基础物理尺寸
mm / 英寸自动双单位换算 · 工程采购基础规格
数据来源:工厂资料结构化字段,最终以实测值为准
| 产品外部尺寸(宽 × 深 × 高) | 1200 × 700 × 420 mm | |
|---|---|---|
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
重量、承重与性能参数
净重 / 最大承重 / 适用人数 / 耐久性能
数据来源:产品性能数据,采购前请核对具体测试口径
| product net weight | 48 kg | |
|---|---|---|
| tabletop static load capacity | 80 kg | |
| supported user count | 4 | |
| surface scratch resistance rating | 6 Mohs | |
| structure service life | 8 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years; finish 2 years |
材质与结构参数
工程采购验收核心字段 · 面板基材 / 五金 / 框架 / 面料
数据来源:以工厂材质清单与验货报告为准
| tabletop | 12mm white sintered stone with grey marble veining, matte polished surface | |
|---|---|---|
| cylindrical support leg | Light oak veneer over MDF core, natural vertical grain finish | |
| left solid support block | Light oak veneer over particleboard core, rounded exposed edges | |
| metal support frames | Brushed bronze plated carbon steel, U-shaped open frame design | |
| support connection hardware | Zinc-plated steel dowels and mounting brackets | |
| bottom foot pads | Non-slip PE plastic, floor-protecting contact surface | |
| tabletop backing layer | 15mm high-density fiberboard reinforcement layer | |
| metal surface finish | Brushed anti-fingerprint bronze coating | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
功能与调节参数
升降 / 旋转 / 倾仰 / 锁定 / 移动 / 储物功能
数据来源:功能配置参数,以供应商正式规格为准
| fixed stationary placement | Four-point support structure designed for permanent placement without mobility casters | |
|---|---|---|
| flat load-bearing surface | Level, seamless tabletop supporting beverage service, reading materials and decorative items | |
| floor protection | Recessed foot pads prevent direct metal/wood contact with hard flooring to reduce scratches | |
| stain-resistant tabletop | Non-porous sintered stone surface allows wet cloth cleaning without sealing | |
| stable dual-side support | Asymmetric mixed leg layout eliminates wobbly tops and provides knee clearance for seated use | |
| hidden internal wiring | Solid support block allows optional aftermarket cable routing for tabletop lamps or devices | |
| solid wood block support size | 400 x 250 x 408 mm | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
包装与物流参数
经核验的外箱 / 毛重 / 组装 / 装柜数据
数据来源:外贸报价与装柜测算参考
| number of shipping packages | 1 | |
|---|---|---|
| shipping carton dimensions | 1280 x 780 x 180 mm | |
| shipping gross weight | 55 kg | |
| shipping volume per unit | 0.18 CBM | |
| required assembly time | 30 minutes | |
| 20ft GP container loading quantity | 150 units | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons |
应用场景与使用方式
推荐空间 / 目标用户 / 使用方式
数据来源:依据产品结构与品类整理的推荐应用场景
| residential living room placement | Positioned in front of 3-seat sofas for beverage service and decorative display | |
|---|---|---|
| modern light luxury interiors | Suits spaces with neutral upholstery, light wood and metallic accent finishes | |
| lounge and reception waiting areas | Suitable for low-traffic office reception zones serving guest refreshments | |
| open-plan apartment seating zones | Scaled appropriately for compact to mid-sized open living spaces without blocking foot traffic | |
| hard floor surface use | Designed for tile, polished concrete and engineered wood floors with protective foot pads |
欧盟市场准入要求 * EN 标准
欧洲市场准入与化学品要求
| surface abrasion resistance | EN 15185:2011 Furniture - Assessment of surface resistance to abrasion | |
|---|---|---|
| structural strength requirement | EN 12521:2015 Furniture - Strength, durability and safety for domestic tables |
适用于中国市场项目的标准 * GB 标准
适用于中国市场项目的标准
| tabletop flatness tolerance | GB/T 3324General technical requirements for wooden furniture | |
|---|---|---|
| surface adhesion performance | GB/T 4893.4Furniture surface paint film adhesion test | |
| structural stability requirement | GB/T 10357.1Furniture mechanical test for table stability |
本产品须满足以下技术参数要求: 1. tabletop flatness tolerance:GB/T 3324General technical requirements for wooden furniture; 2. surface adhesion performance:GB/T 4893.4Furniture surface paint film adhesion test; 3. structural stability requirement:GB/T 10357.1Furniture mechanical test for table stability; 最终交付参数、检测报告和验收标准以双方采购合同为准。
