Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2530 x 660 x 2360 mm | |
|---|---|---|
| Left sliding door panel dimensions | 750 x 1400 mm | |
| Top open display shelf dimensions | 1200 x 300 mm | |
| Middle open display shelf dimensions | 1500 x 300 mm | |
| Third-tier open display shelf dimensions | 1200 x 300 mm | |
| Lower full-width closed storage compartment dimensions | 2330 x 580 mm | |
| Side closed wood drawer panel dimensions (per unit) | 580 x 300 mm | |
| Shelf usable depth | 350 mm | |
| Lower storage compartment usable depth | 580 mm | |
| Metal frame profile thickness | 30 mm | |
| Wall clearance requirement behind unit | 50 mm | |
| LED strip recessed depth | 10 mm | |
| Carcass Panel Thickness | 25 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
| Total product net weight | 250 kg | |
|---|---|---|
| Open display shelf static load capacity | 15 kg per shelf | |
| Lower closed storage compartment static load | 50 kg | |
| Sliding door track rated cycle life | 50000 open/close cycles | |
| Drawer slide rated static load | 25 kg per drawer | |
| Drawer slide rated cycle life | 30000 open/close cycles | |
| LED strip operational lifespan | 30000 hours | |
| Maximum recommended user load for full unit | 200 kg | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Outer perimeter frame | Powder-coated matte grey steel, 30mm profile | |
|---|---|---|
| Sliding door panel core | 18mm thick MDF with matte dark grey laminate finish | |
| Closed storage wood-grain panels | 18mm thick particleboard with dark brown wood grain melamine foil | |
| Open shelf panels | 18mm thick MDF with matte dark grey laminate, matching door finish | |
| Back panel | 3mm thick hardboard dark grey finish | |
| Edge banding | 1mm thick PVC matching panel finish, applied to all exposed panel edges | |
| Sliding door track system | Anodized aluminum top and bottom tracks with nylon roller glides | |
| Integrated lighting | Low-voltage 3000K warm white LED strip recessed at shelf front edges | |
| Drawer hardware | Cold-rolled steel side-mount slides, zinc-plated finish | |
| Hanging rail (internal) | 25mm diameter oval steel tube, powder-coated dark grey | |
| Anti-tip hardware | Steel wall anchor brackets with included mounting screws | |
| Edge Band Thickness | 2 mm |
Adjustment / rotation / tilt / mobility / storage features
| Sliding door operation | Left offset panel slides horizontally on aluminum tracks to access internal hanging/folded storage | |
|---|---|---|
| LED shelf lighting | Warm white strips illuminate open display shelves, operated via touch switch or door sensor | |
| Internal shelf adjustability | Internal storage shelves support 5 height positions via 32mm system hole drilling | |
| Drawer operation | Wood-grain front drawers open smoothly on side-mount slides for small accessory storage | |
| Soft-close mechanism | Sliding doors and drawers include soft-close damping to prevent slamming | |
| Storage configuration | Mixed open display for decor/accessories, closed storage for clothing, full lower compartment for long garments | |
| Wall anchoring | Unit secures to wall via two anti-tip brackets to prevent forward tipping | |
| Cable management | Recessed rear channel routes LED power wiring to wall outlet without visible cords | |
| Cable / Vent Opening Reference | If fitted, 80 mm diameter |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
| Residential bedroom application | Primary clothing storage with integrated display for decor and personal items | |
|---|---|---|
| Studio apartment application | Space-saving sliding door design eliminates swing clearance for small living spaces | |
| Walk-in closet application | Modular storage mix of open and closed compartments for organized wardrobe storage | |
| Modern apartment interior design | Two-tone dark grey and wood finish matches contemporary minimalist, industrial decor styles | |
| Entryway/dressing area application | Lower closed storage for outerwear, open shelves for bags and frequently used accessories |
EU Market Access Requirements* EN Standards
| EN 14749:2016 | Safety and performance requirements for domestic and kitchen storage cabinets | |
|---|---|---|
| EN 12521:2015 | Strength, durability and safety requirements for residential furniture storage units | |
| EN 62471:2008 | Photobiological safety requirements for integrated LED lighting components |
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.9 Storage Units |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to cabinet performance and finish quality | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, required for indoor furniture compliance | |
| GB/T 4893.8-2013 | Surface wear resistance test for furniture finishes, applicable to laminated panel durability | |
| GB/T 10357.5-2011 | Cabinet furniture strength and durability test, applicable to shelf and load testing |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to cabinet performance and finish quality; 2. GB 18580-2017: Formaldehyde emission limits for wood-based panels, required for indoor furniture compliance; 3. GB/T 4893.8-2013: Surface wear resistance test for furniture finishes, applicable to laminated panel durability; 4. GB/T 10357.5-2011: Cabinet furniture strength and durability test, applicable to shelf and load testing; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
