Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1524 x 432 x 846 mm | |
|---|---|---|
| Open upper cubby count | 6 | |
| Individual upper cubby size | 300 x 350 x 400 mm | |
| Left solid door panel width | 380 mm | |
| Central fluted accent panel width | 320 mm | |
| Lower fluted trim band height | 120 mm | |
| Lower enclosed compartment width | 1140 mm | |
| Curved cutout opening height | 300 mm | |
| Adjustable shelf thickness | 18 mm | |
| Carcass panel thickness | 18 mm | |
| Edge band thickness | 1 mm | |
| Anti-tip wall anchor height | 760 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
| Product net weight | 36 kg | |
|---|---|---|
| Static load per open shelf | 15 kg | |
| Static load per lower compartment shelf | 25 kg | |
| Total cabinet static load capacity | 150 kg | |
| Hinge cycle durability | 80000 open/close cycles | |
| Drawer/door slide load rating | 25 kg | |
| Surface abrasion resistance | 2000 cycles | |
| Recommended maximum user weight for top surface | 30 kg | |
| Standard parts warranty | 1 year | |
| Shelf Distributed Load | 30 kg/shelf |
Core acceptance fields · Panels / hardware / frame / upholstery
| Main carcass | 18mm E1 grade MDF/engineered wood | |
|---|---|---|
| Left door and lower right panel finish | Matte light taupe polyurethane coating | |
| Open cubby and lower compartment interior | Dark charcoal wood-grain melamine veneer | |
| Central decorative panel | Vertical fluted grey oak veneer panel | |
| Accent strip detail | Matte terracotta painted solid wood inlay | |
| Middle trim band | Horizontal fluted light taupe MDF panel | |
| Hardware components | Zinc alloy concealed hinges, steel connecting screws | |
| Back panel | 3mm hardboard backing | |
| Edge treatment | 1mm color-matched PVC edge banding | |
| Anti-tip hardware | Steel wall anchor bracket with included screws | |
| Edge Band Thickness | 2 mm | |
| Primary Connector Specification | Reference M6-M8 cam/bolt fittings with at least 2 fixing points at major joints |
Adjustment / rotation / tilt / mobility / storage features
| Left enclosed storage access | Concealed push-to-open door covering full-height left compartment | |
|---|---|---|
| Upper open cubby storage | Six fixed open display shelves divided into two columns by central accent panel | |
| Lower compartment shelving | Two enclosed bays with 3-position height adjustable shelves | |
| Right lower compartment access | Curved asymmetrical cutout grip edge for handleless door operation | |
| Door operation | Soft-close concealed hinges with 110 degree opening angle | |
| Cable management | Rear cutout behind central panel for media device cord routing | |
| Safety feature | Included anti-tip wall anchor secures cabinet to wall to prevent tipping | |
| Floor contact | Low-profile integrated plinth base with felt floor protection pads | |
| Cable / Vent Opening Reference | If fitted, 80 mm diameter |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
| Living room accent placement | Position against empty living room wall for display of decor, books and media storage | |
|---|---|---|
| Entryway storage use | Placed in foyers to store entry essentials, keys and decorative objects | |
| Home office side storage | Used alongside a desk to store office supplies, books and workspace accessories | |
| Dining room sideboard use | Serves as a compact buffet for table linens, serveware and dining decor | |
| Residential only application | Designed for indoor dry residential use, not rated for outdoor or high-moisture environments | |
| Recommended wall mounting | Required to install included anti-tip anchor when used in homes with children or pets |
EU Market Access Requirements* EN Standards
| EN 14749:2016 | Domestic and kitchen storage units and worktops - safety requirements and test methods | |
|---|---|---|
| EN 12521:2015 | Furniture - strength, durability and safety for residential storage furniture | |
| EN 71-3:2019 | Safety of toys - migration of certain elements, applicable for surface coating material testing |
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.9 Storage Units |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for dimensional and structural acceptance | |
|---|---|---|
| GB 18584-2001 | Indoor decorating and refurbishing materials - limit of formaldehyde emission for wood-based furniture | |
| GB/T 4893.8-2013 | Surface wear resistance test method for furniture coatings, applicable for finish durability acceptance |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for dimensional and structural acceptance; 2. GB 18584-2001: Indoor decorating and refurbishing materials - limit of formaldehyde emission for wood-based furniture; 3. GB/T 4893.8-2013: Surface wear resistance test method for furniture coatings, applicable for finish durability acceptance; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
