Automatic mm / inch conversion · Core engineering specifications
| Overall unit dimensions | 4000 x 420 x 2120 mm | |
|---|---|---|
| Base cabinet height | 700 mm | |
| Open display shelf section height | 1170 mm | |
| Left tall enclosed cabinet width | 550 mm | |
| Right tall enclosed cabinet width | 450 mm | |
| Central open shelf section width | 3000 mm | |
| Shelf depth | 380 mm | |
| Drawer internal dimensions | 550 x 350 x 150 mm | |
| Door panel thickness | 18 mm | |
| Back panel thickness | 9 mm | |
| Edge band thickness | 2 mm | |
| Adjustable shelf hole spacing | 32 mm | |
| Carcass Panel Thickness | 25 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
| Total unit net weight | 260 kg | |
|---|---|---|
| Per open shelf static load capacity | 25 kg | |
| Anti-tip anchoring connector count | 4 | |
| Door hinge open angle | 110 degrees | |
| Hinge cycle rating | 80000 open-close cycles | |
| Drawer slide cycle rating | 50000 open-close cycles | |
| Recommended maximum loaded weight | 300 kg | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Main cabinet carcass | 18mm E1 grade MFC particleboard | |
|---|---|---|
| Concrete-effect panel finish | High-pressure laminate with matte texture | |
| Light beige door panel finish | Matte thermofoil laminate | |
| Light grey door panel finish | Matte powder-coated or laminated MDF | |
| Rounded outer frame | Extruded aluminum with soft-touch matte coating | |
| Back panel | 9mm thick hardboard with matching finish | |
| Edge banding | 2mm thick PVC edge banding | |
| Hardware | Cold-rolled steel concealed hinges and drawer slides | |
| Integrated shelf lighting | 4000K recessed LED strip lighting | |
| Cabinet base plinth | Powder-coated steel leveling base | |
| Edge Band Thickness | 2 mm | |
| Primary Connector Specification | Reference M6-M8 cam/bolt fittings with at least 2 fixing points at major joints |
Adjustment / rotation / tilt / mobility / storage features
| Left tall cabinet storage | Two concealed door compartments separated by a middle concrete-effect panel | |
|---|---|---|
| Left open shelving | Three fixed open shelves for book and document display | |
| Central open storage | Multi-tier partitioned shelves with integrated LED display lighting | |
| Base cabinet storage | Seven soft-close hinged doors and one central drawer for concealed storage | |
| Drawer operation | Recessed integrated handle with push-to-open partial extension slide | |
| Door operation | Handleless push-latch door opening with concealed soft-close hinges | |
| Shelf adjustment | Selectable shelf positions via 32mm system hole grid for custom storage heights | |
| Cable management | Hidden rear cable channels for display lighting power supply | |
| Cable / Vent Opening Reference | If fitted, 80 mm diameter |
Verified carton / gross weight / assembly / loading data
| Number of flat-pack packages | 16 | |
|---|---|---|
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
| Executive office back wall | Placed behind executive desks for document and decor display storage | |
|---|---|---|
| Corporate reception area | Used as a backdrop storage wall for brand display and literature storage | |
| Home office library | Installed in luxury home offices for book and personal item storage | |
| Meeting room storage wall | Mounted along meeting room walls for document and equipment storage | |
| Recommended matching furniture | Paired with curved-edge executive desks and leather office seating | |
| Recommended installation | Wall-anchored to floor for tip-over safety on hard wood or tile flooring |
EU Market Access Requirements* EN Standards
| EN 14749:2016 | Safety and performance requirements for domestic and kitchen storage units | |
|---|---|---|
| EN 312:2010 | Particleboard specifications for load-bearing furniture applications | |
| EN 12521:2015 | Strength, durability and safety for non-domestic storage furniture |
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.9 |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for cabinet structural performance | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, applicable for E1 grade panel verification | |
| GB/T 4897.3-2015 | Particleboard specifications for furniture use, applicable for carcass material |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for cabinet structural performance; 2. GB 18580-2017: Formaldehyde emission limits for wood-based panels, applicable for E1 grade panel verification; 3. GB/T 4897.3-2015: Particleboard specifications for furniture use, applicable for carcass material; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
