Automatic mm / inch conversion · Core engineering specifications
| overall dimensions | 3600 x 400 x 2200 mm | |
|---|---|---|
| plinth base height | 80 mm | |
| lower cabinet internal height | 620 mm | |
| open shelf tier count | 4 | |
| per-shelf vertical spacing | 320 mm | |
| shelf usable depth | 350 mm | |
| center sliding panel total width | 900 mm | |
| lower cabinet door count | 6 | |
| vertical divider count (open shelves) | 5 | |
| LED strip recess depth | 10 mm | |
| Carcass Panel Thickness | 25 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
| unit total static load capacity | 300 kg | |
|---|---|---|
| LED light color temperature | 3000 K | |
| sliding panel cycle rating | 10000 open/close cycles | |
| lower cabinet door hinge cycle rating | 80000 open/close cycles | |
| surface abrasion resistance | 2000 revolutions | |
| product warranty period | 10 years | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles | |
| Anti-tip Fixing Reference | Products above 1200 mm should use at least 2 wall fixing points |
Core acceptance fields · Panels / hardware / frame / upholstery
| main carcass panels | 18mm thick E1-grade engineered wood particle board | |
|---|---|---|
| light-toned panel finish | Natural light oak wood grain veneer | |
| beige panel finish | Matte warm off-white melamine facing | |
| panel edge treatment | 2mm thick PVC edge banding | |
| unit back panel | 5mm thick MDF backing panel | |
| sliding panel track hardware | Anodized aluminum track with nylon glides | |
| lower cabinet door hinges | Concealed European-style soft-close hinges | |
| display lighting components | Recessed 12V warm white LED strip lights with aluminum channel | |
| plinth base construction | 18mm thick engineered wood with matching laminate finish | |
| Edge Band Thickness | 2 mm | |
| Primary Connector Specification | Reference M6-M8 cam/bolt fittings with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| display illumination | Integrated under-shelf warm white LED strips illuminate all open shelf compartments | |
|---|---|---|
| center access panels | Two overlapping sliding panels track horizontally to cover or reveal middle storage bays | |
| lower cabinet storage | Six handle-less flat-panel doors open to concealed full-width storage for files and supplies | |
| display shelf configuration | Four tiers of compartmentalized open shelves arranged for decor, books and display objects | |
| shelf adjustability | Open shelf positions support 25mm incremental height adjustment for variable item sizes | |
| anti-tip safety | Two wall-mounted anti-tip anchors secure the tall unit to prevent forward tipping | |
| lower cabinet door operation | Soft-close hinges pull doors closed gently to avoid slamming and reduce noise | |
| Cable / Vent Opening Reference | If fitted, 80 mm diameter |
Verified carton / gross weight / assembly / loading data
| number of shipping cartons | 5 | |
|---|---|---|
| shipping carton dimensions (master) | 2450 x 460 x 180 mm | |
| total shipping gross weight | 380 kg | |
| total shipping volume (CBM) | 1.82 | |
| required assembly time | 180 minutes | |
| 20ft GP container loading quantity | 10 units | |
| 40ft HQ container loading quantity | 25 units | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split |
Recommended spaces / users / usage modes
| executive office backdrop | Installed as a full-wall background storage unit behind executive desks for combined display and concealed storage | |
|---|---|---|
| corporate reception display | Used in reception areas to showcase corporate awards, branded decor and informational materials | |
| high-end meeting room storage | Installed in boardrooms to store meeting materials and display curated decorative objects | |
| private study or home office | Used in upscale home offices for book storage, decor display and concealed office supply organization | |
| recommended adjacent furniture pairing | Pairs with matching light oak and beige executive desks, office seating and side cabinets for a cohesive workspace suite |
EU Market Access Requirements* EN Standards
| EN 312:2010 | Particle board performance requirements for load-bearing furniture applications | |
|---|---|---|
| EN 14749:2016 | Safety and strength requirements for domestic and office storage furniture | |
| EN 62471:2008 | Photobiological safety standard for integrated LED lighting components |
US and Canada office-furniture standards
| ANSI/BIFMA X5.9-2019 | Standard for storage furniture performance and safety in commercial office environments |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for dimensional and structural qualityAcceptance | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limit for wood-based panels, requirement ≤0.124mg/m3 for E1 grade | |
| GB/T 4897.3-2003 | Specification for particle board used in furniture construction for structural performance |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for dimensional and structural qualityAcceptance; 2. GB 18580-2017: Formaldehyde emission limit for wood-based panels, requirement ≤0.124mg/m3 for E1 grade; 3. GB/T 4897.3-2003: Specification for particle board used in furniture construction for structural performance; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
