolerance checks | |
|---|---|---|
| GB 18584-2001 | Indoor decorating and refurbishing materials limit of formaldehyde emission, applicable for panel materialAcceptance | |
| GB/T 4897.3-2003 | Particleboard for furniture use, applicable for core panel structural performance verification |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for structural and dimensional tolerance checks; 2. GB 18584-2001: Indoor decorating and refurbishing materials limit of formaldehyde emission, applicable for panel materialAcceptance; 3. GB/T 4897.3-2003: Particleboard for furniture use, applicable for core panel structural performance verification; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
