2-Seat Fixed Floor-Mounted Auditorium Seating with Integrated Left-Side Writing Tablet Specifications

AUD-2S-WT-BKYL

代码:53TYEUV1
获取供应商报价
2026-08-20 18:14人气: 23
参数纠错历史记录(所有访客可见)
纠错时间修改字段原参数修改后参数说明 / 状态
暂无参数纠错记录,发现错误可点击行末旗标提交

AUD-2S-WT-BKYL

1家生产中供应商 >>
PRODUCT MODULE 01 / 06

基础物理尺寸

mm / 英寸自动双单位换算 · 工程采购基础规格

Overall unit dimensions (2-seat ganged)1220 x 785 x 970 mm
Single seat center-to-center distance610 mm
Seat height from finished floor460 mm
Depth with writing tablet stowed670 mm
Writing tablet usable surface size379 x 269 mm
Writing tablet panel thickness9 mm
Armrest top height above seat surface240 mm
Clear knee clearance height under tablet660 mm
Floor mounting foot plate length per stanchion215 mm
Seat cushion usable width per position540 mm
Finished Seat Cushion Thickness90 mm
Backrest Padding Thickness70 mm
Lumbar Support Zone Height240 mm
Clear Width Between Armrests540 mm
PRODUCT MODULE 02 / 06

重量、承重与性能参数

净重 / 最大承重 / 适用人数 / 耐久性能

Per-seat static load capacity260 kg
Seat foam density (seat cushion)60 kg/m³
Backrest foam density55 kg/m³
Unit net weight (2-seat ganged)80 kg
Recommended daily occupancy durability12000 use cycles
Standard fabric upholstery abrasion resistance50000 Martindale cycles
Standard warranty period for frame and mechanism5 years
Seat Foam Density / Rebound Reference45 kg/m³ / 65%
Back Foam Density Reference38 kg/m³
Upholstery Thickness / Abrasion Reference1.4 mm / 50000 cycles
PRODUCT MODULE 03 / 06

材质与结构参数

工程采购验收核心字段 · 面板基材 / 五金 / 框架 / 面料

Primary support stanchions and frame2.0 mm thick cold-rolled steel, matte black powder-coated finish
Seat cushion and backrest paddingCold-molded polyurethane foam, high resilience
Seat and back outer shell panels15 mm thick E1-grade plywood, matte black painted finish
Seat and back upholsteryContract-grade woven polyester fabric, yellow/beige finish
ArmrestsCurved steel frame with integrated padded tops, black finish
Integrated writing tablet surface9 mm thick MDF board, light wood-grain laminate finish
Seat tip-up mechanismSteel hinge assembly with damping cylinder for quiet return
Under-table cable management trayPerforated steel wire tray, black powder-coated finish
Floor mounting hardwareM8 hex socket expansion anchor bolts, zinc-plated finish
Seat Internal Support Board Thickness14 mm bent plywood or equivalent support board
Backrest Internal Frame Thickness14 mm bent plywood/composite reinforced frame
Gas-lift Engineering SpecificationRecommended Class 4; outer tube 50 mm; stroke 100 mm
PRODUCT MODULE 04 / 06

功能与调节参数

升降 / 旋转 / 倾仰 / 锁定 / 移动 / 储物功能

Seat tip-up operationGravity-assisted automatic return with damper, 90-degree upward fold to clear aisle space
Writing tablet operationFixed continuous left-side surface with anti-panic fold-down design, locks in horizontal use position
Cable management functionUnder-table perforated tray routes power and AV cables for attendee devices
Floor mounting functionPermanent fixed installation to concrete or raised tiered floors via anchor bolts
Ganged seating alignmentShared stanchion design connects adjacent seats in continuous straight rows for tiered halls
Armrest functionContoured armrests separate adjacent seats and provide upper body support during extended use
Seat cushion contouringErgonomically curved waterfall front edge reduces leg pressure during long lectures
Backrest contouringLumbar-support curved backrest maintains upright posture for 2+ hour seated events
Recline Angle / Lock Reference125° with 3suggested lock positions
Tilt Tension User-weight RangeReference adjustment coverage 120 kg
Height Adjustment Stroke100 mm continuous travel
Rotation / Mobility Configuration360° swivel with 5-caster multidirectional movement
PRODUCT MODULE 05 / 06

包装与物流参数

经核验的外箱 / 毛重 / 组装 / 装柜数据

Reference Package Count1 set / 2 cartons
Reference Assembly Time40 minutes per set
Reference Carton Dimensions850× 420× 720 mm
Reference Packaged Gross Weight23 kg/set
Reference Carton Volume0.26 m³/set
Indicative 20GP Loading135 sets at 85% space utilization
Indicative 40HQ Loading320 sets at 85% space utilization
PRODUCT MODULE 06 / 06

应用场景与使用方式

推荐空间 / 目标用户 / 使用方式

University tiered lecture hallsFixed ganged layout provides clear sightlines and dedicated writing surface for note-taking
Corporate training and conference auditoriumsTip-up seats enable quick aisle access between sessions for large attendee groups
School multi-purpose assembly hallsDurable steel frame and contract-grade fabric withstand daily high-traffic student use
Cinema and screening rooms with note-taking requirementsIntegrated tablet supports program materials and personal devices during screenings
Government and institutional hearing roomsPermanent floor mounting prevents unauthorized reconfiguration and supports AV cabling
Recommended row configurationSeats mount to tiered floors with 900mm minimum row-to-row spacing for unobstructed egress
Recommended Matching Desk Size2.4 m executive desk
Reference Daily Use Duration8 hours/day; confirm by ergonomic testing
STANDARD S1

欧盟市场准入要求 * EN 标准

欧洲市场准入与化学品要求

EN 12727:2000Applies to strength, durability and safety requirements for fixed auditorium seating
EN 1021-1:2014Applies to upholstered furniture flammability resistance to smoldering cigarette ignition
EN 1021-2:2014Applies to upholstered furniture flammability resistance to match flame ignition
STANDARD S3

适用于中国市场项目的标准 * GB 标准

适用于中国市场项目的标准

GB/T 20247-2006Applies to acoustical performance of upholstered seating for auditorium and theater spaces
GB 20286-2006Applies to fire retardancy requirements for upholstered furniture in public assembly spaces
招标文件标准化描述文本
本产品须满足以下技术参数要求:
1. GB/T 20247-2006:Applies to acoustical performance of upholstered seating for auditorium and theater spaces;
2. GB 20286-2006:Applies to fire retardancy requirements for upholstered furniture in public assembly spaces;
最终交付参数、检测报告和验收标准以双方采购合同为准。
GENERATED EXPORTS

一键导出完整商品资料

以下文件均根据当前已发布商品参数实时生成。

完整参数报告 PDF

直接下载英文参数报告,可选择公制或英制单位。

PDF · AUD-2S-WT-BKYL

完整参数 Excel

导出全部商品信息与参数模块,文件内容统一使用英文。

XLSX · AUD-2S-WT-BKYL

外贸 Listing 模板

包含英文标题、规格、材质、标准和采购字段,可用于国际平台刊登。

XLSX · LISTING

海关申报数据

生成申报品名、材质、用途、尺寸及海关申报要素。

CUSTOMS · AUD-2S-WT-BKYL打开导出工具

页面快速操作

发布采购询价

产品描述

This 2-seat fixed floor-mounted auditorium seating unit balances functional durability, space efficiency, and user comfort for high-traffic public and institutional settings. The ganged two-seat configuration presents a streamlined, purpose-built layout, with yellow-beige contract-grade woven polyester upholstery set against matte black structural frames and outer shells, paired with light wood-grain laminate left-side writing tablets for a warm, professional visual profile that integrates smoothly into formal interior environments. Each seat folds 90 degrees upward via a gravity-assisted, damped automatic return mechanism to keep aisles clear when not in use, with contoured black steel armrests with padded tops separating adjacent seats to provide upper body support during extended sessions. The waterfall-front ergonomic seat cushion uses high-resilience cold-molded PU foam, reducing leg pressure during long events, while the fixed left-side writing tablet features an anti-panic fold-down design that locks securely in the horizontal position for use. A perforated black powder-coated steel tray sits beneath each tablet to route power and AV cables for attendee devices. The core frame is constructed from 2.0mm thick cold-rolled steel with a matte black powder-coated finish, paired with 15mm thick E1-grade plywood outer seat and back shells finished in matte black. The integrated MDF writing tablet delivers a stable writing surface, and steel hinge assemblies with damping cylinders ensure quiet, smooth seat operation. Seats secure permanently to concrete or raised tiered floors using zinc-plated M8 hex socket expansion anchor bolts, with shared stanchions that connect adjacent units to form continuous straight rows across venue floors. This seating is well suited for university tiered lecture halls, where it delivers clear sightlines and dedicated surfaces for note-taking, as well as corporate training and conference auditoriums, where tip-up seats enable quick aisle access between sessions for large attendee groups. It also performs reliably in school multi-purpose assembly halls, with robust construction that stands up to daily high-traffic student use, screening rooms that require space for program materials and personal devices, and government or institutional hearing rooms, where fixed mounting prevents unauthorized reconfiguration and supports integrated AV cabling. For procurement, note that each two-seat unit ships in two cartons, requires permanent floor mounting, and is specified for tiered installations with sufficient row-to-row spacing to support unobstructed egress. The frame and mechanism carry a standard 5-year warranty, with fabric and foam selected to withstand regular, high-volume occupancy. The 260kg per-seat static load capacity, high-abrasion upholstery, and damped, quiet operating mechanisms make it a practical choice for venues with consistent daily use.
