基础物理尺寸
mm / 英寸自动双单位换算 · 工程采购基础规格
数据来源:工厂资料结构化字段,最终以实测值为准
| 产品外部尺寸(宽 × 深 × 高) | 1600 × 900 × 450 mm | |
|---|---|---|
| individual tabletop segment side length | 830 mm | |
| tabletop thickness | 20 mm | |
| pedestal base top width | 350 mm | |
| pedestal base bottom flare width | 480 mm | |
| pedestal height | 430 mm | |
| tabletop overlap length | 230 mm | |
| metallic edge trim thickness | 2 mm | |
| floor clearance under tabletop | 100 mm | |
| pedestal wall thickness | 15 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
重量、承重与性能参数
净重 / 最大承重 / 适用人数 / 耐久性能
数据来源:产品性能数据,采购前请核对具体测试口径
| tabletop distributed static load | 80 kg | |
|---|---|---|
| point load capacity per 100x100mm area | 20 kg | |
| product net weight | 75 kg | |
| finish scratch resistance rating | 3H | |
| surface water repellency rating | Grade 5 | |
| base lateral stability load | 30 kg | |
| suitable number of simultaneous users | 6 | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
材质与结构参数
工程采购验收核心字段 · 面板基材 / 五金 / 框架 / 面料
数据来源:以工厂材质清单与验货报告为准
| main tabletop | Polished panda-style marble-look stone with grey/black veining | |
|---|---|---|
| tabletop edge trim | Polished brushed stainless steel band | |
| pedestal bases | Powder-coated dark carbon steel, tapered flared form | |
| base structural frame | 15mm thick welded steel internal support | |
| tabletop backing layer | 12mm thick moisture-resistant MDF reinforcement | |
| base bottom pads | 5mm thick non-slip felt floor protectors | |
| metal surface finish | Matte black powder coating, 80um thickness | |
| stone surface sealant | Food-safe penetrating stone sealer | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
功能与调节参数
升降 / 旋转 / 倾仰 / 锁定 / 移动 / 储物功能
数据来源:功能配置参数,以供应商正式规格为准
| surface use support | Flat seamless extended surface for drinks, decor and snack service | |
|---|---|---|
| floor protection | Felt bottom pads prevent scuffing on carpet and hard flooring | |
| structural stability | Dual pedestal weight distribution eliminates wobble on level floors | |
| cleaning compatibility | Sealed non-porous surface supports wiping with neutral household cleaners | |
| installation requirement | Partial assembly required: attach tabletop segments to pre-drilled pedestal bases | |
| mobility | Fixed non-rolling design, no casters or moving parts | |
| storage provision | No built-in drawers, shelves or hidden compartments | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
包装与物流参数
经核验的外箱 / 毛重 / 组装 / 装柜数据
数据来源:外贸报价与装柜测算参考
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
应用场景与使用方式
推荐空间 / 目标用户 / 使用方式
数据来源:依据产品结构与品类整理的推荐应用场景
| primary living room placement | Positioned in front of large sectional sofas in open-plan living areas | |
|---|---|---|
| luxury residential application | Suitable for modern, Italian minimalist or light luxury interior schemes | |
| lounge area service use | Supports casual drink service, snack display and decorative item placement | |
| show home / model suite use | Ideal for upscale residential show homes and high-end apartment staging | |
| recommended pairing furniture | Matches tufted leather or fabric sectionals, low-pile carpets, metal accent lighting | |
| indoor use limitation | Designed for dry indoor use only, not suitable for outdoor or high-moisture areas |
欧盟市场准入要求 * EN 标准
欧洲市场准入与化学品要求
| furniture safety for domestic use | EN 12521:2015 | |
|---|---|---|
| stone surface slip resistance | EN 14231:2003 | |
| surface formaldehyde emission | EN 13986:2004 |
适用于中国市场项目的标准 * GB 标准
适用于中国市场项目的标准
| tabletop material safety | GB 6566 | |
|---|---|---|
| furniture surface durability | GB/T 4893.4 | |
| furniture structural stability | GB/T 10357.7 | |
| metal coating adhesion | GB/T 9286 |
本产品须满足以下技术参数要求: 1. tabletop material safety:GB 6566; 2. furniture surface durability:GB/T 4893.4; 3. furniture structural stability:GB/T 10357.7; 4. metal coating adhesion:GB/T 9286; 最终交付参数、检测报告和验收标准以双方采购合同为准。
