Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions | 900 x 470 x 2140 mm | |
|---|---|---|
| Carcass panel thickness | 18 mm | |
| Top panel thickness | 25 mm | |
| Upper glass door section height | 1200 mm | |
| Lower solid door section height | 940 mm | |
| Clear glass door panel thickness | 5 mm | |
| Adjustable shelf count (upper section) | 4 | |
| Adjustable shelf pitch | 32 mm | |
| Plinth base height | 50 mm | |
| Door opening angle | 110 degrees | |
| Lower compartment internal depth | 430 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Net product weight | 100 kg | |
|---|---|---|
| Per-shelf static load capacity | 25 kg | |
| Lower door lock key quantity | 2 | |
| Hinge cycle durability | 80000 cycles | |
| Warranty period | 5 years | |
| Individual shelf load width | 800 mm | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles | |
| Anti-tip Fixing Reference | Products above 1200 mm should use at least 2 wall fixing points |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Carcass construction | 18mm melamine-faced particle board, light oak wood-grain finish | |
|---|---|---|
| Upper door panels | 5mm clear tempered glass set in MFC matching frames | |
| Lower door panels | 18mm melamine-faced MFC matching carcass finish, solid panels | |
| Back panel | 3mm hardboard fixed to carcass rear, sealed for stability | |
| Hardware components | Zinc alloy key lock, steel concealed hinges, silver-finish metal handles | |
| Edge banding | 1mm PVC edge banding matching wood finish, sealed on all exposed edges |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Shelf adjustability | Upper section shelves reposition along 32mm system holes for flexible storage height | |
|---|---|---|
| Secured storage | Central lower solid door fitted with key lock to restrict access to stored contents | |
| Door operation | All 5 hinged doors open outward 110 degrees with concealed soft-close hinges | |
| Anti-tip safety | Cabinet includes 2 wall-mounted anti-tip brackets to prevent forward tipping |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Office document storage | Suitable for private offices and open work areas to store files, books and reference materials | |
|---|---|---|
| Manager office use | Ideal for executive offices to keep documents organized while displaying decorative items |
EU Market Access Requirements* EN Standards
| EN 14073-2:2004 | Office storage furniture safety requirements, applicable for structural stability verification | |
|---|---|---|
| EN 14749:2016 | Domestic and kitchen storage units worktops safety requirements, applicable for anti-tip performance | |
| EN 312:2010 | Particle board specifications, applicable for wood-based panel material validation |
US and Canada office-furniture standards
| ANSI/BIFMA X5.9-2019 | Office storage units performance standard, applicable for load and durability testing | |
|---|---|---|
| ANSI/BIFMA e3-2019 | Furniture sustainability standard, applicable for environmental and material compliance checks |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for dimensional and structural quality checks | |
|---|---|---|
| GB/T 4897-2015 | Particle board performance standard, applicable for carcass material quality verification | |
| GB 18584-2001 | Indoor decoration material limit of harmful substances for wood furniture, applicable for emission testing |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for dimensional and structural quality checks; 2. GB/T 4897-2015: Particle board performance standard, applicable for carcass material quality verification; 3. GB 18584-2001: Indoor decoration material limit of harmful substances for wood furniture, applicable for emission testing; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
