Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions | 2400 x 400 x 2000 mm | |
|---|---|---|
| Carcass Panel Thickness | 25 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Single shelf static load capacity | 30 kg | |
|---|---|---|
| Finished product net weight | 185 kg | |
| Anti-tip wall anchor load rating | 80 kg | |
| Shelf surface abrasion resistance | 2000 cycles | |
| Door panel edge band peel strength | 1.5 N/mm | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles | |
| Anti-tip Fixing Reference | Products above 1200 mm should use at least 2 wall fixing points | |
| Recommended Procurement Warranty | Carcass 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Cabinet carcase and shelves | 18mm thick E1 grade melamine-faced particle board, matte black finish | |
|---|---|---|
| Left and lower right solid doors | 25mm thick particle board with dark grey vertical wood grain melamine veneer, PVC edge banding | |
| Upper right display door | 5mm thick smoked brown tempered glass, framed in matching dark grey melamine | |
| Structural frame and plinth | 25mm thick melamine board with dark charcoal matte finish, matching shelf trim | |
| Door hardware | Concealed soft-close hinges for solid doors, sliding track for glass door | |
| Edge Band Thickness | 2 mm |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Storage configuration | Hybrid open display shelving with 11 staggered grid compartments and 2 fully enclosed solid door storage sections plus 1 tinted glass enclosed display section | |
|---|---|---|
| Open shelf usage | Adjustable shelving not fixed, suitable for displaying decor, storing books, files and office accessories | |
| Glass door function | Smoked tinted glass hides stored items while reducing dust accumulation on displayed objects, maintains sleek visual aesthetic | |
| Anti-tip protection | Wall anchor brackets included to secure cabinet to wall, prevent tipping during loading or movement |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Executive office backwall placement | Positioned behind executive desk for document storage and decorative display, matches dark wood executive desk suites | |
|---|---|---|
| Conference room storage wall | Used as side wall storage for meeting materials, awards and reference books in medium to large conference rooms |
EU Market Access Requirements* EN Standards
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.9 Storage Units |
|---|
Standards applicable to China-market projects
This product must meet the following technical requirements: 1. Technical standards and test reports must be supplied during tender or purchase confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
