商品供应商Modern Curved-End Matte Cream TV Media Console with Champagne Gold Plinth Base,Sintered stone
可联系供应商获取生产周期与报价。
| 纠错时间 | 修改字段 | 原参数 | 修改后参数 | 说明 / 状态 |
|---|---|---|---|---|
暂无参数纠错记录,发现错误可点击行末旗标提交 | ||||
mm / 英寸自动双单位换算 · 工程采购基础规格
| Overall dimensions | 2400 x 450 x 450 mm | |
|---|---|---|
| Top surface thickness | 18 mm | |
| Drawer front panel thickness | 18 mm | |
| Carcass side/back panel thickness | 15 mm | |
| Champagne gold plinth base height | 60 mm | |
| Top edge trim width | 10 mm | |
| Individual drawer front width | 480 mm | |
| Internal drawer depth | 400 mm | |
| Curved end radius | 225 mm | |
| Floor clearance under plinth | 5 mm | |
| Usable top surface depth | 430 mm | |
| Cable pass-through opening diameter | 60 mm | |
| Carcass Panel Thickness | 25 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
净重 / 最大承重 / 适用人数 / 耐久性能
| Tabletop static load capacity | 100 kg | |
|---|---|---|
| Total product net weight | 90 kg | |
| Maximum supported TV size | 85 inch | |
| Drawer slide cycle rating | 50000 open/close cycles | |
| Surface scratch resistance rating | 3H pencil hardness | |
| Available colorway count | 3 | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles | |
| Anti-tip Fixing Reference | Products above 1200 mm should use at least 2 wall fixing points |
工程采购验收核心字段 · 面板基材 / 五金 / 框架 / 面料
| Top surface | 18mm polished sintered stone with natural stone-like patterned finish | |
|---|---|---|
| Drawer fronts | 18mm medium-density fiberboard with semi-matte cream baked paint finish | |
| Internal carcass | 15mm multi-layer engineered wood with moisture-resistant sealed edges | |
| Back panel | 8mm hardboard with pre-cut cable management openings | |
| Plinth base and trim | 1.2mm thick stainless steel with brushed champagne gold PVD finish | |
| Drawer slides | Three-section full-extension cold-rolled steel with soft-close damping | |
| Leveling feet | Adjustable nylon-tipped steel feet integrated into plinth base | |
| Internal drawer bottoms | 5mm high-density fiberboard with melamine wear-resistant finish | |
| Edge Band Thickness | 2 mm | |
| Primary Connector Specification | Reference M6-M8 cam/bolt fittings with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
升降 / 旋转 / 倾仰 / 锁定 / 移动 / 储物功能
| Storage configuration | Five full-width handleless drawers spanning the console length for media accessories | |
|---|---|---|
| Drawer operation | Push-to-open soft-close mechanism with 400mm full extension travel | |
| Cable management | Dual rear cable pass-through openings aligned with center and side media device positions | |
| Ventilation | Rear panel ventilation slots behind each drawer bay to prevent AV equipment overheating | |
| Level adjustment | 8 adjustable feet integrated into plinth base allow 10mm total height adjustment for uneven floors | |
| Surface protection | Stain-resistant wipe-clean sintered stone top resists heat from media devices and liquid spills | |
| Edge safety | Fully rounded curved end caps eliminate sharp corners for high-traffic living room use | |
| Cable / Vent Opening Reference | 80 mm diameter; recommend 4rear cable/vent openings |
经核验的外箱 / 毛重 / 组装 / 装柜数据
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
推荐空间 / 目标用户 / 使用方式
| Residential living room | Positioned below wall-mounted 85inch TVs for media device storage and decor display | |
|---|---|---|
| Open-plan lounge space | Low profile maintains sight lines in open concept seating areas without blocking views | |
| Modern light luxury interiors | Curved cream and gold finish complements contemporary, French-modern and minimalist design schemes | |
| Media equipment storage | Enclosed drawers hide media players, cables, game consoles and remote controls out of sight | |
| High-traffic family spaces | Rounded edges and durable wipe-clean surfaces suit daily use in households with children or pets |
欧洲市场准入与化学品要求
| EN 14749:2016 | Safety and strength requirements for domestic storage furniture, applicable to cabinet stability | |
|---|---|---|
| EN 12521:2015 | Strength durability and stability requirements for domestic tables, applicable to top surface load |
适用于中国市场项目的标准
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to cabinet carcass structural performance | |
|---|---|---|
| GB 18584-2001 | Limit of harmful substances in wooden furniture, applicable to formaldehyde emission testing | |
| GB/T 4897.3-2015 | Particleboard for furniture use, applicable to engineered wood panel structural grade |
本产品须满足以下技术参数要求: 1. GB/T 3324-2017:General technical requirements for wooden furniture, applicable to cabinet carcass structural performance; 2. GB 18584-2001:Limit of harmful substances in wooden furniture, applicable to formaldehyde emission testing; 3. GB/T 4897.3-2015:Particleboard for furniture use, applicable to engineered wood panel structural grade; 最终交付参数、检测报告和验收标准以双方采购合同为准。
