基础物理尺寸
mm / 英寸自动双单位换算 · 工程采购基础规格
数据来源:工厂资料结构化字段,最终以实测值为准
| 产品外部尺寸(宽 × 深 × 高) | 1200 × 700 × 450 mm | |
|---|---|---|
| Overall set dimensions (large table primary) | 1200 x 700 x 450 mm | |
| Small nested table dimensions | 900 x 500 x 420 mm | |
| Tabletop thickness | 12 mm | |
| Large tabletop oval major axis | 1200 mm | |
| Large tabletop oval minor axis | 700 mm | |
| Small tabletop oval major axis | 900 mm | |
| Small tabletop oval minor axis | 500 mm | |
| Metal base leg spread (large table) | 650 mm | |
| Metal base leg spread (small table) | 500 mm | |
| Metal leg section thickness | 20 mm | |
| Floor clearance under tabletop | 420 mm | |
| Edge radius of tabletop | 350 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
重量、承重与性能参数
净重 / 最大承重 / 适用人数 / 耐久性能
数据来源:产品性能数据,采购前请核对具体测试口径
| Total set net weight | 37 kg | |
|---|---|---|
| Static distributed load capacity per table | 100 kg | |
| Surface scratch resistance (sintered stone) | 6 Mohs hardness | |
| Surface stain resistance rating | Grade 5 | |
| Recommended maximum number of users | 4 | |
| Base static stability load | 150 kg | |
| Finish abrasion cycles (metal base) | 10000 cycles | |
| Surface heat resistance | 180 °C | |
| Standard product warranty | 2 years | |
| Top Static Load Reference | 150 kg uniformly distributed |
材质与结构参数
工程采购验收核心字段 · 面板基材 / 五金 / 框架 / 面料
数据来源:以工厂材质清单与验货报告为准
| Large table tabletop | 12mm thick white sintered stone, polished matte finish, rounded edges | |
|---|---|---|
| Small table tabletop | 12mm thick white sintered stone, matching finish and edge treatment | |
| Support base frame | 20mm square black carbon steel tube, powder-coated matte black finish | |
| Base foot pads | 5mm thick non-slip polyethylene floor protectors, fitted to each leg end | |
| Connection hardware | M8 zinc-plated steel bolts with lock washers, pre-threaded inserts in tabletops | |
| Tabletop backing panel | 8mm thick high-density MDF reinforcement panel under stone top | |
| Metal base weld points | Full penetration TIG welds, ground smooth before powder coating | |
| Surface coating thickness (metal) | 60 micron matte black powder coat | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
功能与调节参数
升降 / 旋转 / 倾仰 / 锁定 / 移动 / 储物功能
数据来源:功能配置参数,以供应商正式规格为准
| Nesting storage function | Small table slides under large table with 300mm overlap to save floor space | |
|---|---|---|
| Fixed height design | Permanent 450mm table height optimized for seated use from standard sofas | |
| Floor protection function | Non-slip PE foot pads glide gently without scratching hard floors or carpet | |
| Easy-clean surface | Non-porous sintered stone top wipes clean with damp cloth, no sealing required | |
| Anti-collision edge design | Fully rounded racetrack oval edges eliminate sharp corners to prevent impact injury | |
| Tool-light assembly | Two people can complete assembly in 20 minutes with included hex key | |
| Dual-table flexible use | Tables can be separated for extra serving space or nested for compact layout | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
包装与物流参数
经核验的外箱 / 毛重 / 组装 / 装柜数据
数据来源:外贸报价与装柜测算参考
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
应用场景与使用方式
推荐空间 / 目标用户 / 使用方式
数据来源:依据产品结构与品类整理的推荐应用场景
| Living room center placement | Position in front of 4seat upholstered sofas for placing drinks, books and decor | |
|---|---|---|
| Small apartment living space | Nested configuration reduces footprint to 0.84sqm for compact studio apartments | |
| Contemporary interior schemes | White and black minimalist finish suits modern, minimalist and Japandi decor styles | |
| Casual entertaining use | Separate tables to provide extra serving surface for drinks and snacks during gatherings | |
| Light commercial lounge use | Suitable for office reception areas and boutique lounge waiting spaces | |
| Open-concept family spaces | Rounded edges reduce injury risk for homes with young children and pets |
欧盟市场准入要求 * EN 标准
欧洲市场准入与化学品要求
| EN 12521:2015 | Furniture for domestic use, strength, durability and safety requirements for tables | |
|---|---|---|
| EN 13722:2004 | Furniture, test methods for surface resistance to cold liquids for table surfaces |
适用于中国市场项目的标准 * GB 标准
适用于中国市场项目的标准
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for MDF backing panel quality checks | |
|---|---|---|
| GB/T 4897.3-2015 | Particleboard/MDF performance requirements for furniture structural backing panels | |
| GB 18584-2001 | Indoor decoration material limit of harmful substances for wood furniture, applicable for formaldehyde emission checks | |
| GB/T 19001-2016 | Quality management system reference for production consistency of metal and stone components |
本产品须满足以下技术参数要求: 1. GB/T 3324-2017:General technical requirements for wooden furniture, applicable for MDF backing panel quality checks; 2. GB/T 4897.3-2015:Particleboard/MDF performance requirements for furniture structural backing panels; 3. GB 18584-2001:Indoor decoration material limit of harmful substances for wood furniture, applicable for formaldehyde emission checks; 4. GB/T 19001-2016:Quality management system reference for production consistency of metal and stone components; 最终交付参数、检测报告和验收标准以双方采购合同为准。
