Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions | 400 x 400 x 1505 mm | |
|---|---|---|
| Door panel height | 1405 mm | |
| Door panel width | 340 mm | |
| Brown side accent strip width | 40 mm | |
| Plinth base height | 80 mm | |
| Top cap trim thickness | 20 mm | |
| Interior usable depth | 360 mm | |
| Interior shelf quantity | 4 | |
| Adjustable shelf spacing range | 300 mm | |
| Carcass side panel thickness | 18 mm | |
| Door panel thickness | 18 mm | |
| Back panel thickness | 5 mm | |
| Edge banding thickness | 1 mm | |
| Anti-tip wall anchor installation height | 1350 mm | |
| Carcass Panel Thickness | 25 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Total cabinet static load capacity | 30 kg | |
|---|---|---|
| Door hinge cycle rating | 50000 open/close cycles | |
| Magnetic door catch retention force | 30 N | |
| Product net weight | 30 kg | |
| Anti-tip restraint load rating | 50 kg | |
| Surface abrasion resistance | 2000 cycles | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles | |
| Anti-tip Fixing Reference | Products above 1200 mm should use at least 2 wall fixing points |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Carcass panels | 18mm particle board with light oak grain paper laminate | |
|---|---|---|
| Door panel | 18mm engineered wood with vertical light wood grain texture | |
| Right-side accent trim | 18mm engineered wood with warm brown matte finish | |
| Plinth and top trim | 18mm engineered wood with light neutral matte finish | |
| Back panel | 5mm hardboard with light neutral finish | |
| Hardware components | Zinc-plated steel hinges, magnetic catch, wall anchor kit |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Door operation | Single side-hinged door with 110-degree opening angle | |
|---|---|---|
| Shelf adjustability | 4 height-adjustable shelves with 32mm hole spacing | |
| Door closure | Magnetic catch to hold door flush when closed | |
| Safety feature | Included wall-mounted anti-tip restraint |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Residential narrow space storage | Ideal for hallways, entryways or gaps with limited floor width | |
|---|---|---|
| Living room accent storage | Suitable for storing media accessories, books or display items |
EU Market Access Requirements* EN Standards
| EN 14749:2016 | Safety and strength requirements for domestic storage furniture, including tip-over resistance | |
|---|---|---|
| EN 312:2010 | Performance specifications for particle board used in furniture construction |
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.9 Storage Units |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for dimensional and structural quality checks | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, required for indoor air quality compliance |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for dimensional and structural quality checks; 2. GB 18580-2017: Formaldehyde emission limits for wood-based panels, required for indoor air quality compliance; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
