Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2800 x 400 x 2400 mm | |
|---|---|---|
| Upper left closed cabinet size | 700 x 380 x 780 mm | |
| Lower full-width cabinet section height | 1020 mm | |
| Open shelf depth | 360 mm | |
| Large left open bookshelf height | 350 mm | |
| Upper small open cubby dimensions | 480 x 360 x 300 mm | |
| Lower right open display nook height | 350 mm | |
| Plinth base height | 60 mm | |
| Door panel thickness | 18 mm | |
| Shelf panel thickness | 25 mm | |
| Door handle length | 120 mm | |
| Adjustable shelf hole spacing | 32 mm | |
| Carcass Panel Thickness | 25 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
| Recommended static shelf load | 30 kg | |
|---|---|---|
| Closed cabinet interior shelf load | 35 kg | |
| Recommended maximum user weight for top surface | 50 kg | |
| Overall unit net weight | 220 kg | |
| Surface scratch resistance | 2000 cycles | |
| Surface stain resistance | Grade 4 | |
| Door hinge cycle rating | 80000 open/close cycles | |
| Recommended number of users | 15 | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Carcass side/back panels | 18mm E1-grade engineered wood, light taupe melamine finish | |
|---|---|---|
| Door panels | 18mm dark wood grain melamine-faced engineered wood | |
| Open shelf panels | 25mm dark wood grain melamine-faced engineered wood | |
| Plinth base | 25mm light taupe melamine engineered wood, floor-mounted | |
| Door handles | Matte black curved recessed bar, zinc alloy | |
| Door hinges | Cold-rolled steel concealed soft-close hinges | |
| Edge banding | 1mm PVC edge banding, color-matched to panels | |
| Back panel | 9mm medium density fiberboard, light taupe finish | |
| Shelf support pegs | Nickel-plated steel, 5mm diameter | |
| Anti-tip hardware | Zinc-plated steel wall anchor brackets | |
| Edge Band Thickness | 2 mm | |
| Primary Connector Specification | Reference M6-M8 cam/bolt fittings with at least 2 fixing points at major joints |
Adjustment / rotation / tilt / mobility / storage features
| Closed storage compartments | 8 hinged double-door sections, internal adjustable shelves for file and item storage | |
|---|---|---|
| Open display storage | 5 asymmetric staggered open cubbies for books and decorative display | |
| Door operation | Concealed hinges allow 110-degree opening swing for full interior access | |
| Shelf adjustability | 5 adjustable shelf positions per closed compartment via pre-drilled peg holes | |
| Lock option compatibility | Doors support optional core locks for secure document storage | |
| Anti-tip anchoring | Two wall-mounted anchor brackets prevent forward tipping when loaded | |
| Floor installation | Freestanding plinth-mounted design, requires wall anchoring for stability | |
| Cable management compatibility | Optional rear cable cutouts support integrated LED display lighting | |
| Cable / Vent Opening Reference | If fitted, 80 mm diameter |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
| Executive office back wall | Positioned behind a manager desk for document storage and decorative display | |
|---|---|---|
| Open office reception area | Used to display company awards, reading materials and decor at entry zones | |
| Conference room side wall | Stores meeting materials, reference documents and room decor items | |
| Shared office team zone | Provides 15-person team access to shared files and open display space | |
| Recommended configuration | Pair with matching executive desk and mobile file pedestal for coordinated office suite | |
| Installation note | Requires wall anchoring to concrete or stud wall for full load safety |
EU Market Access Requirements* EN Standards
| EN 312:2010 | Particleboard performance specification, applicable for structural cabinet panel requirements | |
|---|---|---|
| EN 14749:2016 | Safety and strength requirements for domestic and office storage furniture | |
| EN 13986:2004+A1:2015 | Wood-based panel performance for construction and furniture use |
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.9 Storage Units |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for panel strength and finish performance | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limit for wood-based panels, E1 grade required for indoor office use | |
| GB/T 4897.3-2015 | Particleboard specification for furniture use, applicable for structural panel components |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for panel strength and finish performance; 2. GB 18580-2017: Formaldehyde emission limit for wood-based panels, E1 grade required for indoor office use; 3. GB/T 4897.3-2015: Particleboard specification for furniture use, applicable for structural panel components; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
