基础物理尺寸
mm / 英寸自动双单位换算 · 工程采购基础规格
数据来源:工厂资料结构化字段,最终以实测值为准
| 产品外部尺寸(宽 × 深 × 高) | 1300 × 700 × 450 mm | |
|---|---|---|
| Overall set footprint (arranged side by side) | 1800 x 700 x 450 mm | |
| Large oval coffee table dimensions | 1300 x 700 x 450 mm | |
| Small side table dimensions | 500 x 500 x 430 mm | |
| Tabletop thickness | 18 mm | |
| Decorative base sphere diameter | 200 mm | |
| Metal leg tube wall thickness | 1.2 mm | |
| Floor clearance under large table | 100 mm | |
| Nesting overlap clearance | 50 mm | |
| Large table top minor axis width | 700 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
重量、承重与性能参数
净重 / 最大承重 / 适用人数 / 耐久性能
数据来源:产品性能数据,采购前请核对具体测试口径
| Large table static distributed load capacity | 50 kg | |
|---|---|---|
| Set total net weight | 35 kg | |
| Surface scratch resistance rating | Level 3 (4000 abrasion cycles) | |
| Surface heat resistance threshold | 120 °C | |
| Frame anti-corrosion coating durability | 5 years | |
| Floor protector pad static friction coefficient | 0.6 | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
材质与结构参数
工程采购验收核心字段 · 面板基材 / 五金 / 框架 / 面料
数据来源:以工厂材质清单与验货报告为准
| Large table top | 18mm sintered stone with polished marble-vein finish | |
|---|---|---|
| Small table top | 10mm clear tempered glass with light tint | |
| Large table frame and base | Powder-coated black carbon steel with matte black spherical base accent | |
| Small table frame and base | Titanium gold-plated stainless steel with polished gold spherical base accent | |
| Foot pads | Non-slip silicone rubber pads attached to all leg bases | |
| Connection hardware | Zinc-plated steel M6 screw fasteners with lock washers | |
| Metal surface finish | Multi-layer scratch-resistant spray coating on black frames, electroplated polish on gold frames | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support | |
| Reference Finish / Color Count | Recommended 6top finishes and 3frame colors |
功能与调节参数
升降 / 旋转 / 倾仰 / 锁定 / 移动 / 储物功能
数据来源:功能配置参数,以供应商正式规格为准
| Nesting storage function | Small side table tucks 400mm under the large table edge to reduce footprint when not in use | |
|---|---|---|
| Surface utility function | Smooth non-porous tops support placement of drinks, decor, books and small serving items | |
| Floor protection function | Pre-installed silicone pads prevent metal legs from scratching hard flooring and reduce movement noise | |
| Assembly structure | Knock-down design requiring attachment of legs/base spheres to tabletops with included hardware | |
| Arrangement flexibility | Tables can be positioned separately as side table plus center table, or nested for compact small-space use | |
| Cleaning function | Non-porous stone and glass tops allow wipe-clean maintenance with damp cloth | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
包装与物流参数
经核验的外箱 / 毛重 / 组装 / 装柜数据
数据来源:外贸报价与装柜测算参考
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
应用场景与使用方式
推荐空间 / 目标用户 / 使用方式
数据来源:依据产品结构与品类整理的推荐应用场景
| Residential living room | Placed in front of sofas for serving drinks, displaying decor and holding media remotes | |
|---|---|---|
| Small apartment/open studio | Nesting function saves floor space when extra surface area is not required | |
| Lounge/waiting area | Used in office reception or hotel lounge areas for guest beverage placement | |
| Open-plan bedroom seating nook | Positioned next to accent chairs as paired side/coffee surface for reading corners | |
| Modern minimalist/light luxury interiors | Matches black/gold contemporary decor schemes with stone and metal finish palette |
欧盟市场准入要求 * EN 标准
欧洲市场准入与化学品要求
| EN 12521:2015 | Safety strength and durability requirements for domestic dining and living room tables | |
|---|---|---|
| EN 13722:2004 | Test methods for furniture table surface resistance to heat and staining |
适用于中国市场项目的标准 * GB 标准
适用于中国市场项目的标准
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to top substrate quality checks | |
|---|---|---|
| GB/T 4893.4-2013 | Surface abrasion resistance test standard for furniture finished surfaces | |
| GB 18584-2001 | Limit of harmful substances for indoor wooden furniture, applicable for emission testing |
本产品须满足以下技术参数要求: 1. GB/T 3324-2017:General technical requirements for wooden furniture, applicable to top substrate quality checks; 2. GB/T 4893.4-2013:Surface abrasion resistance test standard for furniture finished surfaces; 3. GB 18584-2001:Limit of harmful substances for indoor wooden furniture, applicable for emission testing; 最终交付参数、检测报告和验收标准以双方采购合同为准。
