基础物理尺寸
mm / 英寸自动双单位换算 · 工程采购基础规格
数据来源:工厂资料结构化字段,最终以实测值为准
| 产品外部尺寸(宽 × 深 × 高) | 800 × 800 × 450 mm | |
|---|---|---|
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
重量、承重与性能参数
净重 / 最大承重 / 适用人数 / 耐久性能
数据来源:产品性能数据,采购前请核对具体测试口径
| Large table static load capacity | 50 kg | |
|---|---|---|
| Total set net weight | 24 kg | |
| Tabletop surface scratch resistance (Martindale equivalent) | 6 grade | |
| Tabletop heat resistance | 180 °C | |
| Frame static load stability rating | 30 kg lateral force at table edge without tipping | |
| Recommended maximum user weight for edge seating | 80 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
材质与结构参数
工程采购验收核心字段 · 面板基材 / 五金 / 框架 / 面料
数据来源:以工厂材质清单与验货报告为准
| Tabletop substrate and finish | 12mm sintered stone with polished white marble-vein finish, sealed stain-resistant surface | |
|---|---|---|
| Frame structure | Matte black powder-coated carbon steel tubing, cross-braced geometric base | |
| Floor protection pads | Non-slip TPE rubber pads fitted at each foot end | |
| Tabletop edge treatment | Soft rounded pencil edge, polished to match top surface | |
| Frame connection hardware | Zinc-plated steel bolts and cross-braced welding joints | |
| Surface coating on frame | Epoxy-polyester powder coat, 60um thickness, corrosion-resistant for indoor use | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support | |
| Reference Finish / Color Count | Recommended 6top finishes and 3frame colors |
功能与调节参数
升降 / 旋转 / 倾仰 / 锁定 / 移动 / 储物功能
数据来源:功能配置参数,以供应商正式规格为准
| Nested tucking function | Small table slides fully or partially under large table to adjust available surface area | |
|---|---|---|
| Independent use function | Both tables can be separated and positioned as separate side or coffee tables in a room | |
| Surface utility function | Smooth non-porous tabletop supports drink service, decor display and light reading materials | |
| Floor protection function | TPE foot pads prevent scuffing on hard flooring and reduce sliding on carpet | |
| Low-maintenance surface function | Sealed sintered stone top cleans with standard household cleaners and resists common household stains | |
| Tool-free reconfiguration | Tables can be repositioned and rearranged without disassembly of frame or top | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
包装与物流参数
经核验的外箱 / 毛重 / 组装 / 装柜数据
数据来源:外贸报价与装柜测算参考
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
应用场景与使用方式
推荐空间 / 目标用户 / 使用方式
数据来源:依据产品结构与品类整理的推荐应用场景
| Living room seating area placement | Position in front of 3seat sofas for beverage, decor and reading material placement | |
|---|---|---|
| Small apartment flexible layout | Use nested to save floor space when hosting, separated to create additional surface for gatherings | |
| Modern interior style matching | Coordinates with minimalist, contemporary and light luxury interior design schemes | |
| Reception lounge use | Suitable for office reception breakout areas to hold visitor refreshments and decor | |
| Side table alternative use | Individual small table can be used as a side table beside armchairs or beds when separated |
欧盟市场准入要求 * EN 标准
欧洲市场准入与化学品要求
| Furniture surface durability | EN 15185:2011 | |
|---|---|---|
| Furniture stability | EN 1730:2012 | |
| Furniture mechanical strength | EN 12521:2015 |
适用于中国市场项目的标准 * GB 标准
适用于中国市场项目的标准
| Tabletop material safety | GB 6566Class A | |
|---|---|---|
| Furniture structural safety | GB/T 3324 | |
| Metal furniture coating performance | GB/T 2020 |
本产品须满足以下技术参数要求: 1. Tabletop material safety:GB 6566Class A; 2. Furniture structural safety:GB/T 3324; 3. Metal furniture coating performance:GB/T 2020; 最终交付参数、检测报告和验收标准以双方采购合同为准。
