基础物理尺寸
mm / 英寸自动双单位换算 · 工程采购基础规格
数据来源:工厂资料结构化字段,最终以实测值为准
| 产品外部尺寸(宽 × 深 × 高) | 800 × 800 × 550 mm | |
|---|---|---|
| Overall set dimensions (fully extended) | 1200 x 800 x 550 mm | |
| Larger table top size | 800 x 800 mm | |
| Smaller table top size | 600 x 600 mm | |
| Larger table total height | 450 mm | |
| Smaller table total height | 400 mm | |
| Tabletop thickness | 12 mm | |
| Frame tubing cross-section | 20 x 40 mm | |
| Drawer internal usable dimensions | 520 x 480 x 80 mm | |
| Nested set footprint (stowed) | 800 x 800 x 450 mm | |
| Floor clearance under frame | 120 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
重量、承重与性能参数
净重 / 最大承重 / 适用人数 / 耐久性能
数据来源:产品性能数据,采购前请核对具体测试口径
| Total set net weight | 42 kg | |
|---|---|---|
| Distributed static load on tabletop | 50 kg | |
| Drawer static load capacity | 5 kg | |
| Surface scratch resistance rating | 6H | |
| Surface heat resistance | 180 °C | |
| Recommended maximum users | 4 | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
材质与结构参数
工程采购验收核心字段 · 面板基材 / 五金 / 框架 / 面料
数据来源:以工厂材质清单与验货报告为准
| Tabletop surface | 9mm white veined sintered stone with polished finish | |
|---|---|---|
| Tabletop edge trim | Black matte PVC edge banding | |
| Structural frame | 1.2mm thick black powder-coated carbon steel | |
| Drawer body construction | 15mm thick grey melamine-faced MDF | |
| Drawer pull hardware | Zinc alloy gold brushed pull handle | |
| Drawer slides | Side-mounted 3-section silent ball-bearing slides | |
| Frame foot pads | Non-slip PE plastic floor protection pads | |
| Frame welding joints | Full-arc welded steel joints with polished finish | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
功能与调节参数
升降 / 旋转 / 倾仰 / 锁定 / 移动 / 储物功能
数据来源:功能配置参数,以供应商正式规格为准
| Nesting deployment | Smaller table slides partially under larger table for adjustable footprint | |
|---|---|---|
| Drawer storage | Single pull-out drawer on smaller table provides concealed storage for remote controls and small accessories | |
| Stable fixed base | Open sled base eliminates wobble on level hard floors without additional adjustment | |
| Heat-resistant work surface | Polished sintered stone top supports hot mugs and tableware without coasters | |
| Easy cleaning | Smooth non-porous stone and powder-coated metal surfaces wipe clean with a damp cloth | |
| Floor protection | PE foot pads on each frame contact point prevent scuffs on hardwood and tile floors | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
包装与物流参数
经核验的外箱 / 毛重 / 组装 / 装柜数据
数据来源:外贸报价与装柜测算参考
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
应用场景与使用方式
推荐空间 / 目标用户 / 使用方式
数据来源:依据产品结构与品类整理的推荐应用场景
| Primary use space | Small to medium residential living rooms, positioned in front of sofas | |
|---|---|---|
| Secondary use space | Studio apartments and open-plan lounges | |
| Target user group | Urban households seeking modern minimalist luxury furniture | |
| Recommended use case | Serving drinks, displaying decorative items and storing small living room accessories | |
| Complementary decor pairing | Pairs with low-profile fabric or leather sofas, light neutral or dark grey upholstery |
欧盟市场准入要求 * EN 标准
欧洲市场准入与化学品要求
| Furniture surface durability | EN 15185:2011 | |
|---|---|---|
| Domestic furniture stability | EN 12521:2015 |
适用于中国市场项目的标准 * GB 标准
适用于中国市场项目的标准
| Sintered stone tabletop safety | GB/T 3810.1 | |
|---|---|---|
| Metal furniture structural safety | GB/T 3324 | |
| Furniture formaldehyde emission | GB 18584 |
本产品须满足以下技术参数要求: 1. Sintered stone tabletop safety:GB/T 3810.1; 2. Metal furniture structural safety:GB/T 3324; 3. Furniture formaldehyde emission:GB 18584; 最终交付参数、检测报告和验收标准以双方采购合同为准。
